Image preview - the first page of the document



>> Download PJVM_ISSUE_66 documenatation <<

Text preview - extract from the document

SI PJVM ISSUE 66                                                         Video Cassette Recorder
5th July 2001


                                                                                                          V13 Chassis
                                                                                                    VR_10, VR_15 series




Service Information
                                        Part Numbers for Tuner
The original Tuner used in these models was 9965 000 04526, due to
shortage of this Tuner at that time, another type was substituted, the
new Tuner part number is 9965 000 05204, please see pictures below:




                       The old Tuner                                                      The new Tuner

These 2 Tuners are not interchangeable, the motherboard has
already been modified to accommodate this change, please order the
spare part according to the picture above.

Replace only the same type of Tuner you remove from the
motherboard, do not change to the other type.
