Image preview - the first page of the document



>> Download vsx-d514-k_208 documenatation <<

Text preview - extract from the document

                                                                                                                                                                                                                                        AUDIO/VIDEO MULTI-CHANNEL RECEIVER   VSX-D514




                                                                                                                                                                                                                                                                              MULTI JOG
                                                     DVD/LD    DVD 5.1   TV/SAT   DVR/VCR



                                                                CD-R/                                                                                                                                                                          ENTER
                                                      CD       TAPE/MD    FM        AM




                                                                                                                                                                                                                                                          MASTER VOLUME


                                                                                                                                                      ADVANCED   STEREO/   SIGNAL   MIDNIGHT/    SPEAKER     VSB
                                                                                                   STATION             TUNING             STANDARD    SURROUND    DIRECT   SELECT   LOUDNESS    IMPEDANCE   MODE   TONE   QUICK SETUP
                                                        STANDBY/ON                                                                                                                                                                           DOWN                                   UP


                                                                                                                                                  LISTENING MODE                                                      MULTI JOG




                                                                                                                                                                                                                                                                                                              ORDER NO.
                                                                                            TUNER EDIT   CLASS   MPX      INPUT ATT   FL DIMMER      MUTE



                                                           PHONES
                                                                                            MULTI JOG




                                                                                                                                                                                                                                                                                                           RRV2936
                                                                                                                          VSX-D514-K

AUDIO/VIDEO MULTI-CHANNEL RECEIVER


VSX-D514-K
VSX-D514-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model             Type                      Power Requirement                                                                                                                                                                                                                                Remarks

 VSX-D514-K      MYXJI             AC220-230V

 VSX-D514-K      MYXJIFG           AC220-230V

 VSX-D514-S      MYXJI             AC220-230V

 VSX-D514-S      MYXJIFG           AC220-230V

 VSX-D514-S      MVXJI             AC230V




   For details, refer to "Important symbols for good services".


PIONEER CORPORATION         4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2004
