                PRODUCTUPDATE

                 tools. The addition of a system-         to evaluate Universal Mobile
                 explorer window allows users to          Telecommunication System (UMTS)
                 browse global fonts and background       or General Packet Radio Service
                 scripts; an enhanced properties win-     (GPRS) network elements before
                 dow with hierarchical tree control       making them operational within a
                 gives a streamlined, application-        live network. The LTS21 enables cus-
                 dedicated parameter layout.              tomers to test 3G networks with re-
                    Base price: free. DVT,                alistic but simulated voice calls and
                 www.dvtsensors.com.                      data streams from many thousands
                                                          to many millions of mobile units.
                 Odyssey Xpro+ features                      Base price: $250,000. Tektronix,
                                                          www.tektronix.com.
                 1.4-GHz PowerPC
                 The Odyssey Xpro+ enhanced ver-          Clock generator handles
                 sion of the Matrox Odyssey Xpro
                 scalable vision-processor board          2-GHz signals
                 features the latest version of the       Engineers often use RF synthesizers
                 Freescale G4 PowerPC embedded            to generate clock signals over 1
                 microprocessor with a core fre-          GHz. With the CG635, you can free
                 quency starting at 1.4 GHz, a Matrox-    those expensive instruments for
                 designed Oasis processing and            other tasks. The CG635 can gener-
                 router ASIC, and a customizable co-      ate single-ended and differential
                 processor FPGA. The single-slot          clocks at frequencies from 0.001 Hz
                 Odyssey Xpro+ also offers over 5
                 Gbytes/s of memory bandwidth, up
                 to 2 GBytes of DDR SDRAM, up to 2
                 Gbytes/s of external I/O bandwidth,
                 and PCI-X bus support.
                     Like the Odyssey Xpro, the
                 Odyssey Xpro+ can capture from
                 the majority of area- or line-scan
                 video sources, thanks to a standard      to 2.05 GHz. Jitter is less than 1 ps
                 PCI mezzanine card (PMC) site lo-        with phase noise less than
