Image preview - the first page of the document
>> Download SM210 documenatation <<
Text preview - extract from the document
EXPLODED VIEWS AND PARTS LIST
1-19
1-10 1-14
1-16 1-18
1-11
1-3
1-15
1-2
1-5
1-13
1-9
1-1
1-17
Mar
K2
1-7
1-20 1-4
1-15
1-21
1-8
1-12
1-28
1-25
1-24 1-6 1-15 1-29
1-23
1-22
1-26
1-27
34
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
1- 1 9001-0746-01A Body Ass'y-2 1
1- 2 7211-0289-02A Tripod Connector 1
1- 3 9007-1386-01A Front Cover Ass'y (DIGIMAX 210SE) 1
9007-1490-01A Front Cover Ass'y (KENOX DIGIMAX 210SE) 1
1- 4 7217-1857-04A Front Cover (DIGIMAX 210SE) 1
7217-2070-01A Front Cover (KENOX DIGIMAX 210SE) 1
1- 5 7217-1859-02A Grip Cover 1
1- 6 7409-1035-01B FCC Sticker 1
1- 7 0960-2139-01A Tape 2
1- 8 7308-0069-01A Jack Door 1
1- 9 9007-1387-01A Back Cover Ass'y 1
1 -10 7308-0063-01A Power Jack Cap 1
1 - 11 9007-1388-01A Top Cover Ass'y 1
1 - 12 9007-1389-01A Battery Cover Ass'y 1
1 - 13 9761-1735-07 Screw 3
1 - 14 7217-1852-01A EP Window 1
1 - 15 6003-0242-01A Screw 6
1 - 16 9761-1760-12 Screw 1
1 - 17 7017-0284-01A Logo Plate 1
1 - 18 9007-1506-01A Monitor Window Ass'y 1
1 - 19 7217-1851-02A Status LCD Window 1
1 - 20 7217-1862-01A Finder Window 1
1 - 21 9002-0821-01A Front Panel Ass'y 1
1 - 22 7217-1240-02A Front Panel 1
1 - 23 6735-0013-01A Sky Light Filter 1
1 - 24 7217-1241-02A Spacer-C 1
1 - 25 9761-1430-01A Screw 3
1 - 26 7409-0682-01A Front Panel Tape 2
1 - 27 7012-0612-01A Decoration Ring 1
1 - 28 7212-1268-02A Lens Cap 1
1 - 29 9761-1740-01 Screw 1
35
2-8
2-46 2-8
2-43 2-16
2-11
2-30 2-17 2-8
2-29 2-31
2-32 2-37
2-26
2-38 2-28
2-27
2-8
2-4 2-36
2-33
2-25 2-19
2-18
2-8
2-8
2-9
2-5 2-15 2-35
2-24
2-39
2-22
2-21
2-23 2-44
2-41
2-14
2-40
2-42 2-8
2-7
2-6
2-3
2-2 2-3
2-1
2-13
2-20
2-12
2-34
2-8
2-11
2-10
36
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
2-1 7211-0547-06A Body 1
2-2 7011-0352-03A Battery Contact-A 1
2-3 7011-0353-02A Battery Contact-B 2
2-4 3002-0007-01A Buzzer 1
2-5 2401-0046-01A Main Condensor 1
2-6 9353-2000-01 Self LED 1
2-7 4104-0135-01A SPD PCB 1
2-8 9761-1735-07 Screw 13
2-9 9008-0347-01A Power PCB Ass'y 1
2 - 10 9002-0811-01A Barrel Ass'y 1
2 - 11 9761-1750-07 Screw 5
2 - 12 9003-0146-01A Finder Ass'y 1
2 - 13 0474-9116-01A Screw 2
2 - 14 9008-0346-01A CCD PCB Ass'y 1
2 - 15 6002-0007-01A Screw 2
2 - 16 9008-0348-01A Main PCB Ass'y 1
2 - 17 3708-0024-01A CF Ejector 1
2 - 18 0408-0006-01A Diod Photosennsor 1
2 - 19 7211-0555-01A LED Holder 1
2 - 20 9008-0361-01A LED F PCB Ass'y 1
2 - 21 7211-0549-03A Reflector Holder 1
2 - 22 7014-0032-02A Reflector 1
2 - 23 0611-0024-01A Xenon Tube 1
2 - 24 7309-0253-01A XE Tube Band 1
2 - 25 7211-0548-03A Dial Holder 1
2 - 26 9008-0386-01A SUB PCB Ass'y 1
2 - 27 7211-0464-01A LCD Frame 1
2 - 28 3715-0025-01A Zebra 1
2 - 29 0704-0048-01A TN LCD 1
2 - 30 7011-0331-01A LCD Holder 1
2 - 31 9001-0764-01A TFT LCD Ass'y 1
2 - 32 9001-0765-01A FD Contact Ring Ass'y 1
2 - 33 9008-0374-01A PR F PCB Ass'y 1
2 - 34 9008-0349-01A Jack PCB Ass'y 1
2 - 35 4301-0017-01A Button Cell Battery 1
2 - 36 6001-0160-01A Screw 2
2 - 37 9008-0358-01A Main PCB Ass'y(SMD) 1
2 - 38 7409-1060-01A Key Tape 1
2 - 39 0950-2169-01A Bond Tape-E 1
2 - 40 3717-0014-01A Harness Connector 1
2 - 41 2904-0005-01A OLPF 1
2 - 42 7309-0319-01A OLPF Cusshion 1
2 - 43 7409-1057-01A Dial Ring Sheet 1
2 - 44 7012-0638-01A Punt Washer (t=0.1) 1
7012-0639-01A Punt Washer (t=0.15) 1
7012-0640-01A Punt Washer (t=0.2) 1
37
3-2
3-13
3-11
3-15
3-3
3-4
3-5
3-14 3-6
3-1
3-8
3-16
3-12
3-17 3-7
3-9
3-10
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
3-1 7217-1849-05A Back Cover 1
3-2 7217-1850-05A CF Card Door 1
3-3 7411-0760-02A CF Door Hinge 1
3-4 7217-2016-01A Zoom Button 2
3-5 7308-0035-01A Zoom Rubber Button 1
3-6 7308-0062-01A Power Button 1
3-7 7308-0070-01A Monitor Button 1
3-8 7308-0067-01A 4Way Button 1
3-9 9008-0365-01A Key F PCB Ass'y 1
3 - 10 9761-1730-07 Screw 4
3 - 11 7409-1041-02A Monitor Tape 1
3 - 12 7409-1023-01A Monitor Shield 1
3 - 13 9008-1387-01A Back Cover Ass'y 1
3 - 14 7409-1066-01A Key Tape 1
3 - 15 0960-2139-01A Bond Tape 1
3 - 16 9761-1735-07 Screw 3
3 - 17 7409-1080-01A Key Sheet 1
38
4-4
4-11
4-3
4-10
4-2
4-10
4-5
4-10
4-12
4-6
4-1
4-9
4-7
4-8
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
4-1 7217-1858-04A Top Cover 1
4-2 7217-1915-02A Mode Dial 1
4-3 6107-0343-01A Release S/P 1
4-4 7217-1914-02A Release Button 1
4-5 7017-0134-01A Front Dial Click 1
4-6 9761-1725-07 Screw 2
4-7 7217-1848-04A Select Button 1
4-8 6003-0295-01A Screw 1
4-9 7217-1846-03A Fresnel Lens 1
4 - 10 0958-9050-01A Front Tape-B 3
4 - 11 9007-1388-01A Top Cover Ass'y 1
4 - 12 7409-1065-02A Mode Dial Sheet 1
39
5-31
5-42 5-39
5-34
5-28
5-42
5-21
5-1 5-30
5-31
5-29
5-33
5-27
5-32 5-43
5-31
5-26
5-2
5-25 5-39
5-8 5-39
5-46 5-6
5-9
5-10
5-39 5-4
5-22 5-3
5-39
5-13 5-11
5-5
5-39
5-14
5-41 5-23
5-15
5-12
5-39
5-38
5-19
5-17
5-47 5-39
5-36
5-18
5-7
5-37
5-45
5-20
5-40
5-35
5-16 5-37
5-44
5-24
40
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
5-1 9002-0811-01A Barrel Ass'y 1
5-2 7212-1229-02B Guide Barrel 1
5-3 9002-0815-01A 2'nd Barrel Ass'y 1
5-4 9002-0816-01A 2'nd Lens Ass'y 1
5-5 7012-0598-02A Balnce Spring 1
5-6 0980-9002-01A Screw 2
5-7 7411-0747-04A Roller Shaft 3
5-8 7012-0576-01A Encorder Contact 1
5-9 9005-0135-01A Shutter Ass'y 1
5 - 10 9005-0133-01A AE Meter Ass'y-A 1
5 - 11 9005-0134-01A AE Meter Ass'y-B 1
5 - 12 7015-0078-01A Sector 1
5 - 13 7015-0077-01A Aperture 1
5 - 14 7015-0076-01B Shutter Cover 1
5 - 15 7212-1233-03A Focus Holder 1
5 - 16 7409-1076-01A Guide Shield 1
5 - 17 9002-0813-01A Focus Lens Ass'y 1
5 - 18 7212-1235-04A Focus Clip 1
5 - 19 7411-0748-02A Focus Guide Pin-A 1
5 - 20 7411-0749-02A Focus Guide Pin-B 1
5 - 21 7012-0603-01A FPCB Guide Plate 1
5 - 22 7215-0572-03A Shutter Base 1
5 - 23 9008-0350-01A AF F PCB Ass'y 1
5 - 24 7212-1230-03A Zoom Cover 1
5 - 25 9002-0868-01A Cam Barrel Ass'y 1
5 - 26 7012-0601-04A Cam Plate Spring 1
5 - 27 9002-0817-01A 3rd Barrel Ass'y 1
5 - 28 7212-1238-01A Zoom Idle Gear-A 1
5 - 29 7212-1239-02A Zoom Idle Gear-B 1
5 - 30 9002-0819-01A Zoom Gear Plate Ass'y 1
5 - 31 9762-1750-07 Screw 5
5 - 32 7411-0754-01A Idle Gear Shaft 1
5 - 33 9002-0820-01A Zoom Motor Ass'y 1
5 - 34 7012-0635-01A Shutter F PCB Plate 1
5 - 35 7212-1236-04A Focus Ring 1
5 - 36 9002-0812-01A 1st Barrel Ass'y 1
5 - 37 9761-1745-07 Screw 3
5 - 38 9611-1420-07 Screw 2
5 - 39 6003-0274-01A Mecha Screw 12
5 - 40 7411-0778-01A Guide Ring AL 2
5 - 41 4101-0203-02A Shutter F PCB 1
5 - 42 0950-9001-01A Screw 2
5 - 43 4102-0041-01A Encoder F PCB 1
5 - 44 9761-1725-07 Screw 3
5 - 45 7411-0765-01A Roller 3
5 - 46 7411-0777-01A Roller-D 3
5 - 47 7411-0767-01A Clip Pin 1
41
6-4
6-12
6-14
6-3
6-6
6-13
6-15
6-1
6-5
6-7
6-16
6-11
6-2
6-8 6-10
6-9
42
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
6-1 7213-0209-04A Finder Base 1
6 -2 6722-0031-02A OB Lens 1
6 -3 6726-0006-01A Prism 1
6 -4 7213-0171-02A Finder Cover 1
6 -5 7013-0107-02A Finder Mask 1
6 -6 7213-0153-01A Prism-B 1
6 -7 7213-0246-03A E/P Holder B 1
6 -8 7411-0703-01A Finder Shaft 1
6 -9 6107-0435-01A Finder Spring 1
6 - 10 9003-0151-01A VA Lens Ass'y 1
6 - 11 6721-0052-02A CO Lens 1
6 - 12 9003-0147-01A EP Holder-A Ass'y 1
6 - 13 7213-0245-01A E/P Holder A 1
6 - 14 6721-0054-02A E/P Lens A 1
6 - 15 6722-0032-02A E/P Lens B 1
6 - 16 9003-0146-01A Finder Ass'y 1
43
7-3
7-1
7-2
7-4
7-5 7-6
7-7
7-8
7-9
7-10
7-11
7-12
7-14
7-13
SAMSUNG CAMERA
User Manual
Digital Camera
Digimax 210SE
CAMERA
Digimax 210SE
Application S/W Driver CD-ROM
www.samsungcamera.com
www.zoomin.co.kr
44
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
7-1 4301-0018-01A Alkaline Battery 4
7-2 1107-0006-01A CF Card (8MB) 1
7-3 3719-0013-01A AC Adaptor 1
7-4 3801-0003-01A AC Code Cable (USA) 1
3801-0004-01A AC Code Cable (Europ) 1
3801-0005-01A AC Code Cable (Korea) 1
3801-0006-01A AC Code Cable (Australia)) 1
7-5 3802-0005-01A RS-232C Cable 1
7-6 3802-0004-01A USB Cable 1
7-7 9010-0409-01A Video Cable Ass'y 1
7-8 3802-0007-01A Mac Cable 1
7-9 7409-1026-01A Strap_Lens Cap 1
7 - 10 7409-1053-01A Strap_Camera 1
7 - 11 6904-0185-01A Skin Case 1
7 - 12 6806-1084-01B Quick Guide 1 ENG
6806-1067-01C Mini User Manual 1 KOR
7 - 13 4609-0017-01C ENG/KOR Photo Delux TWAIN Driver 1
7 - 14 6806-0994-01B User Manual 1 ENG
6806-0993-01B User Manual 1 KOR
45
