Image preview - the first page of the document
>> Download GC8510_02 documenatation <<
Text preview - extract from the document
System Iron
GC8510
Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION TECHNICAL INFORMATION
Iron Voltage : 220 - 240 V
- SteamGlide soleplate Frequency : 50 - 60 Hz
- Steam rate max. 110 g/min Power - Iron : 800 W
- Steam boost max. 120 g/min - Boiler : 1200 W
- 2 dot heat up time < 75 sec Dimension (F-box) : 428 mm x 258 mm x 384 mm
Weight : 5.3 kg
Stand
- Rotary power on knob
- Inox boiler pressure max. 5 bar SteamGlide soleplate
- Time to steam < 2 min This specially treated soleplate is designed with 2 distinctly
- 3 level steam selection different types of steam vents:
- Hose cord storage hook - Large vents for maximum crease removal
- Cord set storage compartment - Fine vents for best glide
- Hose cord length 1.9 m
Detachable iron resting mat
- Power cord length 1.8 m
- Detachable iron resting mat This is a heat resistant mat that can be detached from the tray.
It allows you to place your iron horizontally on the ironing
- Iron carry lock
board.
- Water tank empty light
- Detachable water tank capacity 1.6 L Iron carry lock
- Anti calc cartridge in water tank Iron can be locked to the stand via a carry lock slide. This
- ECO steam setting allows you to carry the whole appliance by the handle of the
iron.
EMF & Service Information
- This product meets the requirements regarding
interference suppression on radio & TV.
- After the product has been repaired, it should function
properly & has to meet the safety requirements as
officially laid down at this moment.
