Image preview - the first page of the document
>> Download Philips_HQ-7885_Aquagenic_Quadra_Shaver_2011_SM documenatation <<
Text preview - extract from the document
Shaver
HQ 7885
AQUAGENIC
QUADRA
Philips Domestic Appliances and Personal Care
Service Manual SAP coding HQ 7885
HINTS FOR REPAIR: TECHNICAL DATA:
- Remove the shaving unit, to prevent damages during Voltage : 100 - 240 Volt 50 - 60 Hz
repairing. Motor voltage : 2,4 Volt
- Remove screws A1 (2x) Open trimmer for screw. Shaving heads : HQ6 - 4822 690 10214
- Take cover from housing (trimmer must be closed).
- Remove brackets (14 and 21).
- The PCB-board can now be removed out of the housing.
- Remove the connecting strip from the motor by
dis soldering.
- Remove screws B1 (2x) now the motor and hairchamber
can be removed out of the housing.
- Detach the motor springs (17) from the gearwheel unit with
a small screwdriver.
ASSEMBLY:
- Think by assembly on right placing of the trimmer
GENERAL:
- Recharcheble shaver
- Constant motor voltage
- Electronic push on/off
- Washable
- NiCd cell 2AA
This product meets the requirements regard-
- Charge time 1hr/30min
- Charging (mains) indication LCD ing interference suppression on radio and TV.
- Battery low indication LCD
- Battery full indication LCD
- Minutes left LCD
After the product has been repaired, it should
function properly and has to meet the safety
requirements as officially laid down at this
moment.
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
