Image preview - the first page of the document
>> Download deh-p5800mp_188 documenatation <<
Text preview - extract from the document
ORDER NO.
CRT3638
MULTI-CD CONTROL HIGH POWER CD/MP3/WMA PLAYER WITH RDS TUNER
DEH-P5800MP /X1B/EW
This service manual should be used together with the following manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).
Model No. Order No. Mech. Module Remarks
DEH-P6700MP/XM/EW CRT3435
CX-3158 CRT3394 S10.1AAC CD Mech. Module:Circuit Description, Mech. Description, Disassembly
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
K-ZZA. JAN. 2006 Printed in Japan
1 2 3 4
EXPLODED VIEWS AND PARTS LIST
PACKING(Page 6)
PACKING SECTION PARTS LIST *:Non spare part
A
Mark No. Description DEH-P6700MP/XM/EW DEH-P5800MP/X1B/EW
1 Polyethylene Bag CEG-162 UEG-012
* 11 Polyethylene Bag CEG-158 UEG-019
18 Carton CHG5476 UHG5135
19 Contain Box CHL5476 UHL5158
20 Protector XHP7003 UHP2719
21 Protector XHP7004 UHP2720
22-1 Owner's Manual CRD3959 URD3876
B
22-2 Owner's Manual CRD3960 URD3877
22-3 Owner's Manual CRD3961 URD3878
22-4 Installation Manual CRD3962 URD3879
* 22-5 Passport CRY1013 CRY1014
* 22-6 Warranty Card CRY1157 URY1087
* 22-7 Caution Card CRP1332 Not used
23 Case Assy CXB3520 UXB-009
Owner's Manual,Installation Manual
C
Part No. Language
URD3876 English, Spanish
URD3877 German, French
URD3878 Italian, Dutch, Russian
URD3879 English, Spanish, German, French, Italian, Dutch, Russian
EXTERIOR(Page 8)
EXTERIOR SECTION PARTS LIST
D
Mark No. Description DEH-P6700MP/XM/EW DEH-P5800MP/X1B/EW
1 Screw BMZ30P040FZK BMZ30P040FTB
16 FM/AM Tuner Unit CWE1645 UWE1645
25 Holder CND1352 UND1749
28 Holder XNC7003 UND1767
30 Holder Unit CXB6681 CNC8659(Holder)
53 Sub Panel Unit XXA7361 CXC4367
58 Chassis Unit CXC4063 CXC5982
E 59 Detach Grille Assy CXC4175 CXC6099
60 Screw BPZ20P100FZK BPZ20P100FTB
63 Button(1-6) CAC9038 CAC9673
73 Cover CNS8149 CNS8546
86 Sub Grille Assy CXC4243 CXC6104
92 Label VRW-329 *CAN1616
93 Case XNB7002 UNB2883
96 Panel XNS7089 CNS8547
F
97 Choke Coil(L981) CTH1291 YTH5001
2 DEH-P5800MP/X1B/EW
1 2 3 4
5 6 7 8
ELECTRICAL PARTS LIST(Page 41)
TUNER AMP UNIT
Circuit Symbol and No. Part Name DEH-P6700MP/XM/EW DEH-P5800MP/X1B/EW A
Q102 Transistor DTC124EU DTC124EUA(Digital Transistor)
Q301 Transistor DTC124EU DTC124EUA(Digital Transistor)
ZNR401 Surge Protector CSA30-201N RCCA-201Q31UA-PI
L981 Choke Coil 600 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
