   LDC500 Series                                                                 O500C Series Cables

   Laser Diode Cables
   Two styles of cable are available to connect the LDC500 series controller to a laser diode--
   a flyinglead cable and a double terminated cable.  Both styles have a 9pin male Dsub
   connector to mate with the controller.  All SRS laser diode cables are specially constructed
   for high flexibility and high bandwidth, and optimized for use with the LDC500 series
   controllers.
   The terminated version (see Figure 1) is available in two lengths (6 ft and 12 ft).





   Figure 1
