Image preview - the first page of the document
>> Download hd_8753 documenatation <<
Text preview - extract from the document
Coffee Machine HD 8753 HD 8751 HD 8752
Service Intelia
Service
Service
Service Manual
Rev. 01 September 2011
Table of contents Page Table of contents Page
1. Introduction 4.7. Dose self-learning (SAS) 6
1.1. Documentation required 1 4.8. Water level detection (water tank) 7
1.2. Tools and equipment required 1 4.9. Descaling request 7
1.3. Material 1 4.10. Water filter 8
1.4. Safety warnings 1 4.11 Intelia Cappuccino milk carafe 8
1.5 Intelia range 2
1.6.1. External machine parts 3 5. Troubleshooting
1.6.2. Internal machine parts 4 5.1.1. Intelia Cappuccino test mode 1
5.1.2. Intelia Focus and Class Test mode 6
2. Technical specifications 5.2. SteamOut 10
2.1. Technical specifications 1 5.3. Error messages 11
2.2. Machine parameters and performance 2
6. Standard checks
3. User instructions 6.1. Repair schedule 1
3.1. Intelia Cappuccino customer and programming 1 6.2. Service schedule 1
menu 6.3. Final test 2
3.2. Intelia Focus and Class customer and programming 2
menu 7. Disassembly
3.3. Operation, cleaning and maintenance 3
7.1. Intelia Cappuccino outer Shell 1
7.2. Intellia Class and Focus outer Shell 2
4. Operating logic 7.3. Coffee grinder 2
4.1. Water circuit 1 7.4. Grinder blades 3
4.2. Coffee cycle 3 7.5. Coffee grinder adjustment 4
4.3. Single microswitch 4 7.6 Intelia Cappuccino three-way solenoid valve 4
4.4. Temperature sensor 4 7.7 Intelia Class and Focus two-way solenoid valve 5
4.5. Coffee grinder 5 7.8 Intelia Cappuccino carafe fitting body 5
4.6 Low bean level detection, dose quantity 5 7.9 Pump 6
adjustment, coffee grinder blocked
All parts of this document are the property of Saeco International Group.
All rights reserved. This document and all the information herein is provided without liability deriving from any errors or omissions. Furthermore, no part may be reproduced,
used or collected, except where express authorisation has been provided in writing or through a contractual agreement.
Published by Saeco International Group Subject to modification EN 4219 400 00014
2011-Sept-30
Downloaded from www.Manualslib.com manuals search engine
Table of contents Page
7.10. Flow-meter 6
7.11. Power board 6
7.12. Water sensor control board 6
7.13. Gear motor 7
7.14. Boiler 9
7.15. Dispenser assembly 9
7.16. Valve disassembly 9
7.17. Control board and display 10
7.18. Fitting and removing Oetiker clamps 11
8. Notes
9. Water circuit diagram
10 Electrical diagram
Saeco International Group Rev. 01 / September 2011 INTELIA
Downloaded from www.Manualslib.com manuals search engine
CHAPTER 1
INTRODUCTION
Saeco International Group Rev. 01 / September 2011 INTELIA
Downloaded from www.Manualslib.com manuals search engine
INTELIA 01 INTRODUCTION
1.1 Documentation required
The following documentation is needed for repair procedures:
