Image preview - the first page of the document
>> Download HD6161_SM_4569626185 documenatation <<
Text preview - extract from the document
Metal Fryer
HD6161
Philips Domestic Appliances and Personal Care
Service Manual
PRODUCT INFORMATION REPAIR INSTRUCTIONS
- This product meets the requirements regarding - Electrical circuit
interference suppression on radio and TV. When the appliance does not work, check the electrical
- After the product has been repaired, it should function circuit. Be aware of the micro switch that detects if the
properly and has to meet the safety requirements as control panel is correct placed!
officially laid down at this moment. If the Fuse F1 has blown/tripped, the whole heater assy has
to be replaced.
TECHNICAL INFORMATION
- Voltage : 220 - 240 V - The below error messages will be visible on the display if
- Frequency : 50 - 60 Hz they are detected by the system.
- Power consumption : 2200 W Error 2 Thermofuse error (burnt/ not connected)
- Contents Oil : 3500 cc
- Colour : Metal / black Error 3 Overheat (too hot, not enough oil, dry heating)
- Electronic adjustable temperature control : 140 - 190 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
