Image preview - the first page of the document



>> Download U-loader_rework_B documenatation <<

Text preview - extract from the document

                        MCM7,M8 U-loader rework procedure (disassembly) Method B

1. Take out four screws from top panel and then pull out the top panel.

                                                                                                           Equipment : Screw driver Torx 10




2.Screw out four screws of left /right panel and then pull out the left/right panel.

                                                                                                           Equipment : Screw driver Torx 10




3. Use a stick to press the lock of CD tray and let CD tray out, pull of CD tray, then pull off CD cover
                                                                                                           Equipment : stick (about 15-20CM)
4. Open the U-loader assembly fixed screw and disconnect FFC cabel, then take out the U-loader assembly.


                                                                                                           Equipment : Screw driver Torx 10




5.use stick press the lock button and pull CD tray out.


                                                                                                           Equipment : stick (about 15-20CM)
6. Screw out four pieces of screw from four holes on CD module which mount CD modue with bracket module.


                                                                                                                       Equipment : Screw driver Torx 10




7. Disconnect the FFC cable and take out The CD module from CD bracket and screw out four of cross-head screw from module.

                                                                                      Equipment : Screw driver (cross head 2.6)




9. Paste Fiber Washer (8241 150 10571) on each screw.
            Important: Fiber washer should be concentric with the washer of screw.



                                                                                                            Material: fiber washer 8241 150 10571
