Image preview - the first page of the document
>> Download service documenatation <<
Text preview - extract from the document
Coffee Machine
HD8854 / HD8856
Service
Service
Service
Exploded View
Contents Table
External / Electronical components 1/8
Front panel / User interface 2/8
Coffee dispenser 3/8
Water container 4/8
Milk carafe 5/8
Water system with slim boiler 6/8
Coffee grinder assembly 7/6
Gear motor / Brewing unit 8/8
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system or transmitted, in any form or by any means, electronic, mechanical,
photocopying, or otherwise without the prior permission of Saeco.
Published by Saeco International Group Subject to modification EN 4219 400 00003.6
2012-Dec-14
Exp. E74153 Rev.06 - 04/12/12
14
38 28
13 1
18
19 52
46
L
MAN U
A
15 16 10 45
12 27 2
17
43 26
48 20 3
41
4
21 24
42 37 12 5
12 47
22 25
6
44 49
40 39 12
36 51 7
35
23 8
12
9
32 50
33
12
34 31 11
30 29
HD8854/01-02-03-09-14-15-16 Cod.10003286-87-3521-22-23-24-25-26-78-79
HD8856/01-02-03-04-05-06-08-09-41-43-47 Cod.10003738-39-60-61-3808-78-4089-90
POS CODE 12NC DESCRIPTION NOTE POS CODE 12NC DESCRIPTION NOTE
01 15002582 996530067477 MANUAL PSA HD8854/HD8856 MDS CHN 14 11026339 996530070521 SB/SS WATER CONT.DOOR COVER MDS/H ASSY.
15003143 996530070518 MANUAL PSA HD8854/HD8856 MDS PT/BRA FROM S/N TU901208034136
15001999 996530067561 MANUAL PSA HD8854/HD8856 MDS GB 11023040 996530007555 BLACK WATER CONTAINER DOOR MDS/P
15002047 996530067512 MANUAL PSA HD8854/HD8856 MDS FR UP TO S/N TU901231130583 SEE POSITION 38
15002330 996530067505 MANUAL PSA HD8854/HD8856 MDS ES 11030827 996530072591 MATT/BLACK WATER CONTAINER DOOR MDS/P
02 146680850 996530016529 BLACK COFFEE MEASURE SMART FROM S/N TU901231130584
03 127390100 996530011867 BRUSH FOR CLEANING 15 11028990 996530070519 SB/SS LEFT SIDE PANEL V2 MDS/H ASSY. SS
04 11028379 996530070318 PSA KLUBER TRIBOSTAR SIL 2 TUBE 5GR. FROM S/N TU901208034136
05 21002051 996530071783 ACC PSA MAVEA WATER FILTER 1UNIT USA-BRA UP TO TU901208034135 SEE POSITION 51
06 0301.961 996530039604 STICKER FOR WATER HARDNESS TEST 11022955 996530007511 BLACK LEFT SIDE PANEL MDS/P CLASS
07 183911050 996530025808 BLACK POWER CABLE SCHUKO L=1200 UP TO S/N TU901231130583
183940650 996530025872 BLACK POWER CABLE AUSTRALIA L=1200 11030825 996530072633 MATT/BLACK LEFT SIDE PANEL MDS/P CLASS
11004247 996530002167 BLACK POWER CABLE RVV 3X1 CHINA L=1200 FROM S/N TU901231130584
183930650 996530025858 POWER CABLE CH BLACK 3X1 H05VV-F L=1200 17000804 996530069914 SB/SS LEFT SIDE PANEL W/FAST.MDS/H ASSY. ONLY USA
11001985 996530001089 BLACK POWER CABLE KOREA L=1200 UP TO S/N TU901208034135
07 183970350 996530025882 BLACK POWER CABLE UK L=1200 11028929 996530070512 SB/SS LEFT SIDE PANEL W/FAST.MDS/H ASSY. ONLY USA
11004246 996530002166 BLACK POWER CABLE TAIWAN HVCTF L=1200 FROM S/N TU901208034136
183921950 996530025843 POWER CABLE SJT3 USA BLACK UL L=1200 16 11023035 996530007549 SS SPRING FOR WATER CONTAINER LEVER MDS
17800330 996530069926 BLACK POWER CABLE BRAZIL L=1200 120V 17 11022425 996530007364 YELLOW LEVER FOR WATER CONTAIN.S/SC.MYB9
17800019 996530009627 BLACK POWER CABLE BRAZIL L=1200 230V 18 17000400 996530067486 SB/SS BEAN CONTAIN.DOOR COVER MDS/H ASSY
08 13001097 996530008404 BAND FOR LIFTING L=1800MM H=300MM UP TO S/N TU901208034135
09 20006892 996530067472 KIT PS-E INSERT FOR BOX MDS 11026340 996530070511 SB/SS BEAN CONTAIN.DOOR COVER MDS/H ASSY
10 17000111 996530067464 BLACK COVER CONDUCTING SEAL MDS FROM S/N TU901208034136
11 13001130 996530008417 DISPLAY BOX MDS/H PSA EXPRELIA WE 11023046 996530007558 BLACK BEAN CONTAINER DOOR MDS/P
13001252 996530067528 DISPLAY BOX MDS/H PSA EXPRELIA CEE UP TO S/N TU901231130583 SEE POSITION 38
13001358 996530069911 DISPLAY BOX MDS/H PSA EXPRELIA USA 11030828 996530072577 MATT/BLACK BEAN CONTAINER DOOR MDS/P
12 12000450 996530007819 SCREW TCBR TORX 10 3,5X12 PLAST.ZN-N FROM S/N TU901231130584
13 17000399 996530067522 SB/SS GROUND CONT.DOOR COVER MDS/H ASSY. 19 12001330 996530008026 TRANSP.ROUND ADHESIVE FOOT SJ-5382
UP TO S/N TU901208034135 20 17000113 996530067474 BLACK COVER CASING V2 MDS
11026338 996530070513 SB/SS GROUND CONT.DOOR COVER MDS/H ASSY. 21 11022950 996530007507 BLACK GROUND COFFEE HOPPER PLATE MDS
FROM S/N TU901208034136 22 11023060 996530007567 BLACK HORIZONTAL MOUNTING PLATE MDS
11024933 996530067448 BLACK GROUND CONTAINER DOOR S/SCR.MDS/P 23 11022938 996530067532 BLACK STEEL CASING MDS ASSY.
UP TO S/N TU901231130583 24 11003232 996530001522 AS.CPU+SW WATER LEVEL SENSOR V2
11030840 996530072588 MATT/BLK GROUND CONTAIN.DOOR S/SCR.MDS/P 25 11024263 996530067506 PWR BOARD MDS 230V 230V
FROM S/N TU901231130584 11021342 996530007079 PWR BOARD MYB9/MDS 120V 120V
14 17000398 996530067521 SB/SS WATER CONT.DOOR COVER MDS/H ASSY. 26 11023061 996530007568 BLACK PWR BOARD COVER MDS
UP TO S/N TU901208034135
PSA EXPRELIA TABLE 1a/8
Exp. E74153 Rev.06 - 04/12/12
14
38 28
13 1
18
19 52
46
L
MAN U
A
15 16 10 45
12 27 2
17
43 26
48 20 3
41
4
21 24
42 37 12 5
12 47
22 25
6
44 49
40 39 12
36 51 7
35
23 8
12
9
32 50
33
12
34 31 11
30 29
HD8854/01-02-03-09-14-15-16 Cod.10003286-87-3521-22-23-24-25-26-78-79
HD8856/01-02-03-04-05-06-08-09-41-43-47 Cod.10003738-39-60-61-3808-78-4089-90
POS CODE 12NC DESCRIPTION NOTE POS CODE 12NC DESCRIPTION NOTE
27 11022984 996530067519 BLK-SB/SS REAR FRAME MDS ASSY. FROM S/N.TU901128094835
UP TO S/N TU901210043090 46 11025804 996530070517 CHROM.LEFT LATERAL REAR FRAME INS.MDS
11025064 996530067475 BLK/BLK REAR FRAME MDS ASSY. FROM S/N TU901210043091
UP TO S/N TU901128094834 47 17001089 996530069908 BLK RIGHT LATERAL REAR FRAME INSERT MDS
28 11022956 996530007512 BLACK REAR PANEL WHIT LOGO SAECO MDS FROM S/N.TU901128094835
29 11028928 996530070533 SB/SS RIGHT SIDE PANEL V2 MDS/H ASSY. SS 11025803 996530070514 CHROM.RIGHT LATERAL REAR FRAME INS.MDS
FROM S/N TU901208034136 FROM S/N TU901210043091
UP TO TU901208034135 SEE POSITION 51 48 129912521 996530013148 SCREW TCBR TORX 10 3,5X14 PLAST.SS
11022954 996530007509 BLACK RIGHT SIDE PANEL MDS/P CLASS 49 11023304 996530007613 PWR ELECTR.BOARD INSULATE SHEET MYB9 ONLY USA
UP TO S/N TU901231130583 50 17000007 996530066726 COMPONENTS SUPPORT INSULATE SHEET MYB9 ONLY USA
11030826 996530072549 MATT/BLACK RIGHT SIDE PANEL MDS/P CLASS 51 20007080 996530070509 KIT SPARES SB/SS RIGHT+LEFT PANEL MDS/H
FROM S/N TU901231130584 UP TO TU901208034135
17000806 996530069913 SB/SS RIGHT SIDE PANEL W/FAST.MDS/H ASSY ONLY USA 52 15003523 996530073223 DOCUMENTAT.CD MDS EXPRELIA/ENERGICA ASSY
UP TO S/N TU901208034135
11028927 996530070515 SB/SS RIGHT SIDE PANEL W/FAST.MDS/H ASSY ONLY USA
FROM S/N TU901208034136
30 11021829 996530007156 BLACK/TRANSP.RIGID FOOT MYB9
31 11021769 996530007136 BLACK RIGID FOOT FIXING PIN MYB9
32 11023034 996530007548 BLACK DUMP BOX MDS ASSY.
33 11023032 996530007547 BLK DRIP TRAY COFF.BREW UNIT COVER MDS
34 17002176 996530073075 BLACK COFFEE UNIT DRIP TRAY V2 MDS
35 11023166 996530007589 40POLES FLAT CABLE BOARDS LINK MDS UL
36 11013806 996530006864 BLACK FLAT-CABLE PROTECTION MYB9
37 17000064 996530067437 BLK CAPACIT.SENSOR DEADLOCK INSERT XSM
38 20007164 996530072935 KIT SPAR.MATT/BLK CASING CONT.DOOR MDS/P
UP TO S/N TU901231130583
39 17000363 996530009605 TRANSP.INFRAREDS PLATE MDS
40 11021976 996530007207 STEEL PLATE FOR DOOR CLOSURE MYB9
41 129913202 996530013156 SCREW TCB TORX 10 3X8 PLAST.ZN-B
42 9161.111 996530050555 MAGNET FOR FLOAT SUPERAUT.
