Image preview - the first page of the document



>> Download AVH-P5700DVD s.m.part2 documenatation <<

Text preview - extract from the document

                                                                                                                             ORDER NO.
                                                                                                                           CRT3257

DVD MECHANISM MODULE(MS-3V1)



CX-3078
This service manual describes the operation of the DVD mechanism modules
incorporated in the models listed below.
When performing repairs use this manual together with the specific manual for the
model under repair.
           Model No.                          Service Manual                        DVD Mechanism Module

 AVH-P6600DVD/UC                        CRT3193                                CXK6410
 DVH-P5650/RC                           CRT3264                                CXK6414




CONTENTS
1. CIRCUIT DESCRIPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2. MECHANISM DESCRIPTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3. DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18




PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
   PIONEER CORPORATION 2004
                                                                                                           K-ZZU. MAR. 2004 printed in Japan
                1                                       2                                        3                                     4



        1. CIRCUIT DESCRIPTIONS
A       1 Front End Part (MN35103UB, MN35104UB:IC1501)
         MN35103UB and MN35104UB are 1-chip LSI for DVD-Player. The connection of this LSI to the Driver IC,
         SDRAM, Flash-ROM, Audio-DAC, etc. can configure the DVD-Player System.
         This LSI contains Front End (SODC/FE) that performs RF signal /Servo /Decode processings, Back End
         (AV decoder/BE) that performs the video decode processing such as MPEG1/MPEG2/JPEG and audio decode
         processing such as DVD-Audio/AC-3/DTS/MP3, and the system controller (Siscon) for controlling the system.
         Front End part realizes the arithmetic processing of optical head signal and RF signal processing,
         the digital signal processing for DVD-ROM reproduction that conforms to DVD standards (16-8 Demodulation,
         Error correction), the digital signal processing for CD-DA/CD-ROM (Error correction), AV decoder transmission,
         servo control, spindle motor control and seek control.
         Please take note that, since (FEP) and (SODC) with DVD mecha-module (MS3) of CX-3016 are integrated into
         one chip at MN35103UB and MN35104UB, the waveforms of servo system on the front end which had
B        previously appeared at MS3, i.e., the waveforms of FE, TE and AS, cannot be seen anymore.

        1.1 Analog Block (MN35103UB, MN35104UB:IC1501)
         The analog block for IC1501 generates the servo signals including focus and tracking, processes addition of
         RF signals, and controls the laser power of pickup.
         The servo system contains focus operation amp, focus offset adjustment circuit, 3-beam tracking operation amp,
         phase difference tracking detection circuit, tracking offset adjustment circuit, TE2 value-making circuit.
         Also, RF signal processing system contains the functions of AGC and equalizer.

        1.1.1 APC Circuit
         The optical output for the laser diode (LD) has large minus temperature characteristics. Therefore, the constant
C        optical output cannot be obtained when LD is driven by the constant current. APC circuit controls the electric
         current so as to provide constant output at the monitor diode (MD). MN35103UB and MN35104UB contain two
         types of APC circuits, one for DVD and another for CD. The LD electric current for DVD (CD) can be obtained by
         dividing the voltage measurements between DVDLD1 (CDLD1) and 5V by 15.6 (3.9             4=15.6 ). For DVD (CD),
         the results are approx. 26mA (44mA).


                                                                          +5V
                                                                                        3.9 3.9 3.9 3.9                 CN1101


                                                                                +                         CDLD1

                                                    +                                                              24
                                                                                                                         78LD
