Image preview - the first page of the document



>> Download DVDR3575H_SB-KL-EX-SI_1237872317 documenatation <<

Text preview - extract from the document

                         DVDR3575H/05/31/58
                        DVDR3577H/05/31/51/58
                        DVDR3595H/05/31/51/58
                         DVDR3597H/05/31/58
                           Service Package
                            Version 1.1
The table below gives the summary of all the files in the service package.
Please refer to this document for the required information.
Chapter No.                                   Reference Document & Instructions
Chapter 1 Technical Specifications and
          Connection Facilities

Chapter 2 Safety Information, General notes
          & Lead-free Requirements


Chapter 3 Directions for Use / QUG            Direction for use is available at website:
                                              www.p4c.philips.com




                                              (EPG /31)



                                              (Non EPG/05/51/58)
Chapter 4 Mechanical Instructions



Chapter 5 Firmware Upgrading, Alignment
          and Test Procedures
          Diagnostic Software




                                              (Diagnostic Software)
Chapter 6 Block Diagram & Wiring Diagram
Chapter 7 Electrical Circuits & Layout      1. Front Panel:
          Drawings, Test Point View,
          Waveforms


                                            2. Analog Board



                                            3. Digital Board



                                            4. HDMI Board



Chapter 8 Exploded View and Service Parts
List




Chapter 9 Revision List
1. Technical Specifications and Connection Facilities
1.1.       PCB Locations




                               Front Board                                                       Standby Board

                                                 Digital Board
                      HDD                                                       Basic Engine




                      Analog Board

                                                   HDMI                                      PSU Board
                                                   Board




1.2.       General

           Mains voltage:                                220V-240V
           Mains frequency:                              50 Hz
           Power consumption:                            35 W
           Standby Power consumption:                    <3.5 W

1.3.       RF Tuner (Analogue)

           Test equipment: Fluke 54200 TV Signal generator
           Test streams: PAL BG Philips Standard test pattern

1.3.1.1.   System

           B/G, I, L/L', D/K


1.3.2.     RF
