Image preview - the first page of the document
>> Download MVH-150UB_2 documenatation <<
Text preview - extract from the document
ORDER NO.
CRT5257
RDS MEDIA CENTER RECEIVER
MVH-150UB /XMUW5
This service manual should be used together with the following manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).
Model No. Order No. Mech. Module Remarks
MVH-350BT/XMEW5 CRT5065 MVH-150UI/XMEW5
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2012
K-ZZZ OCT. 2012 Printed in Japan
1 2 3 4
EXPLODED VIEWS AND PARTS LIST
PACKING(Page 24)
PACKING SECTION PARTS LIST *: Non spare part
A
Mark No. Description MVH-150UI/XMEW5 MVH-150UB/XMUW5
5 Cord Assy QDP3012 QDP3014
7 Unit Box QHG3331 QHG3434
8 Contain Box QHL3331 QHL3434
14-1 Owner's Manual QRD3133 QRB3325
* 14-2 Warranty Card CRY1376 Not used
B EXTERIOR(Page 26)
EXTERIOR SECTION PARTS LIST
Mark No. Description MVH-150UI/XMEW5 MVH-150UB/XMUW5
6 Cord Assy QDP3012 QDP3014
8 Tuner Amp Unit QWM3477 QWM3485
11 Holder QNC3049 QNC3051
19 Detachable Grille Assy QXA3579 QXA3824
25 Button(SRC, BAND) QAC3101 QAC3102
32 Grille Unit QXA3635 QXA3826
C
34 Knob Unit QXA3670 QXA3673
D
E
F
MVH-150UB/XMUW5
2
1 2 3 4
5 6 7 8
ELECTRICAL PARTS LIST(Page 44)
Tuner Amp Unit
Circuit Symbol and No. Part Name MVH-150UI/XMEW5 MVH-150UB/XMUW5
IC301 IC PA2030A PAL011A A
IC531 IC 337S3959 Not used
Q251 Chip Transistor RN1910 Not used
Q531 Transistor LSAR523UB Not used
Q951 Transistor LSAR523UB Not used
D951 Diode 1SS301 Not used
L951 Chip Coil BTH1101 Not used
JA251 Pin Jack CKB1099 CKB1056
JA891 Jack CKS6437 Not used
R251 RS1/16SS821J Not used
B
R252 RS1/16SS821J Not used
R253 RS1/16SS223J Not used
R254 RS1/16SS223J Not used
R531 RS1/16SS473J Not used
R532 RS1/16SS222J Not used
R533 RS1/16SS222J Not used
R534 RS1/16SS272J Not used
R535 RS1/16SS472J Not used
R536 RS1/16SS472J Not used
C
R537 RS1/16SS101J Not used
R538 RS1/16SS101J Not used
R539 Not used RS1/16SS473J
R540 Not used RS1/16SS473J
R604 RS1/16SS473J Not used
R619 Not used RS1/16SS103J
R891 RS1/16SS102J Not used
R892 RS1/16SS102J Not used
R951 RS1/16SS102J Not used D
R952 RS1/16SS223J Not used
R953 RS1/16SS153J Not used
C251 4.7 uF CCG1201 Not used
C252 4.7 uF CCG1201 Not used
C253 CCSSCH101J50 Not used
C254 CCSSCH101J50 Not used
C319 CCSSCH101J50 Not used
C320 CCSSCK1R0C50 Not used
C321 CCSSCH101J50 Not used E
C323 CCSRCH100D50 Not used
C324 CCSRCH100D50 Not used
C325 CCSRCH100D50 Not used
C326 CCSRCH100D50 Not used
C531 CKSSYB104K10 Not used
C532 CKSSYB104K10 Not used
C891 CKSRYB104K16 Not used
C892 CKSRYB104K16 Not used
The mounting positions of the additional parts are described in the circuit diagram and PCB diagram of the parent manual. F
