Image preview - the first page of the document
>> Download FM1100_BA_1240291139 documenatation <<
Text preview - extract from the document
User Manual
Philips
FM1200 / FM1100 / FM1300
VHF or UHF
Personal Mobile Radio
Dennis Koller PA4DEN
Jan Buiting PE1CSI
Philips Mobile Radio Collection
July 2001
Contents
User Manual ............................................................................................. 1-6
Appendix A, The FM1200 SB0 PMR with Handsfree Kit................................ 7
Appendix B, FM1200/1300 Equipment Identification Code System................. 8
Appendix C, Microphone Socket and Power Connector Pinouts..................... 9
Appendix D, Local and Remote Mounting Options ........................................ 10
Appendix E, Frequently Asked Questions ................................................... 11
[This document to be printed in colour only]
-1-
Keyboard Layout:
Main Functions: When the transceiver is switched on, the upper
line of the display shows the current channel or
Key(s): Function: the frequency. If a valid tone code is received, it is
0123456789 Enter channel, frequency displayed in the lower right hand corner of the
or number display. The lower display line shows an S (signal
* Scanning strength) meter in the form of a horizontal bar.
# Reverse shift This is called the normal state.
E Activate tone squelch
(CTSS / 5-tone) To activate the second function of a key, press
F Go to Calling Channel the H key. The text `Select Function'' will appear.
G Switch between VFO and The second (alternate) function of the next key
Memory pressed is activated. Press H again to return to
H Select second function of the normal state.
next key
Second (alternate) function:
Key: Function:
1 Adjust transmit power
2 Adjust squelch trip level
3 Select CTCSS tone
4 To MENU
5 To Status Menu
6 Show names with
memory channels
8 Select step size
* Exclude memory channel
from scanning
0 Call
