Image preview - the first page of the document



>> Download pioneer_avhp7500dvd documenatation <<

Text preview - extract from the document

   Service
   Manual                                                 AVH-P7500DVD/UC
                                                                                                            ORDER NO.
                                                                                                         CRT3039
7 INCH WIDE FULLY MOTORIZED LCD COLOR DISPLAY WITH 5 CHANNEL HIGH-POWER DVD/VCD/CD RECEIVER



AVH-P7500DVD                                                                                                 UC,EW




- This service manual should be used together with the following manual(s):
Model No.         Order No.    Mech. Module Remarks
AVH-P7500DVD      CRT3112                     ADJUSTMENT, GENERAL INFORMATION AND OPERATIONS
/UC,EW
CX-3016           CRT3056      MS3            DVD Mech. Module:Circuit Description, Mech.Description, Disassembly



NOTE:
- Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby
  Laboratories.
- Inverter for LCD back light becomes a high voltage.




           For details, refer to "Important symbols for good services".


PIONEER CORPORATION             4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936

C PIONEER CORPORATION 2003                                                              K-ZZU. JUNE 2003 Printed in Japan
              1                                2                              3                                4




    - DVD Player Service Precautions
A
    1. Before disassembling the unit, be sure to turn off the power. Unplugging and plugging the connectors during
       power-on mode may damage the ICs inside the unit.
    2. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment (shorting-sol-
       der) by referring to " the DISASSEMBLY" on page 49 of CRT3112.
    3. Please adjusting the skew after changing the pickup unit(see page 8 of CRT3112).
    4. During disassembly, be sure to turn the power off since an internal IC might be destroyed when a connector is
       plugged or unplugged.


    SAFETY INFORMATION
B

    UC
    CAUTION

    This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
    Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
    complex products such as those covered by this manual.
    Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
    If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
    and refer the repair to a qualified service technician.

C   WARNING

    This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
    California to cause cancer, birth defects or other reproductive harm.
    Health & Safety Code Section 25249.6 - Proposition 65

    EW
    1. Safety Precautions for those who Service this Unit.
