Image preview - the first page of the document



>> Download pioneer_avic-z1_hd1bt_uc-ew5_sm documenatation <<

Text preview - extract from the document

                                                                                                                 ORDER NO.
                                                                                                               CRT3618
                                                                 AVIC-Z1/UC

HDD MULTIMEDIA AV NAVIGATION SERVER


AVIC-Z1                                                                  /UC

AVIC-HD1BT                                                                       /EW5


This service manual should be used together with the following manual(s):
   Model No.         Order No.     Mech.Module                                     Remarks

 CX-3016           CRT3056        MS3              DVD Mech. Module:Circuit Descriptions, Mech. Descriptions, Disassembly
 ND-BT1/E5         CRT3684                         Bluetooth unit
                                                   (ND-BT1/E is sold as packed unit of AVIC-HD/BT/EW5 in EW area.)




             For details, refer to "Important Check Points for Good Servicing".


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2006
                                                                                             K-ZZU.MAR. 2006 Printed in Japan
                  1                                 2                                 3                                 4

    SAFETY INFORMATION
        UC
A       CAUTION

        This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
        Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
        complex products such as those covered by this manual.
        Improperly performed repairs can adversely affect the safety and reliability of the product and may void the              .
        If you are not qualified to         the repair of this product properly and          , you should not risk trying to do so



        WARNING
        W

B       This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of

        Health & Safety Code Section 25249.6 - Proposition 65
        This product contains mercury. Disposal of this material may be regulated due to environmental considerations.
        For disposal or recycling information, please contact your local authorities or the Electronics Industries
        Alliance: www.eiae.org.




C




D




E




F




                                                              AVIC-Z1/UC
    2
                  1                                 2                                 3                                 4
               5                                                         6                 7                         8


EW5
1. Safety Precautions for those who Service this Unit.
