Image preview - the first page of the document



>> Download service documenatation <<

Text preview - extract from the document

                                                                                                            Table solarium
                                                                                                                        HB172/A
                                                                                                                        HB179




   Philips Domestic Appliances and Personal Care




  Service Manual
   PRODUCT INFORMATION
   - This solarium is especially intended for the tanning of
     the face.
   - The UVA-source consists of 2x2 series connected TL's.                   LA1            LA2              LA3        LA4
   - The radiation distance is 10 cm or less.
   - In connection with this small distance the advice is to
     wear protecting goggles during the cure.
                                                                                S1            S2                S3         S4

   TECHNICAL INFORMATION
   -   Input                             :   75 W
                                                                                L1                                                          N
   -   UVA-source                        :   4 x TL CLEO 15W                                                   60 MIN

   -   Radiation area                    :   20 x 26 cm                                                                                     L

   -   Radiation distance                :   10 cm                              L2

   -   Starter                           :   4 x S2
   -   Ballast                           :   2 x 30 W
   -   Timer                             :   60 min./Diehl                 REPAIR INSTRUCTIONS
   -   Protecting goggles                :   4822 690 80072                - If one lamp or starter is defective 2 lamps will not burn
   -   Output UVX36 meter                :   >3.4 mW/cm
