Image preview - the first page of the document
>> Download service documenatation <<
Text preview - extract from the document
Haloplate
HD4412/00
HD4412/04
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION REPAIR INSTRUCTION
- Product meets the requirements regarding interference - Replacing halogen lamps
suppression on radio and television. Make sure the lamp will not be soiled to maintain the
- After the product has been repaired, it should function guaranteed lifetime.
properly and has to meet the safety requirements as laid - Replacing the reflector
down officially established at this moment. The reflector needs to be replaced when entirely or partly
scorched, deformed.
TECHNICAL INFORMATION - Sensor
Make sure the sensor is fixed on the right place after
- Voltage : 110 V, 220 V
servicing.
- Frequency : 50 - 60 Hz
- Circuit Diagram
- Power consumption : 1500 W - 110 V
1560 W - 220 V HALOGEN
LAMP
- Colour setting : Antique White (HD4412/00)
Dark Aubergine (HD4412/04) FAN
- Sap coding : HD4412/00
SENSOR
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
- No specific issues. MAIN PCB
CONTROL PCB
OPTIONAL (ACCESSORIES)
- No specific issues.
