Image preview - the first page of the document



>> Download Pioneer+KRL-46V+LCD documenatation <<

Text preview - extract from the document

                                                                                                          ORDER NO.
                                                                                                        ARP3517
                                                                 KRL-46V

FLAT SCREEN TV


KRL-46V
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
    Model             Type                    Power Requirement                             Remarks

 KRL-46V        WYVSIXSP5          AC 220 V to 240 V




       For details, refer to "Important Check Points for good servicing".


PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
  PIONEER CORPORATION 2008
                                                                                        T-ZZK OCT. 2008 Printed in Japan
                        1                                                             2                                                            3                                                             4

    SAFETY INFORMATION

A   IMPORTANT SERVICE SAFETY PRECAUTION

            Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the
            servicing guidelines which follow:
