Image preview - the first page of the document



>> Download gc7020 documenatation <<

Text preview - extract from the document

                                                                         Boiler Steam Iron Intellicare
                                                                                                                        GC7020




   Philips Domestic Appliances and Personal Care




  Service Manual
   PRODUCT INFORMATION                                                   TECHNICAL INFORMATION
   Features                                                              Voltage                  : 230 V
   Iron                                                                  Frequency                : 50 Hz
   - Careeza soleplate                                                   Power consumption
   - Steam output: 80 g/min                                                     Iron              :   800 W
   - Hose cord length: 1.7 m                                                    Boiler            :   1400 W
                                                                         Dimension (F-box)        :   40 cm (L) x 40 cm (W) x 21 cm (H)
   Stand                                                                 Weight (with package)    :   6.4 kg
   - Pressure: 3.5 bar
   - Boiler capacity: 250 ml                                             Water advice
   - Detachable water tank capacity: 800 ml                              If the tap water in your area is very hard, it is advisable to mix
   - Water level sensor to ensure constant steam output                  the tap water with an equal amount of demineralised water.
   - Steam ready in 2.5 min
   - Power cord length: 2.0 m                                            Careeza soleplate
   - Calc clean function                                                 High scratch resistant & superior gliding on various types of
                                                                         fabric.


   Safety Information                                                    Detachable water tank
   - This product meets the requirements regarding                       The detachable water tank can be refilled at any moment,
     interference suppression on radio and TV.                           hence offering non-stop ironing.
   - After the product has been repaired, it should function
     properly and has to meet the safety requirements as                 Water level sensor
     officially laid down as this moment.                                The intelligent water level sensor delivers a constant high
                                                                         steam output.




Published by Philips Domestic Appliances and Personal Care   Printed in the Netherlands
