Image preview - the first page of the document

>> Download pioneer_avh-p4400bh_avh-4400bt_avh-p4450bt_avh-p4490bt_crt4840 documenatation <<

Text preview - extract from the document

ORDER NO.
CRT4840
AVH-P4400BH/XUUC

DVD RDS AV RECEIVER

AVH-P4400BH /XUUC

AVH-4400BT /XUEW5

AVH-P4450BT /XURC

AVH-P4450BT /XURD

AVH-P4450BT /XURI

AVH-P4490BT /XUID
This service manual should be used together with the following manual(s):
Model No. Order No. Mech.Module Remarks

CX-3283 CRT4843 LS2 DVD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly

Production place difference models exist on these models.
Please note that some parts are not compatible according to the
production place difference.

PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2012
K-ZZZ JAN. 2012 Printed in Japan
1 2 3 4

SAFETY INFORMATION
CAUTION
B
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.

WARNING

This product may contain a chemical known to the State of California to cause cancer, or birth defects or other reproductive
harm.
C
Health & Safety Code Section 25249.6 - Proposition 65

Where in a manufacturer's service documentation, for example in circuit diagrams or lists
of components, a symbol is used to indicate that a specific component shall be replaced only
by the component specified in that documentation for safety reasons, the following symbol shall
be used:

- Safety Precautions for those who Service this Unit.
When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
results.
D
Caution:
1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.

CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

CAUTION
E This product is a class 1 laser product classi-
fied under the Safety of laser products, IEC
60825-1:2007, and contains a class 1M laser
module. To ensure continued safety, do not re-
move any covers or attempt to gain access to
the inside of the product. Refer all servicing to
qualified personnel.

CAUTION--CLASS 1M INVISIBLE LASER
F RADIATION WHEN OPEN, DO NOT VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS.

AVH-P4400BH/XUUC
2
1 2 3 4
5 6 7 8

A
WARNING!
The AEL (accessible emission level )of the laser power output is less than CLASS 1
but the laser component is capable of emitting radiation exceeding the limit for
CLASS 1.
A specially instructed person should do servicing operation of the apparatus.

Laser diode characteristics
Wave length:
DVD:660 nm to 670 nm B
CD:780 nm to 800 nm
Focus lens on Maximum output:
CD:6.26 mW(Emitting period :9 sec.)
DVD:1.27 mW (Emitting period : unlimited)

Additional Laser Caution

Transistors Q1103 and Q1104 in PCB drive the laser diodes for DVD and CD
respectively. When Q1103 or Q1104 is shorted between their terminals,
the laser diodes for DVD or CD will radiate beam. If the top cover is removed C
with no disc loaded while such short-circuit is continued, the naked eyes may
be exposed to the laser beam.

CAUTION
Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended by the manufacture.
Discord used batteries according to the manufacture's instructions.
D

AVH-P4400BH/XUUC
5 6 7 8
3
1 2 3 4

CONTENTS
SAFETY INFORMATION..................................................................................................................................... 2
1. SERVICE PRECAUTIONS ............................................................................................................................... 5
A
1.1 SERVICE PRECAUTIONS ........................................................................................................................ 5
1.2 NOTES ON SOLDERING .......................................................................................................................... 6
2. SPECIFICATIONS ............................................................................................................................................ 7
2.1 SPECIFICATIONS ..................................................................................................................................... 9
2.2 DISC/CONTENT FORMAT ...................................................................................................................... 14
3. BASIC ITEMS FOR SERVICE........................................................................................................................ 15
3.1 CHECK POINTS AFTER SERVICING..................................................................................................... 15
3.2 PCB LOCATIONS .................................................................................................................................... 16
3.3 JIGS LIST ................................................................................................................................................ 16
3.4 CLEANING............................................................................................................................................... 17
4. BLOCK DIAGRAM.......................................................................................................................................... 18
4.1 OVERALL CONNECTION DIAGRAM...................................................................................................... 18
B 4.2 BLOCK DIAGRAM ................................................................................................................................... 20
5. DIAGNOSIS.................................................................................................................................................... 29
5.1 OPERATIONAL FLOWCHART ................................................................................................................ 29
5.2 INSPECTION METHOD OF PICKUP UNIT............................................................................................. 30
5.3 DIAGNOSIS FLOWCHART ..................................................................................................................... 33
5.4 ERROR CODE LIST ................................................................................................................................ 53
5.5 CONNECTOR FUNCTION DESCRIPTION ............................................................................................. 56
6. SERVICE MODE ............................................................................................................................................ 57
6.1 MONITOR TEST MODE .......................................................................................................................... 57
6.2 DVD TEST MODE ................................................................................................................................... 67
7. DISASSEMBLY .............................................................................................................................................. 72
8. EACH SETTING AND ADJUSTMENT ........................................................................................................... 78
C
8.1 DVD ADJUSTMENT ................................................................................................................................ 78
8.2 PCL OUTPUT CONFIRMATION.............................................................................................................. 83
9. EXPLODED VIEWS AND PARTS LIST.......................................................................................................... 84
9.1 PACKING ................................................................................................................................................. 84
9.2 EXTERIOR (1) ......................................................................................................................................... 88
9.3 EXTERIOR (2) ......................................................................................................................................... 90
9.4 EXTERIOR (3) ......................................................................................................................................... 92
9.5 DVD MECHANISM MODULE (1)............................................................................................................. 94
9.6 DVD MECHANISM MODULE (2)............................................................................................................. 96
10. SCHEMATIC DIAGRAM............................................................................................................................... 98
10.1 MOTHER PCB (ANALOG BLOCK)........................................................................................................ 98
D 10.2 MOTHER PCB (SYSTEM BLOCK) (GUIDE PAGE) ............................................................................ 100
10.3 MOTHER PCB (POWER SUPPLY BLOCK) ........................................................................................ 106
10.4 MOTHER PCB (IN/OUT BLOCK) (GUIDE PAGE)............................................................................... 108
10.5 MOTHER PCB (TUNER BLOCK) .........................................................................................................114
10.6 IF PCB ..................................................................................................................................................116
10.7 DVD CORE UNIT (GUIDE PAGE) ........................................................................................................118
10.8 SERVICE UNIT(MONITOR) (GUIDE PAGE) ....................................................................................... 124
10.9 SERVICE UNIT (KEYBOARD)............................................................................................................. 130
10.10 PCB UNIT (SERVICE) ....................................................................................................................... 132
10.11 WAVEFORMS .................................................................................................................................... 134
11. PCB CONNECTION DIAGRAM.................................................................................................................. 136
11.1 MOTHER PCB ..................................................................................................................................... 136
E 11.2 IF PCB.................................................................................................................................................. 140
11.3 DVD CORE UNIT ................................................................................................................................. 142
11.4 SERVICE UNIT (MONITOR) ................................................................................................................ 144
11.5 PCB UNIT (SERVICE) ......................................................................................................................... 148
11.6 SERVICE UNIT (KEYBOARD)............................................................................................................. 150
12. ELECTRICAL PARTS LIST ........................................................................................................................ 151

AVH-P4400BH/XUUC
4
1 2 3 4
5 6 7 8

1. SERVICE PRECAUTIONS
1.1 SERVICE PRECAUTIONS
A

1. You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.
2. Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by electrostatic
induction.
3. Please be sure to conduct line process to original status if you make assembling after repair.
4. Please be careful of not to imply static charge onto integrated circuits, etc, when you conduct repair work.
Especially, please use soldering iron with its tip grounded.
Also, please use a pair of tweezers with static charge protection capability if there is the possibility of contacting to
device terminals, and avoid the use of metal-made tweezers.
5. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during power-on
mode may damage the ICs inside the unit. B
6. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment (shorting-solder)
by referring to "the DISASSEMBLY".
7. Please keep the distance of more than 13 cm from focus lens for safety when you check pickup and make adjustment,
and do not look straight at Laser Beam for more than 10 seconds.
8. Please power adjustment when you replaced mechanical area of DVD Mecha Module or DVD core unit.
9. Graphically-illustrated areas become hot . Be careful not to burn yourself.

C
Holder
Drive
IC Heat Sink

IC1251 Main IC Case

IC1501

10. The acceptance surface of the remote controller on the keyboard PCB is not fixed with a cushion or other materials.
External force applied on the acceptance surface of the remote controller may distort the lead and change the mounting
angle of the acceptance surface, and accordingly, deteriorate the light sensitivity.
Do not apply external force on the acceptance surface of the remote controller.
If you accidentally apply external force, check whether the lead is bent or not.
If the lead is bent, repair it so that the angle between the lead and the acceptance surface becomes 90 degrees, or
exchange the acceptance surface for the remote controller (PNJ4833M).
11. When a home product is used in a vehicle (using DC/AC converter), GND on secondary side of some devices of home
products (PS etc.) becomes indefinite. If these devices are connected to AVH, GND becomes indefinite because ISO is
E
received and the video disordered.
If a defect is generated in a market, the land is prepared between GNDs for connecting GND of AVH sides and VGND
of input as a service.
With this product, a part of VGND pattern is thin. If it is used, insert 0.5A of fuse.
A used part and wiring numbers are shown below.
Wiring number: P531, P532
Used part: CEK1379 or CEK1278
12. The part listed below is difficult to replace as a discrete component part.
When the part listed in the table is defective, replace whole Assy.
SERVICE UNIT (MONITOR) IC5301 OZ527IRN Heat pad
MOTHER PCB IC751 341S2162 QFN package
F
13. On this mechanism, Pickup and Spindle Motor can not be replaced at the service site, because a special facility is
required for the adjustment after replacing them.
So, if Pickup or Spindle Motor is defective, replace the Mechanism Unit.

AVH-P4400BH/XUUC
5 6 7 8
5
1 2 3 4

1.2 NOTES ON SOLDERING

For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs
accompanied by reworking of soldering.

Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 C.
Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 373 C in general, although
the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of
the soldering iron.

Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting
temperatures (hard to melt/easy to harden).
B

The following lead-free solders are available as service parts:
Parts numbers of lead-free solder:
GYP1006 1.0 in dia.
GYP1007 0.6 in dia.
GYP1008 0.3 in dia.

AVH-P4400BH/XUUC
6
1 2 3 4
5 6 7 8

2. SPECIFICATIONS

◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
