>> Download HB185_SM_4566948006 documenatation <<Text preview - extract from the document Table solarium
HB185/A
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION
- This solarium is especially intended for the tanning of
the face.
LA1 LA2 LA3 LA4 LA5 LA6
- The UVA-source consists of 3x2 series connected TL's.
- The radiation distance is 10 cm or less.
- In connection with this small distance the advice is to
S1 S2 S3 S4 S5 S6
wear protecting goggles during the cure.
TECHNICAL INFORMATION L1 N
60 MIN
- Input : 105 W L
- UVA-source : 6 x TL CLEO 15W L2
- Radiation area : 20 x 26 cm
- Radiation distance : 10 cm L3
- Starter : 6 x S2
- Ballast : 3 x 30 W
- Timer : 60 min./Diehl REPAIR INSTRUCTIONS
- Protecting goggles : 4822 690 80123 - If one lamp or starter is defective 2 lamps will not burn
- Output UVX36 meter : >4.0 mW/cm
