Image preview - the first page of the document
>> Download crt4036_deh_p6000ub_112 documenatation <<
Text preview - extract from the document
ORDER NO.
CRT4036
DEH-P6000UB/XN/EW5
CD RDS RECEIVER
DEH-P6000UB /XN/EW5
This service manual should be used together with the following manual(s):
Model No. Order No. Mech.Module Remarks
CX-3240 CRT4050 S10.5COMP2-iPod/USB CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
K-ZZW. OCT. 2007 Printed in Japan
1 2 3 4
SAFETY INFORMATION
CAUTION
A
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfe.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.
- Safety Precautions for those who Service this Unit.
When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
results.
B Caution:
1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.
CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
C
CLASS 1
LASER PRODUCT
D
WARNING!
The AEL (accessible emission level )of the laser power output is less than CLASS 1
but the laser component is capable of emitting radiation exceeding the limit for
CLASS 1.
A specially instructed person should do servicing operation of the apparatus.
E
Laser diode characteristics
Wave length : 785 nm to 814 nm
Maximum output : 1 190 W(Emitting period : unlimited)
Additional Laser Caution
Transistors Q101 in PCB drive the laser diodes.
When Q101 is shorted between their terminals, the laser diodes will radiate beam.
F If the top cover is removed with no disc loaded while such short-circuit is continued,
the naked eyes may be exposed to the laser beam.
DEH-P6000UB/XN/EW5
2
1 2 3 4
5 6 7 8
CAUTION
Danger of explosion if battery is incorrectly replaced. A
Replaced only with the same or equivalent type recommended by the manufacture.
Discord used batteries according to the manufacture's instructions.
B
C
D
E
F
DEH-P6000UB/XN/EW5
5 6 7 8
3
1 2 3 4
[Important Check Points for Good Servicing]
In this manual, procedures that must be performed during repairs are marked with the below symbol.
Please be sure to confirm and follow these procedures.
A
1. Product safety
Please conform to product regulations (such as safety and radiation regulations), and maintain a safe servicing environment by
following the safety instructions described in this manual.
1 Use specified parts for repair.
Use genuine parts. Be sure to use important parts for safety.
2 Do not perform modifications without proper instructions.
Please follow the specified safety methods when modification(addition/change of parts) is required due to interferences such as
radio/TV interference and foreign noise.
B 3 Make sure the soldering of repaired locations is properly performed.
When you solder while repairing, please be sure that there are no cold solder and other debris.
Soldering should be finished with the proper quantity. (Refer to the example)
4 Make sure the screws are tightly fastened.
Please be sure that all screws are fastened, and that there are no loose screws.
5 Make sure each connectors are correctly inserted.
Please be sure that all connectors are inserted, and that there are no imperfect insertion.
6 Make sure the wiring cables are set to their original state.
Please replace the wiring and cables to the original state after repairs.
C In addition, be sure that there are no pinched wires, etc.
7 Make sure screws and soldering scraps do not remain inside the product.
Please check that neither solder debris nor screws remain inside the product.
8 There should be no semi-broken wires, scratches, melting, etc. on the coating of the power cord.
Damaged power cords may lead to fire accidents, so please be sure that there are no damages.
If you find a damaged power cord, please exchange it with a suitable one.
9 There should be no spark traces or similar marks on the power plug.
When spark traces or similar marks are found on the power supply plug, please check the connection and advise on secure
connections and suitable usage. Please exchange the power cord if necessary.
D a Safe environment should be secured during servicing.
When you perform repairs, please pay attention to static electricity, furniture, household articles, etc. in order to prevent injuries.
Please pay attention to your surroundings and repair safely.
2. Adjustments
To keep the original performance of the products, optimum adjustments and confirmation of characteristics within specification.
Adjustments should be performed in accordance with the procedures/instructions described in this manual.
3. Lubricants, Glues, and Replacement parts
Use grease and adhesives that are equal to the specified substance.
Make sure the proper amount is applied.
E
4. Cleaning
For parts that require cleaning, such as optical pickups, tape deck heads, lenses and mirrors used in projection monitors, proper
cleaning should be performed to restore their performances.
5. Shipping mode and Shipping screws
To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be
installed before shipment. Please be sure to follow this method especially if it is specified in this manual.
F
DEH-P6000UB/XN/EW5
4
1 2 3 4
5 6 7 8
CONTENTS
SAFETY INFORMATION .....................................................................................................................................2
1. SERVICE PRECAUTIONS................................................................................................................................6
1.1 SERVICE PRECAUTIONS .........................................................................................................................6 A
1.2 NOTES ON SOLDERING...........................................................................................................................6
2. SPECIFICATIONS.............................................................................................................................................7
2.1 SPECIFICATIONS ......................................................................................................................................7
2.2 DISC/CONTENT FORMAT.........................................................................................................................8
2.3 PANEL FACILITIES ....................................................................................................................................9
2.4 CONNECTION DIAGRAM........................................................................................................................12
3. BASIC ITEMS FOR SERVICE ........................................................................................................................13
3.1 CHECK POINTS AFTER SERVICING .....................................................................................................13
3.2 PCB LOCATION .......................................................................................................................................13
3.3 JIGS LIST .................................................................................................................................................14
4. BLOCK DIAGRAM ..........................................................................................................................................16
5. DIAGNOSIS ....................................................................................................................................................19 B
5.1 OPERATIONAL FLOWCHART.................................................................................................................19
5.2 ERROR CODE LIST.................................................................................................................................20
5.3 CONNECTOR FUNCTION DESCRIPTION .............................................................................................22
6. SERVICE MODE.............................................................................................................................................23
6.1 CD TEST MODE.......................................................................................................................................23
7. DISASSEMBLY ...............................................................................................................................................25
8. EACH SETTING AND ADJUSTMENT............................................................................................................30
8.1 CD ADJUSTMENT ...................................................................................................................................30
8.2 CHECKING THE GRATING AFTER CHANGING THE PICKUP UNIT ....................................................31
8.3 PCL OUTPUT CONFIRMATION ..............................................................................................................33
9. EXPLODED VIEWS AND PARTS LIST ..........................................................................................................34
C
9.1 PACKING..................................................................................................................................................34
9.2 EXTERIOR(1) ...........................................................................................................................................36
9.3 EXTERIOR(2) ...........................................................................................................................................38
9.4 CD MECHANISM MODULE .....................................................................................................................40
10. SCHEMATIC DIAGRAM................................................................................................................................42
10.1 OVERALL CONNECTION DIAGRAM(GUIDE PAGE)............................................................................42
10.2 KEYBOARD UNIT ..................................................................................................................................48
10.3 CD MECHANISM MODULE(GUIDE PAGE)...........................................................................................50
10.4 WAVEFORMS.........................................................................................................................................56
11. PCB CONNECTION DIAGRAM ....................................................................................................................60
11.1 TUNER AMP UNIT .................................................................................................................................60
11.2 KEYBOARD UNIT...................................................................................................................................64 D
11.3 CD CORE UNIT(S10.5COMP2-iPod) .....................................................................................................66
11.4 PANEL UNIT ...........................................................................................................................................68
12. ELECTRICAL PARTS LIST...........................................................................................................................69
E
F
DEH-P6000UB/XN/EW5
5 6 7 8
5
1 2 3 4
1. SERVICE PRECAUTIONS
1.1 SERVICE PRECAUTIONS
A
1. You should conform to the regulations governing
the product (safety, radio and noise, and other
regulations), and should keep the safety during
servicing by following the safety instructions
described in this manual.
2. Before disassembling the unit, be sure to turn off
the power. Unplugging and plugging the connectors
during power-on mode may damage the ICs inside
the unit.
3. To protect the pickup unit from electrostatic discharge
B during servicing, take an appropriate treatment
(shorting-solder) by referring to "the DISASSEMBLY".
4. After replacing the pickup unit, be sure to check the
grating.
5. Be careful in handling ICs. Some ICs such as MOS
type are so fragile that they can be damaged by
electrostatic induction.
C
1.2 NOTES ON SOLDERING
D
For environmental protection, lead-free solder is used on the printed circuit boards mounted in this unit.
Be sure to use lead-free solder and a soldering iron that can meet specifications for use with lead-free solders for repairs
accompanied by reworking of soldering.
Compared with conventional eutectic solders, lead-free solders have higher melting points, by approximately 40 C.
Therefore, for lead-free soldering, the tip temperature of a soldering iron must be set to around 373 C in general, although
the temperature depends on the heat capacity of the PC board on which reworking is required and the weight of the tip of
the soldering iron.
Compared with eutectic solders, lead-free solders have higher bond strengths but slower wetting times and higher melting
E temperatures (hard to melt/easy to harden).
The following lead-free solders are available as service parts:
Parts numbers of lead-free solder:
GYP1006 1.0 in dia.
GYP1007 0.6 in dia.
GYP1008 0.3 in dia.
F
DEH-P6000UB/XN/EW5
6
1 2 3 4
5 6 7 8
2. SPECIFICATIONS
2.1 SPECIFICATIONS
A
B
C
D
E
F
DEH-P6000UB/XN/EW5
5 6 7 8
7
1 2 3 4
2.2 DISC/CONTENT FORMAT
A
B
C
D
E
F
DEH-P6000UB/XN/EW5
8
1 2 3 4
5 6 7 8
2.3 PANEL FACILITIES
A
B
C
D
E
F
DEH-P6000UB/XN/EW5
5 6 7 8
9
1 2 3 4
A
B
C
D
E
F
DEH-P6000UB/XN/EW5
10
1 2 3 4
5 6 7 8
Fixing the front panel A
If you do not operate the removing and attaching the front panel function, use the supplied
fixing screws and holders to fix the front panel to this unit.
1. Attach the holders to both sides of the front panel.
Holder
CND1249 Holder
CND1250
B
2. Replace the front panel to the unit.
C
3. Flip the holders into upright positions.
D
4. Fix the front panel to the unit using fixing screws.
E
Fixing Screw
BPZ20P060FTB
F
DEH-P6000UB/XN/EW5
5 6 7 8
11
1 2 3 4
2.4 CONNECTION DIAGRAM
A
B
C
D
E
F
DEH-P6000UB/XN/EW5
12
1 2 3 4
5 6 7 8
3. BASIC ITEMS FOR SERVICE
3.1 CHECK POINTS AFTER SERVICING
A
To keep the product quality after servicing, please confirm following check points.
No. Procedures Item to be confirmed
1 Confirm whether the customer complain has The customer complain must not be
been solved. reappeared.
If the customer complain occurs with the Display, audio and operations must be
specific media, use it for the operation check. normal.
2 CD Play back a CD. No malfunction on display, audio and
(Track search) operation.
3 FM/AM tuner Check FM/AM tuner action. Display, audio and operations must be
(Seek, Preset) normal. B
Switch band to check both FM and AM.
4 Check whether no disc is inside the product. The media used for the operating check must
be ejected.
5 Appearance check No scratches or dirt on its appearance after
receiving it for service.
See the table below for the items to be checked regarding audio:
Item to be checked regarding audio
Distortion
Noise
C
Volume too low
Volume too high
Volume fluctuating
Sound interrupted
3.2 PCB LOCATION
D
C Panel Unit
A Tuner Amp Unit
B Keyboard Unit E
Unit Number : QWM3010
Unit Name : Tuner Amp Unit
Unit Number :
Unit Name : Keyboard Unit
Unit Number : CWM8758
Unit Name : Panel Unit
Unit Number : CWX3526
D CD Core Unit Unit Name : CD Core Unit
(S10.5COMP2-iPod) F
(S10.5COMP2-iPod)
DEH-P6000UB/XN/EW5
5 6 7 8
13
1 2 3 4
3.3 JIGS LIST
A - Jigs List
Name Jig No. Remarks
Test Disc TCD-782 Checking the grating
L.P.F. Checking the grating (Two pieces)
- Grease List
B Name Grease No. Remarks
Grease GEM1024 CD Mechanism Module
Grease GEM1045 CD Mechanism Module
Before shipping out the product, be sure to clean the
C
following portions by using the prescribed cleaning
tools:
Portions to be cleaned Cleaning tools
CD pickup lenses Cleaning liquid : GEM1004
Cleaning paper : GED-008
D
E
F
DEH-P6000UB/XN/EW5
14
1 2 3 4
5 6 7 8
A
B
C
D
E
F
DEH-P6000UB/XN/EW5
5 6 7 8
15
1 2 3 4
4. BLOCK DIAGRAM
A TUNER AMP UNIT
A
VDD
LDET
TUNPDO
TUNPDI
TUNPCK
7 6 13 5 10 9 8 11 14 18 19 20 21
NC
CE2
ROM_VDD
SL
DI
CK
CE1
LDET
DO
RDS_CK
RDS_DATA
RDS_LOCK
RDS_HSLK
FM/AM TUNER UNIT
IC 3 EEPROM IC 5
5.0V 5V t 3.3V
B OSC LPF
ANTENNA ANT401
AM ANT FMRF
1
1 ATT
Rch
2,3 24
IC 2
2.5V
FM ANT IC 1
3 3.3V
ATT Lch
23
FMRF MIXER, IF AMP DET, FM MPX,
RDS DECODER
RF adj
ANT adj
T51 CF52
C
AUDIOGND
IC 4
OSCGND
VDD_3.3
RFGND
3.3V 3.3V t 2.5V 2.5V
DGND
VCC
NC
2 12 15 22 16 4 17 TUNL
CDL
3.3V BUS+L
BUS-L
AUXL
CN101 IP-BUS DRIVER AUXG
IC101
7 BUSL+ HA12241FP
11 BUSL-
IP-BUS 5 BUS- 5 BUS- DIN1 1 TX 28
TX
1 BUS+ 6 BUS+ ROUT 2 RX 27
RX
8 19
STBY
8 RX2 SYSTEM
Q101 8 CONTROLLER
IPPW 52 IC 601(2/2)
BUP IPPW
PEG402A8
46
SYSPW
38 39
CN151 Q102 ASENBO MUTE
D 6
5 AUXL
AUX
4 AUXG
3 KEYD 32 KEYD
WIRE 2 KEYAD 92
KEYAD
REMOTE 1 USB5V
REGULATOR
D CD CORE UNIT(S10.5COMP2-iPod) CN521
1
IC501
BD9781HFP
OELPW
48
BUP VIN
PICKUP UNIT RF-AMP, CD DECODER, 68
MP3/WMA DECODER, AMPPW
(P10.5)(SERVICE) DIGITAL SERVO / DATA PROCESSOR CPU, 1 VBUS 5
VOUT VIN
4 2
5
SW
7 26
VDD2 USB HOST CONTROLLER 6 FB EN SYNC
LASER CN101 IC521 INV
DIODE LD-
15 15 141 USB R5523N001B
LD
Q101 USBXTAL 1 EN 1 22 B
MD 142 USBCTL
X205
5 5 PD
48MHz FLG 3 23
FLG
REFO 133
VREF 8 8 REFOUT /USBXTAL 2 2
D- FLPILM
50
AC,BD,E,F Q102 8
HOLOGRAM 3 D+ EJTIN
UNIT VCC VDD2
DSENS
FOM FOM S801
3 3 CD 39
FOP FOP /PUEN 9
FOCUS ACT. 2 2 DRIVER DSENS ILM
E MONITOR
DIODE TRACKING ACT.
TOP
1 1 TOP CN701 CN701 B
TOM
4 4
TOM IC301 5 DP DP
LD+ BA5839FP IC201 DP 16 4
Q82
14 14 TD,FD
12
FOM
PE5611B DM
4 DM
17 3 DM
11 SD,MD LOUT CDL
FOP ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
