Image preview - the first page of the document



>> Download GC6510_ET-SB-EX-SI_1360749605 documenatation <<

Text preview - extract from the document

                                          Pressurized Steam Generator Compact Care
                                                                                                                          GC6510




   Philips Consumer Lifestyle




  Service Manual
   PRODUCT INFORMATION                                                     TECHNICAL INFORMATION
   Iron                                                                    Voltage                :   230 V
   - Dark Blue color                                                       Frequency              :   50 - 60 Hz
   - Blue Ceralon soleplate                                                Power     - Iron       :   800 W
   - Steam rate (max): 95 g/min                                                      - Boiler     :   1370 W
   - Steam trigger with lock                                               Dimension (F-box)      :   39 cm (D) x 25 cm (W) x 37 cm (H)
   - Steam tip                                                             Weight Product)        :   4.7 kg
   - Steam hose length: 1.7 m

   Stand                                                                   Water advice
   - Inox boiler pressure max.: 4.0 bar                                    If the tap water in your area is very hard, it is advisable to mix
   - Boiler volume max.: 800 ml                                            the tap water with an equal amount of demineralised water
   - Steam ready in: 6 minutes
   - Hose cord storage compartment
   - Hose cord length: 1.7 m
   - Power cord length: 1.9 m                                              REPAIR INSTRUCTION
   - Power on light                                                        - No specific issues
   - Overheat safety stop (Thermal fuse)

   EMF & Service Information
                                                                           OPTIONAL (ACCESSORIES)
   - This product meets the requirements regarding
     interference suppression on radio & TV.                               - No specific issues
   - After the product has been repaired, it should function
     properly & has to meet the safety requirements as
     officially laid down at this moment.




Published by Philips Consumer Lifestyle       Printed in the Netherlands
