Image preview - the first page of the document



>> Download HR208490ROW_ET-EX-SI_1374645835 documenatation <<

Text preview - extract from the document

                                                                                                                            Blender
                                                                                                     HR2084/90 ROW




   Philips Consumer Lifestyle




  Service Manual
   PRODUCT INFORMATION                                                   TECHNICAL INFORMATION
   HR2084/90 = HR2080 + Fruitfilter                                      - Power                            :   650 W
                                                                         - Voltage / frequency              :   220 - 240 V / 50 - 60 Hz
   Features                                                                                                 :   110 V / 60 Hz
   - Powerful 650 W                                                      -   Jar capacity                   :   1,5 Litre
   - Speed control knob                                                  -   Speed                          :   0 - 12000 rpm
   - Special buttons for instant results                                 -   Cord length                    :   120 cm
   - 1,5 Litre glass jar                                                 -   Packaging - F-Box
   - Serrated blades                                                         Dimensions (L x W x H)         : 330 x 185 x 370 mm
                                                                             Weight                         : 5,1 kg
   - Detachable knife unit
   - Measuring cup 50 ml                                                 -   Length                         :   190 mm
   - Suction feet                                                        -   Width                          :   150 mm
   - Cord storage                                                        -   Height                         :   190 mm (only Power unit)
                                                                         -   Height with Jar + Lid          :   395 mm
   Accessories:
   - Fruit filter                                                        Materials:
                                                                         - Housing                          :   ABS plastic
   Safety:                                                               - Jar                              :   Borosilicate Glass
   - Attachment safety system                                            - Knife unit                       :   Stainless steel
   - This product meets the requirements regarding                       - Jar lid                          :   PP + rubber
     interference suppression on radio and TV.                           - Measuring cup                    :   SAN
   - After the product has been repaired, it should function             - Bottom + 2 sides                 :   ABS
     properly and has to meet the safety requirements as                 - Switch                           :   ABS lacquered
     officially laid down at this moment.
                                                                         DISASSEMBLY- AND RE-ASSEMBLY ADVISE
                                                                         - No specific issues.
                                                                         REPAIR INSTRUCTION
                                                                         - No specific issues.
                                                                         OPTIONAL (accessories)
                                                                         - No specific issues.

Published by Philips Consumer Lifestyle     Printed in the Netherlands
