Image preview - the first page of the document



>> Download pioneer_AVIC-X1 documenatation <<

Text preview - extract from the document

                                                                                                                    ORDER NO.
                                                                                                                  CRT3423
                                                                   AVIC-N2/XU/UC

DVD MULTIMEDIA AV NAVIGATION SERVER


AVIC-N2
DVD AV NAVIGATION HEAD-UNIT
                                                                              /XU/UC

AVIC-X1R/XU/EW
This service manual should be used together with the following manual(s):
   Model No.        Order No.        Mech.Module                                      Remarks

 CX-3016          CRT3056           MS3               DVD Mech. Module:Circuit Description, Mech. Description, Disassembly



 NOTE:
 Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks
 of Dolby Laboratories.
 This product has the unit part number as below.
  Unit Part No.       Description
  CPN1955             Navigation Unit(AVIC-N2/XU/UC)
  CPN1953             Hideaway Unit(AVIC-N2/XU/UC)
  CPN1954             Navigation Unit(AVIC-X1R/XU/EW)
  CPN1952             Hideaway Unit(AVIC-X1R/XU/EW)
  *) The unit part numbers listed above are not for the service components.




           For details, refer to "Important Check Points for Good Servicing".



PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2005
                                                                                                K-ZZW. FEB. 2005 Printed in Japan
                 1                                 2                                  3                                  4


    SAFETY INFORMATION
        UC
A
        CAUTION

        This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
        Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair

        Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
        If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so



        W
        WARNING
B
        This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
        California to cause cancer, birth defects or other reproductive harm.
                                 r
        Health & Safety Code Section 25249.6 - Proposition 65
        This product contains mercury. Disposal of this material may be regulated due to environmental considerations.
        For disposal or recycling information, please contact your local authorities or the Electronics Industries
        Alliance: www.eiae.org.



        EW
        1. Safety Precautions for those who Service this Unit.
C
