Image preview - the first page of the document
>> Download PIONEER_MVH-X3_CRT5947 documenatation <<
Text preview - extract from the document
ORDER NO.
CRT5947
MVH-X3/XINCS
DIGITAL MEDIA RECEIVER
MVH-X3 /XINCS
PIONEER CORPORATION 28-8, Honkomagome 2-chome, Bunkyo-ku, Tokyo 113-0021, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 2 Jalan Kilang Barat, #07-01, Singapore 159346
PIONEER CORPORATION 2016
K-ZZZ SEPT. 2016 Printed in Japan
1 2 3 4
SAFETY INFORMATION
CAUTION
A This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.
Where in a manufacturer's service documentation, for example in circuit diagrams or lists
of components, a symbol is used to indicate that a specific component shall be replaced only
by the component specified in that documentation for safety reasons, the following symbol shall
be used:
B
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended by the manufacturer.
Discard used batteries according to the manufacturer's instructions.
C
CONTENTS
SAFETY INFORMATION..................................................................................................................................... 2
1. SERVICE PRECAUTIONS ............................................................................................................................... 3
1.1 SAFETY PRECAUTIONS .......................................................................................................................... 3
1.2 NOTES ON DISASSEMBLY / ASSEMBLY................................................................................................. 3
1.3 NOTES ON REPLACING PARTS .............................................................................................................. 3
1.4 OTHERS .................................................................................................................................................... 4
2. SPECIFICATIONS ............................................................................................................................................ 4
2.1 SPECIFICATIONS...................................................................................................................................... 4
2.2 DISC/CONTENT FORMAT ........................................................................................................................ 4
D 3. BASIC ITEMS FOR SERVICE.......................................................................................................................... 4
3.1 CHECK POINTS AFTER SERVICING....................................................................................................... 4
4. BLOCK DIAGRAM............................................................................................................................................ 5
4.1 BLOCK DIAGRAM ..................................................................................................................................... 5
4.2 POWER SUPPLY SYSTEM FIGURE......................................................................................................... 6
5. DIAGNOSIS...................................................................................................................................................... 7
5.1 OPERATIONAL FLOWCHART .................................................................................................................. 7
5.2 ERROR CODE LIST .................................................................................................................................. 8
5.3 CONNECTOR FUNCTION DESCRIPTION ............................................................................................... 9
5.4 FUSE CHECK ............................................................................................................................................ 9
6. SERVICE MODE ............................................................................................................................................ 10
6.1 DISPLAY TEST MODE1 .......................................................................................................................... 10
E
6.2 DISPLAY TEST MODE2 .......................................................................................................................... 11
6.3 SOFTWARE VERSION UP METHOD ..................................................................................................... 12
7. DISASSEMBLY............................................................................................................................................... 13
8. EACH SETTING AND ADJUSTMENT ........................................................................................................... 15
9. EXPLODED VIEWS AND PARTS LIST.......................................................................................................... 16
9.1 PACKING ................................................................................................................................................. 16
9.2 EXTERIOR............................................................................................................................................... 18
10. SCHEMATIC DIAGRAM ............................................................................................................................... 20
10.1 TUNER AMP UNIT................................................................................................................................. 20
10.2 KEYBOARD UNIT.................................................................................................................................. 21
11. PCB CONNECTION DIAGRAM ................................................................................................................... 22
F 11.1 TUNER AMP UNIT................................................................................................................................. 22
11.2 KEYBOARD UNIT.................................................................................................................................. 24
12. ELECTRICAL PARTS LIST .......................................................................................................................... 25
MVH-X3/XINCS
2
1 2 3 4
5 6 7 8
1. SERVICE PRECAUTIONS
1.1 SAFETY PRECAUTIONS
A
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.
Heat sink becomes hot areas. Be careful not to burn yourself.
HEAT SINK
B
1.2 NOTES ON DISASSEMBLY / ASSEMBLY
Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during power-on
mode may damage the ICs inside the unit.
Please be sure to conduct line process to original status if you make assembling after repair.
1.3 NOTES ON REPLACING PARTS C
Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by electrostatic
induction.
Please be careful of not to apply static charge onto integrated circuits, etc, when you conduct repair work.
Especially, please use soldering iron with its tip grounded.
Also, please use a pair of tweezers with static charge protection capability if there is the possibility of contacting to
device terminals, and avoid the use of metal-made tweezers.
Notes about installation and pin number description of Power IC (IC301: PA2032A)
The Power IC, PA2032A used on the Tuner Amp Unit is a 25 pin IC.
D
The same PCB of the Tuner Amp Unit is used for other models that use a 27 pin IC, too.
So, the PCB has lands for a 27 pin IC.
When you replace the Power IC, install the Power IC onto 25 pins (2- 26 pin) located in the center of 27 pins for IC301.
Therefore, when you check the Power IC on the schematic diagram and the PCB connection diagram, you have to pay
attention as follows.
SCHEMATIC DIAGRAM
The pin number of left side is a number
No connection on the PCB (silk printing).
1
2
3
4
The pin number of right side (in the IC frame) E
5 means the pin number of IC itself.
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25 F
No connection
MVH-X3/XINCS
5 6 7 8
3
1 2 3 4
1.4 OTHERS
Notes on soldring
For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
A Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for
repairs accompanied by reworking of soldering.
To secure the front panel
The front panel can be secured with the supplied screw.
Screw
XXX7020
B
2. SPECIFICATIONS
2.1 SPECIFICATIONS
For all items except the backup current, refer to the Owner's Manual.
Backup current......................... 4.0 mA or less
2.2 DISC/CONTENT FORMAT
C
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by Pioneer Corporation is under license.
Other trademarks and trade names are those of their respective owners.
3. BASIC ITEMS FOR SERVICE
D
3.1 CHECK POINTS AFTER SERVICING
To keep the product quality after servicing, please confirm following check points.
No. Procedures Item to be confirmed
1 Confirm whether the customer complain has The customer complain must not be
been solved. reappeared.
If the customer complain occurs with the Display, audio and operations must be
specific media, use it for the operation check. normal.
2 FM/AM tuner Check FM/AM tuner action. Display, audio and operations must be
(Seek, Preset) normal.
E Switch band to check both FM and AM.
3 Appearance check No scratches or dirt on its appearance after
receiving it for service.
See the table below for the items to be checked regarding audio:
Item to be checked regarding audio
Distortion
Noise
Volume too low
Volume too high
F
Volume fluctuating
Sound interrupted
MVH-X3/XINCS
4
1 2 3 4
4.1 BLOCK DIAGRAM
4. BLOCK DIAGRAM
4. BLOCK DIAGRAM
RL/SW RR/SW FL FR
B.UP
ACC
BT MIC & W/R
FM/AM ANT
Power Connector
14. BREM &
NM
15. B.UP
18. B.UP
16. GND
17. GND
13. ACC
6. RR+
10. NC
12. NC
2. FR+
11. ILL
A.ANT
5. RL+
9. TEL
1. FL+
5
8. RR -
-
W/R
5
-
4. FR
7. RL
3. FL-
JA401 JA912 JA911
L R L R
JA901 10A F R/SW
P253
YEK5001 CEK1404
3A
A TUNER AMP UNIT
GND RCA GND
IC301 B. Up
IC POWER AMP
PA2032A
STBY MUTE
VDD3.3V S TBY
IC201
KEYD,KEYAD SYS+B 5.78 MUTE
E.VOL JASPER
PM9013A SYS+B SYS+B
RCA MUTE
MCLK,LRCLK
RESETB,STB
6
6
IC451
DATA,CLK
BCLK,DIN
DC to DC DDCON 5V
TUN 3.3V converter
IC401
5V to 3.3V IC882
IC681 VDD1.2 VDD1.2
MM3571A33P
Lithio S-Quad Flash VDD 3.3V S-1155B12-U5
QWW4058 IC881
IC601 Q501 VDD 3.3 V
CP_SW3.3V CP_SW 3.3V S-1170B33UC-OTS
TEF6686HN SYSTEM
MVH-X3/XINCS
TUNL TUNR LSAR523UB CPPWR Q861 B. Up
R5S726A0D216FP VDD3.3V IC821 VDD 6.8V
X-8086 TUNSCL,TUNSDA SWVDD5.3 KTD2092 DALMON
Memory: 64Kbyte VDD1.2V SWVDD5V NJM2831F53 SWVDD
X401 9.216MHz DALMON
SWVDD IC991
A.SENS ACC SYS+B5.78 SYS5.78V
CPPWR ASENS BD00GA3EEFJ
BT1.8EN BSENS SYSPW
CP_SCL,CP_SD BTPW SSENS B.SENS B.up
IC501
X603 16.93MHz ILMPW
iPod CP CPPW,CPRST
SYSPW TEL.IN IC951
337S3959 SYNC TELIN BT 3.3V BT 3.3V
CP_SW 3.3V MM3411A33N
USBCTL
IC941
DDCON 5V
X601 12MHz DIMMER BT 1.8V BT1.8V
NRST_CPU MUTE MM3479A18P BT18EN
BT 3.3V RESET RESET VDD3.3V
X-8114
BT 1.8V USB&USB5V
X100 26MHz B. Up
ILM SUPPLY B.up
7
7
LRCLK,BCLK,DATA DIMMR CTL Q851 IC531
2SCR514PGZE DD con EN
Q876
ROT0,ROT1
SYSTOBT,BTTPSYS ILM+B KBD9876EFJ DD ON
3 5 ILM+B 2SAR502UB
SYNC
DP,DM
USB5V
DDCON 5V 367.347/439.024kHz
SYNC
SSENS
DSENS
DPDT
KYDT
CN961
22. MIC_BIAS
16. BT_LRCK
18. BTBOOT
17. BTMCLK
13. BTDATA
15. BT_BCK
10.DBG_RX
9. DBG_TX
7. BT_RST
20. MIC_N
21. MIC_P
5. BT 1.8V
6. BT 1.8V
8. BT 3.3V
DDCON 5V
4. BT ON
11. BTRX
SWVDD5V ILM+B
12. BTTX
ILMPW
19. GND
DIM_PWM
CN 961
3. GND
14. NC
23. NC
24. NC
1. NC
2. NC
IC532
USB5V USB 5 V
BD2232G
CN801
CN1941
B KEYBOARD UNIT
CN1941 Digital Line
1. DGND
2. ILMGND
3. SWVDD Communication Line
4. ROT1
5. ILM+B
6. ROT0 I2C Communication line
7. USBGND
8. KYDT SOURCE
9. USBGND PWM ILM+B
10. DPDT I2S communication line
11. USB 5V IC1801
12. BTPW Display System
13. DM Audio Line
14. NC
SWVDD5V key matrix
PDC205A
15. DP
8
8
16. AUXGND Control line
17. AUXR
18. SOURCE
19.AUXL USB5V
20.DSENS L C D
CAW2056
JA1921 JA1901
GND
VBUS
D+
D-
5
AUX USB
E
D
C
A
F
B
1 2 3 4
4.2 POWER SUPPLY SYSTEM FIGURE
A DALMON
B.Up Q861 VDD6.8V IC881
B.UP 15.1 V VDD3.3V
VDD 6.8 V 6.89 V VDD 3.3 V 3.30 V
typ : 14.4V S-1170B33
RESET IC 0.0024 mA 0.0024 mA 0.0024 mA S-80827CNNB
KTD2092
(10.8 V to 15.1 V) L901
MAX 363.1 mA MAX 254.2 mA
typ 220.9 mA typ 166.2 mA
MAX 2.981 W MAX 0.684 W
typ 1.659 W typ 0.606 W
VDD3.3V
FLASH ROM 25.0 mA 12.0 mA 0.005 mA MX25L1633E for Media u-com
VDD3.3V
SH Micon 85.0 mA 60.0 mA mA SH726B PVcc
IC882 VDD1.2
MEDVDD1.2 V 1.20 V
SH Micon 115.0 mA 80.0 mA mA SH726B Vcc
S-1155B12-U5
MAX 115.00 mA
MAX 0.24 W
B Actual survey 80.00 mA 225.0 mA 152.0 mA 0.0074 mA
typ 0.17 W
CPPWR
Q501
CP_SW3.3V
CP_SW
The certification IC 4.2 mA 4.2 mA 0.0 mA 337S3959
LSAR523UB
VDD3.3V
Jasper 25.0 mA 10.0 mA mA
TEL.IN mA
SYSPW
IC991
VDD6.8V 5.78 V
SYS+B5.78
SYS5.78 V JASPER
BD00GA3EEFJ
E-VOL 55.0 mA 38.0 mA mA
PM9013A
EVOL
MAX 73.0 mA
MAX 0.081 W Power AMP
C Mute
18.0 mA
SWVDD
IC821
VDD6.8V 5.25 V SWVDD5V
SWVDD5.3
NJM2831F53
GRILL 25.0 mA 14.0 mA mA M16C64C?
Microcomputer
MAX 35.9 mA
MAX 0.061 W
RBG_DAC 10.4 mA 2.4 mA mA BH2228AFV
LCD Module
Remote-control 0.5 mA 0.3 mA mA GP1UXC14RK
light receiving
35.9 mA 16.7 mA
department
SYNC DDON TUNPW
B.Up DDCON 5V IC451 TUN 3.3V
IC531 5.20 V TUN 3.3 V 3.30 V
DD 5 V
MM3571A33P
Lithio 215.0 mA mA mA Lithio
KBD9876EFJ
MAX 1915.0 mA MAX 215.0 mA
D typ 1100.0 mA typ 0.0 mA
MAX 1.106 W MAX 0.409 W
typ 0.636 W typ 0.000 W BT model only
IC951 Run_Mode(Waiting_for_command)
DDCON 5V BT3.3 V
BT 3.3V 120.0 mA 120.0 mA 40.0 mA BT model only
MM3411A33N
MAX 0.120 W
IC941
DDCON 5V BT1.8 V
BT 1.8V 625.0 mA 180.0 mA 60.0 mA BT model only
MM3479A18P
MAX(Peak) 1.619 W
MAX 0.456 W
USBCTL
IC532
DDCON 5V USB 5 V 5.00 V USB5V
BD2232G
USB(VBUS) 1400.0 mA 1000.0 mA mA
1.0 A Correspondence
E
Q851
B.Up ILM+B
ILMPW mA
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
