Image preview - the first page of the document



>> Download avic-n1 documenatation <<

Text preview - extract from the document

www.freeservicemanuals.info                                                                                                         1/7/2013




                                                                                                                           ORDER NO.
                                                                                                                         CRT3221
                                                                           AVIC-N1/UC

          DVD MULTIMEDIA AV NAVIGATION SERVER


          AVIC-N1
          DVD AV NAVIGATION HEAD-UNIT
                                                                                     /UC

          AVIC-X1/EW
          This service manual should be used together with the following manual(s):
             Model No.         Order No.     Mech.Module                                     Remarks

           CX-3016         CRT3056          MS3              DVD Mech. Module:Circuit Description, Mech. Description, Disassembly


            NOTE:
            - Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are
              trademarks of Dolby Laboratories.
            - This product has the unit part number as below.
               Unit Part No.      Description
               CPN1899            Navigation Unit(AVIC-N1/UC)
               CPN1901            Hideaway Unit(AVIC-N1/UC)
               CPN1898            Navigation Unit(AVIC-X1/EW)
               CPN1900            Hideaway Unit(AVIC-X1/EW)
               *) The unit part numbers listed above are not for the service components.




                     For details, refer to "Important symbols for good services".


          PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
          PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
          PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
          PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
            PIONEER CORPORATION 2004
                                                                                                       K-ZZW. FEB. 2004 printed in Japan
                                                     World of free manuals
    www.freeservicemanuals.info
              1                                    2                                3                                4             1/7/2013


     SAFETY INFORMATION
         UC
A
         CAUTION

         This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
         Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
         complex products such as those covered by this manual.
         Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
         If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
         and refer the repair to a qualified service technician.


         WARNING
B
         This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
         California to cause cancer, birth defects or other reproductive harm.
         Health & Safety Code Section 25249.6 - Proposition 65
         This product contains mercury. Disposal of this material may be regulated due to environmental considerations.
         For disposal or recycling information, please contact your local authorities or the Electronics Industries
         Alliance: www.eiae.org.



         EW
         1. Safety Precautions for those who Service this Unit.
C
