Image preview - the first page of the document



>> Download pioneer_deh-p880prsxnuc,deh-p80rsxnes,deh-p88rsxnew5 documenatation <<

Text preview - extract from the document

                                                                                                                  ORDER NO.
                                                                                                                CRT3650
                                                             DEH-P880PRS/XN/UC

MULTI-CD CONTROL HIGH POWER CD/MP3/WMA/AAC PLAYER WITH FM/AM TUNER


DEH-P880PRS                                                                                              /XN/UC
DEH-P80RS/XN/ES
MULTI-CD CONTROL DSP HIGH POWER CD/MP3/WMA/AAC PLAYER WITH RDS TUNER

DEH-P88RS/XN/EW5
This service manual should be used together with the following manual(s):
   Model No.        Order No.      Mech.Module                                     Remarks

 CX-3164          CRT3583         S10.5COMP1       CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly




           For details, refer to "Important Check Points for Good Servicing".


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2006
                                                                                             Z-ZZW. MAR. 2006 Printed in Japan
                  1                               2                               3                                4

    SAFETY INFORMATION
        CAUTION
A       This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
        Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely
        repair complex products such as those covered by this manual.
        Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
        If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
        and refer the repair to a qualified service technician.

        W
        WARNING

        This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
        California to cause cancer
B       Health & Safety Code Section 25249.6 - Proposition 65



        - Safety Precautions for those who Service this Unit.

          results.

        Caution:
          1. During repair or tests, minimum distance of 13cm from the focus lens must be kept.
          2. During repair or tests, do not view laser beam for 10 seconds or longer.

C
              CAUTION:
              USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
              SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.




D




                         CLASS 1
                         LASER PRODUCT


E




F




                                                      DEH-P880PRS/XN/UC
    2
                  1                               2                               3                               4
            5                                6                               7                                8



                                                 WARNING!
                The AEL (accessible emission level )of the laser power output is less than CLASS 1
                                                                                                                        A
                but the laser component is capable of emitting radiation exceeding the limit for
                CLASS 1.
                A specially instructed person should do servicing operation of the apparatus.



                Laser diode characteristics
                Wave length : 785~814nm
                Maximum output : 1190
