   Service
   Manual                                                  AVH-P6500DVD/UC
                                                                                                           ORDER NO.
                                                                                                        CRT3038
AV RECEIVER/DVD PLAYER WITH 6.5 INCH WIDE DISPLAY



AVH-P6500DVD                                                                                                        UC

AVH-P6500DVD                                                          EW

AVH-P6550DVD                                                          RC,RD



- This service manual should be used together with the following manual(s):
Model No.         Order No.     Mech. Module Remarks
CX-3016           CRT3056       MS3          DVD Mech. Module:Circuit Description, Mech.Description, Disassembly




NOTE:
- Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby
  Laboratories. Confidential unpublished works.
