Image preview - the first page of the document



>> Download cdx-p650_120 documenatation <<

Text preview - extract from the document

                                                                     CDX-P650/X1N/UC




   Service
   Manual                                                                                                                                       ORDER NO.
                                                                                                                                            CRT2315

MULTI-COMPACT DISC PLAYER



CDX-P650
CDX-P650                                                                X1N/EW
                                                                                                                               X1N/UC



CDX-P650                                                                X1N/ES




- See the separate manual CX-892(CRT2356) for the CD mechanism description, disassembly and circuit
   description.
- The CD mechanism employed in this model is one of C7 series.




CONTENTS
 1.   SAFETY INFORMATION ............................................3          7. GENERAL INFORMATION .......................................35
 2.   EXPLODED VIEWS AND PARTS LIST .......................4                       7.1 IC .........................................................................35
 3.   SCHEMATIC DIAGRAM ...........................................12              7.2 DIAGNOSIS ........................................................40
 4.   PCB CONNECTION DIAGRAM ................................20                         7.2.1 DISASSEMBLY .........................................40
 5.   ELECTRICAL PARTS LIST ........................................26                  7.2.2 TEST MODE ..............................................42
 6.   ADJUSTMENT..........................................................29       7.3 BLOCK DIAGRAM ..............................................48
                                                                                8. OPERATIONS AND SPECIFICATIONS.....................50


PIONEER ELECTRONIC CORPORATION                   4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936

C PIONEER ELECTRONIC CORPORATION 1999                                                                                K-ZZY. FEB. 1999 Printed in Japan
CDX-P650



- CD Player Service Precautions
1. For pickup unit(CXX1285) handling, please refer                         3. Please checking the grating after changing the pickup
   to"Disassembly"(See page 40). During replacement,                          unit(see page 29) since these screws protects the
   handling precautions shall be taken to prevent an                          mechanism during transport, be sure to affix it when
   electrostatic discharge(protection by a short pin).                        it is transported for repair, etc.
2. During disassembly, be sure to turn the power off
   since an internal IC might be destroyed when a con-
   nector is plugged or unplugged.




Transportation of multi-CD Player




                                                                                         Seal
                                                                                         After removing the transport screw, cover the hole
                                                                                         with the supplied seal.




                                            Transport screw
                                            Attach to the original position before transporting the set.




A transport screw has been attached to the set in order to protect
it during transportation. After removing the transport screw,
cover the hole with the supplied seal. Be sure to remove the
transport screw before mounting the set. The removed transport
screw should be retained in the accessory bag for use the next
time the set is transported.




2
                                                                                                           CDX-P650




1. SAFETY INFORMATION

1.1 CDX-P650/X1N/UC
CAUTION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.

WARNING

This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65


1.2 CDX-P650/X1N/EW
1. Safety Precautions for those who Service this Unit.
