Image preview - the first page of the document



>> Download pioneer_deh-x16ub_x1650ub_x1690ub_crt5366_car_audio documenatation <<

Text preview - extract from the document

                                                                                                                ORDER NO.
                                                                                                             CRT5366
                                                             DEH-X16UB/XNUC

CD RDS RECEIVER


DEH-X16UB                                                                                                      /XNUC

DEH-X1650UB                                                                   /XNCS

DEH-X1650UB                                                                   /XNGS

DEH-X1650UBG                                                                           /XNGS

DEH-X1650UB                                                                   /XNGS1

DEH-X1690UB                                                                   /XNID


This service manual should be used together with the following manual(s):
  Model No.      Order No.     Mech. Module                                    Remarks

CX-3287        CRT4759        S11.6STD         CD Mech. Module : Circuit Descriptions, Mech. Descriptions, Disassembly




PIONEER CORPORATION 1-1, Shin-ogura, Saiwai-ku, Kawasaki-shi, Kanagawa 212-0031, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2013
                                                                                            K-ZZZ JULY 2013 Printed in Japan
                  1                                          2                        3                               4

    SAFETY INFORMATION
        CAUTION
A       This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
        Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
        complex products such as those covered by this manual.
        Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
        If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
        and refer the repair to a qualified service technician.

        WARNING
        This product may contain a chemical known to the State of California to cause cancer, or birth defects or
        other reproductive harm.
        Health & Safety Code Section 25249.6 - Proposition 65
B
        Where in a manufacturer's service documentation, for example in circuit diagrams or lists
        of components, a symbol is used to indicate that a specific component shall be replaced only
        by the component specified in that documentation for safety reasons, the following symbol shall
        be used:




        - Safety Precautions for those who Service this Unit.
          When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
          results.

C       Caution:
          1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
          2. During repair or tests, do not view laser beam for 10 seconds or longer.

           CAUTION:
           USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
           SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.


           CAUTION
           This product is a class 1 laser product classi-
D          fied under the Safety of laser products, IEC
           60825-1:2007.




                                                     WARNING!
            The AEL (accessible emission level )of the laser power output is less than CLASS 1
            but the laser component is capable of emitting radiation exceeding the limit for
            CLASS 1.
E
            A specially instructed person should do servicing operation of the apparatus.



            Laser diode characteristics
            Wave length : 785 nm to 814 nm
            Maximum output : 1 190
