Image preview - the first page of the document
HD2920-20-21-22-23-24


>> Download HD2920-20-21-22-23-24 documenatation <<

Text preview - extract from the document
                                                                                                                     Air Fryer
                                                                                                               HD9220/20
                                                                                                               HD9220/21
                                                                                                               HD9220/22
                                                                                                               HD9220/23
                                                                                                               HD9220/24


   Philips Consumer Lifestyle




  Service Manual
   PRODUCT INFORMATION                                                      TECHNICAL INFORMATION
   Safety info                                                              - Voltage                           :   220 - 240 V
   - This product meets the requirements regarding                          - Frequency                         :   50 - 60 Hz
     interference suppression on radio and TV.                              - Power consumption                 :   1425 W
   - After the product has been repaired, it should function                - Product dimensions (W x H x D)    :   287 x 315 x 384 mm
     properly and has to meet the safety requirements as                    - Cord length                       :   1 meter
     officially laid down at this moment.                                   - Materials : Outer skin            :   Plastic (PP)
                                                                                        : Pan                   :   Aluminized steel
   - SAP coding        : HD9220/20                                                      : Basket                :   Aluminized steel
                         HD9220/21                                                      : Basket mesh           :   Stainless steel
                         HD9220/22                                                      : Coating               :   PTFE coating
                         HD9220/23                                          - Capacity                          :   2.2 liter
                         HD9220/24                                                                                  (till max indicator)
                                                                            -   Weight                          :   7.0 kg
   OPTIONAL (accessories)                                                   -   Coloursetting                   :   Black
                                                                            -   Temperature                     :   80 till 200
