Image preview - the first page of the document
>> Download AVIC-F850BT F950BT F950DAB documenatation <<
Text preview - extract from the document
ORDER NO.
CRT5329
AVIC-F950DAB/XNEU5
NAVIGATION AV SYSTEM
AVIC-F950DAB /XNEU5
AVIC-F950BT/XNEU5
AVIC-F850BT/XNEU5
AVIC-F950BT/XNUW5
This service manual should be used together with the following manual(s):
Model No. Order No. Mech.Module Remarks
CX-3283 CRT4843 LS2 DVD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly
PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2013
K-ZZZ MAR. 2013 Printed in Japan
1 2 3 4
SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
A
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.
Where in a manufacturer's service documentation, for example in circuit diagrams or lists
of components, a symbol is used to indicate that a specific component shall be replaced only
by the component specified in that documentation for safety reasons, the following symbol shall
be used:
B
- Safety Precautions for those who Service this Unit.
When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
results.
Caution:
1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.
CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
C
CAUTION
This product is a class 1 laser product classi-
fied under the Safety of laser products, IEC
60825-1:2007, and contains a class 1M laser
module. To ensure continued safety, do not re-
move any covers or attempt to gain access to
the inside of the product. Refer all servicing to
qualified personnel.
D
CAUTION--CLASS 1M VISIBLE AND INVISIBLE
LASER RADIATION WHEN OPEN, DO NOT VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS.
WARNING!
The AEL (accessible emission level )of the laser power output is less than CLASS 1
but the laser component is capable of emitting radiation exceeding the limit for
CLASS 1.
A specially instructed person should do servicing operation of the apparatus.
E
Laser diode characteristics
Wave length:
DVD:660 nm to 670 nm
CD:780 nm to 800 nm
Maximum output:
CD:6.26 mW(Emitting period :9 sec.)
DVD:1.27 mW(Emitting period : unlimited)
Additional Laser Caution
Transistors Q1103 and Q1104 in PCB drive the laser diodes for DVD and CD
F respectively. When Q1103 or Q1104 is shorted between their terminals,
the laser diodes for DVD or CD will radiate beam. If the top cover is removed
with no disc loaded while such short-circuit is continued, the naked eyes may
be exposed to the laser beam.
AVIC-F950DAB/XNEU5
2
1 2 3 4
5 6 7 8
CONTENTS
SAFETY INFORMATION .....................................................................................................................................2
1. SERVICE PRECAUTIONS................................................................................................................................5
1.1 SERVICE PRECAUTIONS .........................................................................................................................5 A
1.2 NOTES ON SOLDERING...........................................................................................................................7
2. SPECIFICATIONS.............................................................................................................................................8
2.1 SPECIFICATIONS ......................................................................................................................................8
2.2 DISC/CONTENT FORMAT.......................................................................................................................13
3. BASIC ITEMS FOR SERVICE ........................................................................................................................14
3.1 CHECK POINTS AFTER SERVICING .....................................................................................................14
3.2 PCB LOCATIONS.....................................................................................................................................15
3.3 JIGS LIST .................................................................................................................................................16
3.4 CLEANING ...............................................................................................................................................17
4. BLOCK DIAGRAM ..........................................................................................................................................18
4.1 OVERALL CONNECTION DIAGRAM ......................................................................................................18
4.2 BLOCK DIAGRAM....................................................................................................................................20 B
4.3 POWER SUPPLY SYSTEM FIGURE.......................................................................................................34
5. DIAGNOSIS ....................................................................................................................................................48
5.1 OPERATIONAL FLOWCHART.................................................................................................................48
5.2 FUSE CHECK...........................................................................................................................................49
5.3 INSPECTION METHOD OF PICKUP UNIT .............................................................................................50
5.4 DIAGNOSIS FLOWCHART FOR DVD UNIT ...........................................................................................53
5.5 DIAGNOSIS OF BACK LIGHT .................................................................................................................70
5.6 ERROR CODE LIST.................................................................................................................................71
5.7 CONNECTOR FUNCTION DESCRIPTION .............................................................................................75
5.8 CONNECTOR FUNCTION DESCRIPTION OF CC ASSY(SERVICE).....................................................76
6. SERVICE MODE.............................................................................................................................................79
C
6.1 TEST MODE.............................................................................................................................................79
6.2 DVD TEST MODE ..................................................................................................................................170
7. DISASSEMBLY .............................................................................................................................................176
8. EACH SETTING AND ADJUSTMENT..........................................................................................................180
8.1 DVD ADJUSTMENT ...............................................................................................................................180
8.2 PCL OUTPUT CONFIRMATION ............................................................................................................185
9. EXPLODED VIEWS AND PARTS LIST ........................................................................................................186
9.1 PACKING................................................................................................................................................186
9.2 EXTERIOR (1) ........................................................................................................................................190
9.3 EXTERIOR (2) ........................................................................................................................................192
9.4 EXTERIOR (3) ........................................................................................................................................194
9.5 DVD MECHANISM MODULE (1) ...........................................................................................................196 D
9.6 DVD MECHANISM MODULE (2) ...........................................................................................................198
10. SCHEMATIC DIAGRAM..............................................................................................................................200
10.1 AV UNIT (S_VEHICLE IF SECTION) ...................................................................................................200
10.2 AV UNIT (S_POWER AMP SECTION).................................................................................................202
10.3 AV UNIT (POWER SECTION)..............................................................................................................204
10.4 AV UNIT (SYSTEM uCOM SECTION) (GUIDE PAGE)........................................................................206
10.5 AV UNIT (S_AVSEL SECTION)............................................................................................................212
10.6 AV UNIT (S_E-VOL SECTION) ............................................................................................................214
10.7 AV UNIT (GUIDE SECTION) ................................................................................................................216
10.8 AV UNIT (RDS-TMC POWER SECTION) ............................................................................................218
10.9 AV UNIT (DISTRIBUTION SECTION) ..................................................................................................220
10.10 AV UNIT (S FMAM TUNER SECTION) ..............................................................................................222 E
10.11 AV UNIT (RDS-TMC TUNER SECTION)............................................................................................224
10.12 AV UNIT (WWR POWER SECTION) .................................................................................................226
10.13 AV UNIT (WWR SECTION) ................................................................................................................228
10.14 AV UNIT (S_SENSOR SECTION)......................................................................................................230
10.15 AV UNIT (EXTERNAL IF SECTION) (GUIDE PAGE).........................................................................232
10.16 AV UNIT (AV-NAVI IF SECTION) (GUIDE PAGE) ..............................................................................238
10.17 AV UNIT (APP MODE MIX SECTION) ...............................................................................................244
10.18 AV UNIT (S DDCON SECTION).........................................................................................................246
10.19 NAVI UNIT (SERVICE) (AV_IF SECTION) (GUIDE PAGE) ...............................................................248
10.20 NAVI UNIT (SERVICE) (MIC SECTION) ............................................................................................254
10.21 NAVI UNIT (SERVICE) (ECHO CANCELLER SECTION)..................................................................256
F
10.22 NAVI UNIT (SERVICE) (DAC SECTION) ...........................................................................................258
10.23 NAVI UNIT (SERVICE) (GUIDE MIX SECTION) ................................................................................260
10.24 NAVI UNIT (SERVICE) (HDMI SECTION) (GUIDE PAGE) ................................................................262
AVIC-F950DAB/XNEU5
5 6 7 8
3
1 2 3 4
10.25 NAVI UNIT (SERVICE) (GRAPHIC IC SECTION) (GUIDE PAGE).................................................... 268
10.26 NAVI UNIT (SERVICE) (LVDS SECTION) ......................................................................................... 274
10.27 NAVI UNIT (SERVICE) (MONITOR_IF SECTION) ............................................................................ 276
10.28 NAVI UNIT (SERVICE) (ASIC SECTION).......................................................................................... 278
A 10.29 NAVI UNIT (SERVICE) (CC_IF SECTION)........................................................................................ 280
10.30 NAVI UNIT (SERVICE) (SD SECTION) ............................................................................................. 282
10.31 NAVI UNIT (SERVICE) (S_GPS SECTION) ...................................................................................... 284
10.32 NAVI UNIT (SERVICE) (BT SECTION) ............................................................................................. 286
10.33 NAVI UNIT (SERVICE) (iPod SECTION)........................................................................................... 288
10.34 NAVI UNIT (SERVICE) (USB SECTION)........................................................................................... 290
10.35 NAVI UNIT (SERVICE) (CANBUS SECTION) ................................................................................... 292
10.36 NAVI UNIT (SERVICE) (SXi SECTION) ............................................................................................ 294
10.37 NAVI UNIT (SERVICE) (LS2_IF SECTION) ...................................................................................... 296
10.38 DVD CORE UNIT (GUIDE PAGE) ..................................................................................................... 298
10.39 MONITOR UNIT (NAVI IF SECTION) ................................................................................................ 304
10.40 MONITOR UNIT (LED-BL SECTION)................................................................................................ 306
B 10.41 MONITOR UNIT (LCD-POWER SECTION) ...................................................................................... 308
10.42 MONITOR UNIT (LVDS SECTION) ................................................................................................... 310
10.43 KEY UNIT (SERVICE) ....................................................................................................................... 312
10.44 MICRO SD UNIT(SERVICE).............................................................................................................. 314
10.45 WAVEFORMS .................................................................................................................................... 315
11. PCB CONNECTION DIAGRAM.................................................................................................................. 318
11.1 AV UNIT ............................................................................................................................................... 318
11.2 NAVI UNIT (SERVICE)......................................................................................................................... 322
11.3 DVD CORE UNIT ................................................................................................................................. 326
11.4 MONITOR UNIT ................................................................................................................................... 328
11.5 KEY UNIT (SERVICE).......................................................................................................................... 332
11.6 MICRO SD UNIT (SERVICE) ............................................................................................................... 333
C
12. ELECTRICAL PARTS LIST ........................................................................................................................ 334
D
E
F
AVIC-F950DAB/XNEU5
4
1 2 3 4
5 6 7 8
1. SERVICE PRECAUTIONS
1.1 SERVICE PRECAUTIONS
A
1. You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.
2. Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by electrostatic
induction.
3. Please be sure to conduct line process to original status if you make assembling after repair.
4. Please be careful of not to imply static charge onto integrated circuits, etc, when you conduct repair work.
Especially, please use soldering iron with its tip grounded.
Also, please use a pair of tweezers with static charge protection capability if there is the possibility of contacting to
device terminals, and avoid the use of metal-made tweezers.
5. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during power-on B
mode may damage the ICs inside the unit.
6. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment (shorting-solder)
by referring to "the DISASSEMBLY".
7. Please keep the distance of more than 13 cm from focus lens for safety when you check pickup and make adjustment,
and do not look straight at Laser Beam for more than 10 seconds.
8. Please power adjustment when you replaced mechanical area of DVD Mecha Module or DVD core unit.
9. Graphically-illustrated areas become hot. Be careful not to burn yourself.
C
Drive
IC
IC1251 Main IC
IC1501
D
10. The part listed below is difficult to replace as a discrete component part.
When the part listed in the table is defective, replace whole Assy.
AV UNIT IC3153 LT1912EMSE Heat pad
IC501 MN864779KT BGA
NAVI UNIT(SERVICE)
IC602 DT090197S BGA
IC4201 R1290K103A Heat pad
MONITOR UNIT IC4101 OZ527ILN Heat pad
IC4002 AK4188VN Heat pad E
11. On this mechanism, Pickup and Spindle Motor can not be replaced at the service site, because a special facility is
required for the adjustment after replacing them.
So, if Pickup or Spindle Motor is defective, replace the Mechanism Unit.
F
AVIC-F950DAB/XNEU5
5 6 7 8
5
1 2 3 4
12. EJECT LOCK MODE for DVD mechanism
A
On the screen shown below, eject lock can be turned ON/OFF.
Connection status screen
Example
Connection status
1 3 2
B
< Procedure >
Short push area "1" -> Short push area "2" -> Long push area "3" on above screen.
(In order to change the status, follow the same operation.)
BEEP sound is not output at operation.
However, if the eject lock is turned ON by "3 Long push", "Tone 2 HIGH" is sounded. If it is turned OFF,
"Tone 2 LOW" is sounded.
C
< Current status >
Example
Connection
status Eject Lock: OFF
Connection Eject Lock: ON
status * ("*" is drawn after the title)
Eject lock is turned OFF.
D DISC EJECT - operation is disabled
DISC LOAD - operation is enabled
E
F
AVIC-F950DAB/XNEU5
6
1 2 3 4
5 6 7 8
1.2 NOTES ON SOLDERING
A
For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs
accompanied by reworking of soldering.
Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 C.
Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 350 C in general, although
the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of
the soldering iron.
Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting
temperatures (hard to melt/easy to harden).
B
The following lead-free solders are available as service parts:
Parts numbers of lead-free solder:
GYP1006 1.0 in dia.
GYP1007 0.6 in dia.
GYP1008 0.3 in dia.
C
D
E
F
AVIC-F950DAB/XNEU5
5 6 7 8
7
1 2 3 4
2. SPECIFICATIONS
2.1 SPECIFICATIONS
A ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
