Image preview - the first page of the document
>> Download PIONEER_MVH-180UI_MVH-189UI_MVH-185UI_CRT5758 documenatation <<
Text preview - extract from the document
ORDER NO.
CRT5758
MVH-180UI/XINEW5
RDS MEDIA CENTER RECEIVER
MVH-180UI /XINEW5
MVH-X189UI /XINID
MVH-X185UI /XINCS1
MVH-X185UI /XINGS
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2015
K-ZZZ JULY 2015 Printed in Japan
1 2 3 4
SAFETY INFORMATION
CAUTION
A
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.
Where in a manufacturer's service documentation, for example in circuit diagrams or lists
of components, a symbol is used to indicate that a specific component shall be replaced only
by the component specified in that documentation for safety reasons, the following symbol shall
be used:
B
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended by the manufacturer.
Discord used batteries according to the manufacturer's instructions.
C
D
E
F
MVH-180UI/XINEW5
2
1 2 3 4
5 6 7 8
CONTENTS
SAFETY INFORMATION .....................................................................................................................................2
1. SERVICE PRECAUTIONS................................................................................................................................4
1.1 SAFETY PRECAUTIONS ...........................................................................................................................4 A
1.2 NOTES ON DISASSEMBLY / ASSEMBLY .................................................................................................4
1.3 NOTES ON REPLACING PARTS ...............................................................................................................4
1.4 NOTES ON ADJUSTMENT ........................................................................................................................4
1.5 OTHERS.....................................................................................................................................................4
2. SPECIFICATIONS.............................................................................................................................................5
2.1 SPECIFICATIONS ......................................................................................................................................5
2.2 DISC/CONTENT FORMAT .........................................................................................................................5
3. BASIC ITEMS FOR SERVICE ..........................................................................................................................5
3.1 CHECK POINTS AFTER SERVICING .......................................................................................................5
4. BLOCK DIAGRAM ............................................................................................................................................6
4.1 BLOCK DIAGRAM......................................................................................................................................6
4.2 POWER BLOCK DIAGRAM .......................................................................................................................8 B
5. DIAGNOSIS ......................................................................................................................................................9
5.1 OPERATIONAL FLOWCHART ...................................................................................................................9
5.2 ERROR CODE LIST.................................................................................................................................10
5.3 CONNECTOR FUNCTION DESCRIPTION .............................................................................................12
5.4 FUSE CHECK...........................................................................................................................................13
6. SERVICE MODE.............................................................................................................................................14
6.1 DISPLAY TEST MODE 1 ..........................................................................................................................14
6.2 DISPLAY TEST MODE 2 ..........................................................................................................................15
6.3 SOFTWARE VERSION UP METHOD......................................................................................................16
7. DISASSEMBLY ...............................................................................................................................................17
8. EACH SETTING AND ADJUSTMENT ............................................................................................................19
C
8.1 PCL OUTPUT CONFIRMATION...............................................................................................................19
9. EXPLODED VIEWS AND PARTS LIST ..........................................................................................................20
9.1 PACKING ..................................................................................................................................................20
9.2 EXTERIOR ...............................................................................................................................................22
10. SCHEMATIC DIAGRAM................................................................................................................................24
10.1 TUNER AMP UNIT (1/2 scale) ...............................................................................................................24
10.2 KEYBOARD UNIT ..................................................................................................................................26
11. PCB CONNECTION DIAGRAM ....................................................................................................................28
11.1 TUNER AMP UNIT .................................................................................................................................28
11.2 KEYBOARD UNIT ..................................................................................................................................32
12. ELECTRICAL PARTS LIST ...........................................................................................................................34
D
E
F
MVH-180UI/XINEW5
5 6 7 8
3
1 2 3 4
1. SERVICE PRECAUTIONS
1.1 SAFETY PRECAUTIONS
A
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.
Please keep the distance of more than 13 cm from focus lens for safety when you check pickup and make adjustment,
and do not look straight at Laser Beam for more than 10 seconds.
1.2 NOTES ON DISASSEMBLY / ASSEMBLY
Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during power-on
mode may damage the ICs inside the unit.
Please be sure to conduct line process to original status if you make assembling after repair.
B
1.3 NOTES ON REPLACING PARTS
Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by electrostatic
induction.
Please be careful of not to apply static charge onto integrated circuits, etc, when you conduct repair work.
Especially, please use soldering iron with its tip grounded.
Also, please use a pair of tweezers with static charge protection capability if there is the possibility of contacting to
device terminals, and avoid the use of metal-made tweezers.
Notes about installation and pin number description of Power IC (IC301: PA2032A)
C The Power IC, PA2032A used on the Tuner Amp Unit is a 25 pin IC.
The same PCB of the Tuner Amp Unit is used for other models that use a 27 pin IC, too.
So, the PCB has lands for a 27 pin IC.
When you replace the Power IC, install the Power IC onto 25 pins (2- 26 pin) located in the center of 27 pins for IC301.
Therefore, when you check the Power IC on the schematic diagram and the PCB connection diagram, you have to pay
attention as follows.
SCHEMATIC DIAGRAM
The pin number of left side is a number
No connection on the PCB (silk printing).
1
2
D 3
4
The pin number of right side (in the IC frame)
5 means the pin number of IC itself.
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
E 24
25
No connection
1.4 NOTES ON ADJUSTMENT
Some of the adjustment is required when the part is replaced.
Pease refer to "8. EACH SETTING AND ADJUSTMENT".
1.5 OTHERS
Notes on soldring
F
For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for
repairs accompanied by reworking of soldering.
MVH-180UI/XINEW5
4
1 2 3 4
5 6 7 8
2. SPECIFICATIONS
2.1 SPECIFICATIONS
For all items except the backup current, refer to the Owner's Manual. A
Backup current......................... 4.0 mA or less
2.2 DISC/CONTENT FORMAT
B
3. BASIC ITEMS FOR SERVICE
3.1 CHECK POINTS AFTER SERVICING
To keep the product quality after servicing, please confirm following check points.
No. Procedures Item to be confirmed
1 Confirm whether the customer complain has The customer complain must not be
been solved. reappeared.
If the customer complain occurs with the Display, audio and operations must be C
specific media, use it for the operation check. normal.
2 FM/AM tuner Check FM/AM tuner action. Display, audio and operations must be
(Seek, Preset) normal.
Switch band to check both FM and AM.
3 Appearance check No scratches or dirt on its appearance after
receiving it for service.
See the table below for the items to be checked regarding audio:
Item to be checked regarding audio
D
Distortion
Noise
Volume too low
Volume too high
Volume fluctuating
Sound interrupted
E
F
MVH-180UI/XINEW5
5 6 7 8
5
1 2 3 4
4. BLOCK DIAGRAM
4.1 BLOCK DIAGRAM
A
BT MIC RL/SW RR/SW FL FR
ANT NM
WIRED REMOTE WIRED REMOTE Power Connector
&
14. BREM &
MIC
15. B.UP
18. B.UP
16. GND
17. GND
13. ACC
6. RR+
10. NC
12. NC
11. ILL
2. FR+
5. RL+
A.ANT
8. RR-
1. FL+
4. FR-
7. RL-
3. FL-
9. NC
JA401 JA912 JA911
JA901
B
VDD3
KEYD,KEYAD IC 201 SYS+
E.VOL JASPER
PM 9013A
MCLK,LRCLK
RESETB,STB
IC 451
DATA,CLK
BCLK,DIN
DC to DC DDCON 5 V
C converter
TUN 3.3 V
5 V to 3.3 V
IC 401 (MM3571A33P)
Lithio IC 601
(TEF6686HN) SYSTEM
TUNL TUNR
R5S726A0D216FP
X-8086 TUNSCL,TUNSDA
Memory: 64 Kbyte
X401 9.216 MHz DALMON
SWVDD
CPPWR
BT1.8EN
For BT modual BTPW
CP_SW 3.3 V X603 16.93 MHz ILMPW
IC 501
CP_SCL,CP_SD Except BT modual SYSPW
iPod CP
337S3959 CPPW,CPRST SYNC
X602 16.93 MHz
USBCTL
D X601 12 MHz DIMMER
*BT model only NRST_CPU MUTE
Suntec BT modual BT 3.3 V RESET
X-8075
BT 1.8 V
X100 26 MHz
LRCLK, BCLK, DATA
SYSTOBT, BTTPSYS
ROT0,ROT1
3 5
USB5V
DSENS
SSENS
CN961
DP,DM
22. MIC_BIAS
16. BT_LRCK
DPDT
KYDT
18. BTBOOT
17. BTMCLK
13. BTDATA
15. BT_BCK
10.DBG_RX
9. DBG_TX
7. BT_RST
20. MIC_N
5. BT 1.8V
6. BT 1.8V
8. BT 3.3V
21. MIC_P
4. BT ON
SWVDD5V
11. BTRX
12. BTTX
19. GND
CN 961
3. GND
14. NC
23. NC
24. NC
1. NC
2. NC
CN801
E
CN1931
7 USBGND
2. ILMGND
3. SWVDD
1. DGND
5. ILM+B
4. ROT1
6. ROT0
CN1931
BTPW
SOURCE
ILMCLR1
ILMCLR2
IC 1801
Display System SWVDD 5 V
PD6586A8
USB 5 V
F LCD
(CAW2056)
USB
GND
VBUS
D+
D-
AUX
MVH-180UI/XINEW5
6
1 2 3 4
5 6 7 8
A
A MVH-180UI/XINEW5
B.UP
ACC
B MVH-X189UI/XINID
or C MVH-X185UI/XINCS1
D MVH-X185UI/XINGS
15. B.UP
18. B.UP
16. GND
17. GND
A MVH-180UI/XINEW5 Only
A.ANT
JA751
L R L R
F R/SW
10A P253
CEK1404
YEK5001-A
A TUNER AMP UNIT
3A
GND RCA GND
B
IC 301 B.Up
IC POWER AMP
PA2032A
STBY MUTE
VDD3.3V STBY
SYS+B 5.78 MUTE
SYS+B SYS+B
RCA MUTE
C
VDD1.2 IC 882
IC 681 VDD1.2
S-1155B12
S-Quad Flash VDD 3.3 V
IC 881
CP_SW 3.3 V VDD 3.3 V
CP_SW 3.3 V S-1170B33
CPPWR
VDD 3.3 V
Q 861 B .UP
IC 821 VDD 6.8 V
SWVDD 5 V SWVDD5.3 X1049AG-TF2 DALMON
VDD 1.2 V NJM2831F53 SWVDD
DALMON
SWVDD ACC IC 991
CPPWR ASENS
A.SENS SYS+B5.78 SYS 5.78 V
BD00GA3 SYSPW
BT1.8EN BSENS
BTPW SSENS B.SENS B.up
ILMPW
SYSPW TEL.IN IC 951 NM
TELIN BT 3.3 V BT 3.3 V
SYNC
S-1200B33-M5
USBCTL
VDD 3.3 V DDCON 5 V D
DIMMER IC 941
BT 1.8 V BT1.8 V
MUTE S-1170B18UC BT18EN
RESET RESET VDD 3.3 V
USB&USB 5 V
B .UP B.up
ILM SUPPLY IC 531
DIMMR CTL Q873 2SCR514PZGE DD con EN
ILM+B KBD9876EFJ DD ON
ILM+B Q876 2SAR502UB
367.347/439.024 kHz
SYNC
DDCON 5 V
USB5V
SYNC
SWVDD5V ILM+B DIM_PWM ILMPW DDCON 5 V
USB 5 V High side
E
16. AUXGND
18. SOURCE
14. DIMMER
B KEYBOARD UNIT
7. USBGND
9. USBGND
2. ILMGND
11. USB5V
3. SWVDD
20.DSENS
12. BTPW
17. AUXR
10. DPDT
1. DGND
5. ILM+B
19.AUXL
4. ROT1
6. ROT0
8. KYDT
CN1931
13. DM
Digital Line
15. DP
Communication Line
PW
ILM+B
I2C Communication line
LMCLR1
LMCLR2
I2S communication line
SWVDD 5 V key matrix Audio Line
Control line
F
MVH-180UI/XINEW5
5 6 7 8
7
1 2 3 4
4.2 POWER BLOCK DIAGRAM
DALMON
1SR154-400 CRG03
B.UP 15.1 V VDD 6.8 V 6.89 V VDD 3.3 V 3.30 V
typ : 14.4V S-1170B33
RESET IC 0.0024 mA 0.0024 mA 0.0024 mA S-80827CNNB
X1049AG-TF2
(10.8 V to 15.1 V)
A MAX 363.1 mA MAX 254.2 mA
typ 220.9 mA typ 166.2 mA
MAX 2.981 W MAX 0.684 W
typ 1.659 W typ 0.606 W
FLASH ROM 25.0 mA 12.0 mA 0.005 mA MX25L1633E for Media u-com
SH Micon 85.0 mA 60.0 mA mA SH726B PVcc
MEDVDD1.2 V 1.20 V
SH Micon 115.0 mA 80.0 mA mA SH726B Vcc
S-1155B12
MAX 115.00 mA
MAX 0.24 W
225.0 mA 152.0 mA 0.0074 mA
typ 0.17 W
CPPWR
B
CP_SW
LSAR523UB
iPod CP 4.2 mA 4.2 mA 0.0 mA 337S3959
Jasper 25.0 mA 10.0 mA mA
TEL.IN mA
SYSPW
SYS5.78 V 5.78 V JASPER
BD00GA3
E-VOL 55.0 mA 38.0 mA mA
PM9013A
EVOL
MAX 73.0 mA
MAX 0.081 W Power AMP 18.0 mA
Mute
SWVDD
C SWVDD5.3 5.25 V
NJM2831F53
Grill u-com 25.0 mA 14.0 mA mA M16C64C?
MAX 35.9 mA
MAX 0.061 W
RBG_DAC 10.4 mA 2.4 mA mA BH2228AFV
LCD module
Remote sensor 0.5 mA 0.3 mA mA GP1UXC14RK
35.9 mA 16.7 mA
SYNC DDON TUNPW
CMS30I30A
DD 5 V 5.20 V TUN 3.3 V 3.30 V
MM3571A33P
Lithio 215.0 mA mA mA Lithio
KBD9876EFJ
MAX 1915.0 mA MAX 215.0 mA
typ 1100.0 mA typ 0.0 mA
MAX 1.106 W MAX 0.409 W
typ 0.636 W typ 0.000 W BT model only
90 %
D
Run_Mode(Waiting_for_command)
BT3.3 V
S-1200B33
BT3.3 V 120.0 mA 120.0 mA 40.0 mA BT model only
MAX 0.120 W
BT1.8 V
S-1170B18UC
BT1.8 V 625.0 mA 180.0 mA 60.0 mA BT model only
MAX(Peak) 1.619 W
MAX 0.456 W
USBCTL
USB 5 V 5.00 V
BD2232G
USB(VBUS) 1400.0 mA 1000.0 mA mA
1.0 A
ILMPW 150.0 mA 120.0 mA mA
2SA1577(QR)
ILM+B
E
Power AMP 300 mA 185 mA
F
MVH-180UI/XINEW5
8
1 2 3 4
5 6 7 8
5. DIAGNOSIS
5.1 OPERATIONAL FLOWCHART
Power ON A
Vcc = 1.2 V Vcc : Pin 12, 20, 43, 78, 86, 109
PVcc = 3.3 V PVcc : Pin 3, 16, 28, 36, 48, 69, 82,101, 112
BSENS
Pin 90 B
BSENS = L
ASENS
Pin 89
ASENS = L
DSENS
C
Pin 34
DSENS = L
Starts
communication
with Grille
microcomputer.
D
300 ms
SWVDD <- H
Pin 1
300 ms
In case of the above signal, the communication
Source keys with Grille microcomputer may fail.
operative If the time interval is not 300 msec, the oscillator
may be defective.
E
Source ON
SYSPW <- H
Pin 8
Completes power-on operation.
(After that, proceed to each source operation) F
MVH-180UI/XINEW5
5 6 7 8
9
1 2 3 4
5.2 ERROR CODE LIST
A Common
CHECK USB
AMP ERROR The USB connector or USB cable has
This unit fails to operate or the speaker short-circuited.
connection is incorrect; the protection ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
