Image preview - the first page of the document

>> Download fx-mg8527zt_115 documenatation <<

Text preview - extract from the document

TOYOTA

ORDER NO.
CRT2902
FX-MG8527ZT/EW

RECEIVER ASSY, RADIO

FX-MG8527ZT EW

FX-MG8627ZT EW

FX-MG8527ZT-91 EW

FX-MG8627ZT-91 EW
PRODUCED PIONEER MODEL
VEHICLE DESTINATION TOYOTA PARTS No. ID No.
AFTER No.
LAND CRUISER EUROPE September 2002 86120-60510 P3914 FX-MG8527ZT/EW
PRADO
LAND CRUISER EUROPE September 2002 86120-60510 P3914 FX-MG8527ZT-91/EW
PRADO
LAND CRUISER EUROPE September 2002 86120-60500 P3915 FX-MG8627ZT/EW
PRADO
LAND CRUISER EUROPE September 2002 86120-60500 P3915 FX-MG8627ZT-91/EW
PRADO

This service manual should be used together with the following manual(s):
Model No. Order No. Mech.Module Remarks

CX-951 CRT2872 G2 CD Mech. module: Circuit Description, Mech. Description, Disassembly

CX-1011 CRT2406 3L Cassette Mech. module: Mech. Description, Disassembly

Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.

For details, refer to "Important symbols for good services".

PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
K-ZZD.AUG. 2002 printed in Japan
1 2 3 4

SAFETY INFORMATION
- CD section precaution
A
1. Before disassembling the unit, be sure to turn off the 2. To protect the pickup unit from electrostatic dis-
power. Unplugging and plugging the connectors dur- charge during servicing, take an appropriate treat-
ing power-on mode may damage the ICs inside the ment (shorting-solder) by referring to "the DISAS-
unit. SEMBLY" on page 84.

3. After replacing the pickup unit, be sure to check the
grating. (See p.74.)

2 FX-MG8527ZT/EW
1 2 3 4
5 6 7 8

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely
repair complex products such as those covered by this manual. A
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.

1. Safety Precautions for those who Service this Unit.
