Image preview - the first page of the document
>> Download pioneer_deh-2000mp_exploded-views_and_parts-list documenatation <<
Text preview - extract from the document
ORDER NO.
CRT4084
CD RECEIVER
DEH-2000MP /XS/UC
This service manual should be used together with the following manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).
Model No. Order No. Mech. Module Remarks
DEH-2050MP/XN/ES CRT4044
CX-3195 CRT3815 S10.5COMP2 CD Mech.Module : Circuit Descriptions, Mech. Descriptions, Dissassembly
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
K-ZZU. OCT. 2007 Printed in Japan
1 2 3 4
SAFTY INFORMATION
WARNING
A This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65
EXPLODED VIEWS AND PARTS LIST
PACKING(Page 26)
PACKING SECTION PARTS LIST *:Non spare part
B
Mark No. Description DEH-2050MP/XN/ES DEH-2000MP/XS/UC
2 Accessory Assy CEA6708 * YEA5029
3 Screw Not used BPZ20P060FTC
12 Polyethylene Bag CEG1373 CEG1374
13 Unit Box YHG5313 YHG5338
14 Contain Box YHL5313 YHL5338
15 Protector YHP5039 YHP5041
16 Protector YHP5040 YHP5042
C 17-1 Installation Manual YRD5147 Not used
17-2 Owner's Manual YRD5145 YRD5144
* 17-4 Warranty Card Not used CRY1246
18 Case Assy YXB5009 Not used
D
E
F
DEH-2000MP/XS/UC
2
1 2 3 4
5 6 7 8
EXTERIOR(Page 28)
EXTERIOR SECTION PARTS LIST
Mark No. Description DEH-2050MP/XN/ES DEH-2000MP/XS/UC
A
11 Tuner Amp Unit YWM5234 YWM5232(Tuner Amp Assy)
44 Grille Assy YXA5374 YXA5319(Detachable Assy)
45 Grille Unit YXA5334 YXA5302
46 Knob Unit YXC5072 Not used
68 Screw Not used BMZ40P140FTC
69 Earth Plate Not used CNC8915
70 Cushion Not used CNM8890
71 Holder Not used CNV7619
B
68
71
25
14
23 42
C
13
15
17 16
21
A 40
28 D
70
69
26
27
E
F
DEH-2000MP/XS/UC
3
5 6 7 8
1 2 3 4
ELECTRICAL PARTS LIST(Page 52)
TUNER AMP UNIT
Circuit Symbol and No. Part Name DEH-2050MP/XN/ES DEH-2000MP/XS/UC
A
R644 RS1/16S0R0J Not used
R645 RS1/16S0R0J Not used
R646 RS1/16S0R0J Not used
R647 Not used RS1/16S0R0J
R648 RS1/16S0R0J Not used
R670 Not used RS1/16S473J
R671 RS1/16S473J RS1/16S563J
C406 CCSRCH390J50 Not used
B C409 CCSRCH100D50 Not used
C637 CKSRYB103K50 Not used
C646 CKSRYB103K50 Not used
Page 37 Address 6D Page 34 Address 4E
C
D
E
F
DEH-2000MP/XS/UC
4
1 2 3 4
5 6 7 8
KEYBOARD UNIT
Circuit Symbol and No. Part Name DEH-2050MP/XN/ES DEH-2000MP/XS/UC
D1803 LED CL-195SR-CD CL-195PG-CD
D1805 LED CL-195SR-CD CL-195PG-CD A
D1806 LED CL-195SR-CD CL-195PG-CD
D1807 LED CL-195SR-CD CL-195PG-CD
D1808 LED CL-195SR-CD CL-195PG-CD
D1809 LED CL-195SR-CD CL-195PG-CD
D1810 LED CL-195SR-CD CL-195PG-CD
D1811 LED CL-195SR-CD CL-195PG-CD
D1812 LED CL-195SR-CD CL-195PG-CD
D1813 LED CL-195SR-CD CL-195PG-CD B
D1814 LED CL-195SR-CD CL-195PG-CD
D1815 LED CL-195SR-CD CL-195PG-CD
D1816 LED CL-195SR-CD CL-195PG-CD
D1817 LED CL-195SR-CD CL-195PG-CD
D1818 LED CL-195SR-CD CL-195PG-CD
D1819 LED CL-195SR-CD CL-195PG-CD
D1821 LED CL-195SR-CD CL-195PG-CD
R1803 RS1/4SA821J RS1/4SA561J C
R1804 RS1/4SA821J RS1/4SA561J
R1805 RS1/4SA821J RS1/4SA561J
R1806 RS1/4SA681J RS1/4SA391J
R1807 RS1/4SA681J RS1/4SA391J
D
E
F
DEH-2000MP/XS/UC
5
5 6 7 8
