Image preview - the first page of the document



>> Download deh-p9600mp documenatation <<

Text preview - extract from the document

                                                                                                                 ORDER NO.
                                                                                                               CRT3192
                                                             DEH-P9600MP/XN/EW

MULTI-CD CONTROL DSP HIGH POWER CD/MP3/WMA PLAYER WITH RDS TUNER


DEH-P9600MP                                                                                                    /XN/EW


This service manual should be used together with the following manual(s):
   Model No.        Order No.      Mech.Module                                     Remarks

 CX-3098         CRT3179          S10WMAcode2      CD Mech. Module:Circuit Description, Mech. Description, Disassembly




           For details, refer to "Important symbols for good services".


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2004
                                                                                              K-ZZU.FEB. 2004 printed in Japan
                 1                                2                            3                               4


    SAFETY INFORMATION
A       - CD Section Precaution
        1. Before disassembling the unit, be sure to turn off
           the power. Unplugging and plugging the connectors
           during power-on mode may damage the ICs inside
           the unit.
        2. To protect the pickup unit from electrostatic discharge
           during servicing, take an appropriate treatment
           (shorting-solder) by referring to "the DISASSEMBLY"
           on page 64.
        3. After replacing the pickup unit, be sure to check the
           grating. (See p.60.)
B
    This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
    Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely
    repair complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
    If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
    and refer the repair to a qualified service technician.

    1. Safety Precautions for those who Service this Unit.
