Image preview - the first page of the document



>> Download Philips_HQ-302A_Marco_Polo_3x1,5V_Battery_Shaver_2009_SM documenatation <<

Text preview - extract from the document

                                                                               Battery Shaver "Marco Polo"
                                                                                                                          HQ 302/A
Service
Service
Service

Domestic Appliances and Personal Care




                                                                                                             SAP Coding HQ 302
HINTS FOR REPAIRS

DISASSEMBLY                                                                                                  SK1
- Remove the shaving unit, to prevent damages
   during repairs.
- Remove the batterieholder.
                                                                                      +
- Unlock the snaplocks from the tailpart.                                                 A
                                                                                          3X1.5V                                M
- Lift the motor unit out of the housing.                                                 LR6
- Loosen the motor clamp springs on the bearing.
   block of the motor with a small screwdriver.
- Unlock the peg-clamping 'Z' (2X) between frame
   (item 8) and hair chamber (item 5).
- To remove the trimmer, first disassemble the trimmer
   slide by pushing down the locking pegs 'V' (2X) and
   move slide slightly outwards.
- Maken room between trimmer and cover with a small                       TECHNICAL DATA
   screwdriver, to release the peg fastening 'Y'.
                                                                          Operating voltage              :    4.5V
                                                                          Power supply                   :    3X AA/LR6 battery
ASSEMBLY                                                                  Shaving heads                  :    2X HQ3
                                                                          Comfort control                :    fixed setting
-     The assembly must be carried out in the reverse                     Trimmer                        :    pop-up system
      order of what is discribed under Disassembly.
-     When fitting the shaver it must be checked if
      wiring is correctly positioned.




     PRODUCTS MEETS THE REQUIREMENTS REGARDING
     INTERFERENCE SUPPRESION ON RADIO AND TELEVISION.

     - AFTER THE PRODUCT HAS BEEN REPAIRED IT SHOULD
       FUNCTION PROPERLY AND HAS TO MEET THE SAFETY
       REQUIREMENTS AS LAID DOWN OFFICIALLY ESTABLISHED
       AT THIS MOMENT.
