Image preview - the first page of the document



>> Download crt3979_deh_m3067zy91_290 documenatation <<

Text preview - extract from the document

                                                     DAIHATSU




                                                                                                                   ORDER NO.
                                                                                                                CRT3979

COMBINATION CAR STEREO


DEH-M3067ZY91                                                                                                  /XUEW




                                     PRODUCED
   VEHICLE         DESTINATION                       OEM PARTS No.                 ID No.         PIONEER MODEL No.
                                       AFTER

 COO               EUROPE           September 2006   86180-B1080-B0        -----               DEH-M3067ZY91/XUEW




This service manual should be used together with the following manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).
       Model No.        Order No.     Mech. Module                                     Remarks

 DEH-M3067ZY/XU/EW      CRT3790

 CX-3158                CRT3394       S10.1AAC        CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly




PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2007
                                                                                               K-ZZD. JULY 2007 Printed in Japan
                     1                               2                                3                               4

        EXPLODED VIEWS AND PARTS LIST
        NOTES :
