Image preview - the first page of the document
>> Download RRV3676_DVR-555HX-S documenatation <<
Text preview - extract from the document
ORDER NO.
RRV3676
DVR-555HX-S
HDD/DVD RECORDER
DVR-555HX-S
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Serial No.
Model Type Power Requirement Region No. Please confirm 3rd & 4th
alphabetical letters.
DVR-555HX-S WYXK5 AC 220 V to AC 240 V 2 &&UK######$$
This service manual should be used together with the following manual(s):
Model Order No. Remarks
DVR-LX60D/WYXK5 RRV3573
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
T-ZZA-001 OCT. 2007 printed in Japan
1 2 3 4
1. CONTRAST OF MISCELLANEOUS PARTS
NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
A Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560 56 x 10 1 561 RD1/4PU 5 6 1 J
47k 47 x 10 3 473 RD1/4PU 4 7 3 J
0.5 R50 RN2H R 5 0 K
1 1R0 RS1P 1 R 0 K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
B
5.62k 562 x 10 1 5621 RN1/4PC 5 6 2 1 F
1.1 CONTRAST TABLE
DVR-550HX-S/WYXK5 and DVR-555HX-S/WYXK5 are constructed the same except for the following:
DVR-550HX-S/ DVR-555HX-S/
Mark No. Symbol and Description Remarks
WYXK5 WYXK5
PCB ASSEMBLIES
NSP 1.. TUJB ASSY VWM2436 VWM2425
P97-2 2.. SERVICE DVUB Assy VXX3232 VXX3231 *1
C
PACKING SECTION
P95-3 RF Anttenna Cable (PAL) VDE1075 VDE1095
P95-9 Packing Case VHG2795 VHG2873
P95-12 Operating Instructions (French) VRC1378 VRC1446
P95-13 Operating Instructions (German) VRC1383 VRC1448
P95-14 Operating Instructions (Italian) VRC1387 VRC1450
P95-15 Operating Instructions (Dutch) VRC1391 VRC1452
P95-16 Operating Instructions (Spanish) VRC1395 VRC1454
D EXTERIOR SECTION
P97-25 Housing Assy 10P Not used VKP2391 DVUB Assy -
MAIN Assy
P97-27 Rear Panel VNA3020 VNA3052
FRONT PANEL SECTION
P101-17 Front Panel VNK6221 VNK6334
P101-20 FL Lens VXA2870 VXA2930
*1: Refer to SERVICE DVUB Assy (VXX3231) for DVR-LX60.
E
F
2 DVR-555HX-S
