Image preview - the first page of the document
>> Download SMU-CA3 documenatation <<
Text preview - extract from the document
2
3
4
5
6
7
3.2
UNG SHD LE
MS
SA
NS
Lithium-Ion SLB-1037
ZO
OM mm
5 .8-1 7.4
U-CA 3
Memory Stick Duo
8
9
10
This enables images to transfer between the camera and PC.
This camera uses the USB Storage Driver as the camera driver. You can use the camera as a USB
card reader.
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
1. MAIN ASSEMBLY
1-5
1-4
1-3
1-1
1-2
1-6
1-6
40
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
1-1 Q9007195501A FRONT COVER ASS'Y-KENOX UCA-3 1 SILVER
Q9007196101A FRONT COVER ASS'Y-DIGIMAX UCA-3 1 SILVER
Q9007196201A FRONT COVER ASS'Y-DIGIMAX UCA-3 1 WHITE
Q9007196301A FRONT COVER ASS'Y-KENOX UCA-3 1 WHITE
Q9007196401A FRONT COVER ASS'Y-DIGIMAX UCA-3 1 GRAY
Q9007196501A FRONT COVER ASS'Y-KENOX UCA-3 1 GRAY
1-2 Q7012076401B DECORATION RING 1
1-3 Q9007195601A BACK COVER ASS'Y 1 SILVER
Q9007196601A BACK COVER ASS'Y 1 WHITE
Q9007196701A BACK COVER ASS'Y 1 GRAY
1-4 Q6003040701A SCREW 1
1-5 Q7309039901A SCREW CAP 1
1-6 Q6003024201A SCREW 6
41
2-24 2-32
2-42
2-31 2-35
2-29 2-6
2-28 2-41 2-7
2-33 2-10
2-30
2. BODY ASSEMBLY
2-26
2-27 2-9
2-25 2-36 2-8
2-19 2-34
2-21
2-44
2-46
2-15 2-5
2-1
2-4
2-12 2-3
42
2-2
2-13 2-22
2-14 2-18
2-23
2-11 2-43
2-38
2-37
2-45
2-39
2-16
2-17
2-40 2-20
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
2-1 Q9002120101A UC1 BARREL ASS'Y 1
2-2 Q9003020001A FINDER ASS'Y 1
2-3 Q9761173507 SCREW 3
2-4 Q2904001401A OLPF 1
2-5 Q7309039401A OLPF CUSHION 1
2-6 Q9008064801A CCD FPCB ASS'Y 1
2-7 Q4102007401A CCD FPCB 1
2-8 Q0604002501A CCD SENSOR 1
2-9 Q7011044101A CCD PLATE 1
2-10 Q9761173507 SCREW 2
2-11 Q7211066201A BATTERY CHAMBER_A 1
2-12 Q7211066301A BATTERY CHAMBER_B 1
2-13 Q7217284601A BATTERY LOCK 1
2-14 Q7217284701A BATTERY LOCK SLIDER 1
2-15 Q7017037101A BATTERY PLATE 1
2-16 Q7017037201A BATTERY CONTACT_A 2
2-17 Q7017037301A BATTERY CONTACT_B 1
2-18 Q7017037401A BATTERY LOCK PLATE 1
2-19 Q7411092902A BATTERY HINGE_A 1
2-20 Q6107054601A BATTERY SPRING 1
2-21 Q6107054501A BATTERY HINGE SPRING 1
2-22 Q6107056001A BATTERY LOCK SPRING 2
2-23 Q0462911701A TAP TITE SCREW 1
2-24 Q9008065201A REFLECTOR ASS'Y 1
2-25 Q7211066401A FRESNEL LENS 1
2-26 Q7211066501A REFLECTOR HOLDER 1
2-27 Q7014004201A REFLECTOR 1
2-28 Q7309039701A TUBE RUBBER 2
2-29 Q7409148801A REFLECTOR SHIELD 1
2-30 Q0611003301A XE TUBE 1
2-31 Q4102007501A TRIG FPCB 1
2-32 Q2401007501A MAIN CONDENSOR 1
2-33 Q3708005501A MEMORY STICK DUO CONNECTOR 1
2-34 Q4101026901A USB EXT FPCB 1
2-35 Q4101027001A LCD EXT FPCB 1
2-36 Q9008065701A MAIN PCB SMD ASS'Y 1
2-37 Q9008065901A POWER PCB ASS'Y 1
2-38 Q0961900301A SCREW 1
2-39 Q9008065401A JACK PCB ASS'Y 1
2-40 Q0961900301A SCREW 1
2-41 Q4101026801A AUDIO FPCB 1
2-42 Q4719001801A SPEAKER 1
2-43 Q0902007801A MIC 1
2-44 Q0601004601A AF LED 1
2-45 Q7211028902A TRIPOD CONNECTOR 1
2-46 Q7217284503B BATTERY COVER 1 SILVER
Q7217294501A BATTERY COVER 1 WHITE
Q7217294601A BATTERY COVER 1 GRAY
43
3. BARREL ASSEMBLY
3-25 3-24
3-1
3-20 3-38
3-28
3-22
3- 23
3-19
3-11 3-18
3-12 3-15
3-17
3-26 3-27 3-16
3-13
3-55
3-22
3-2 3-5
3-6 3-8
3-37
3-7
3-35 3-14
3-36
3-3
3-34
3-30
3-10
3-54
3-58
3-31 3-4
3-53
3-32 3-29
3-33 3-21
3-9 3-52
3-51
3-40
3-39
3-46
3-41
3-47
3-45 3-48
3-44
3-56 3-50
3-42
3-49
3-57
44
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
3-1 Q9002120001A LENS BASE ASS'Y 1
3-2 Q7212172505A LENS BASE 1
3-3 Q7411097601A AF GUIDER BAR_A 1
3-4 Q7411097701A AF GUIDER BAR_B 1
3-5 Q7411085902A ZOOM GEAR_A SHAFT 1
3-6 Q7411097801A ZOOM GEAR_B SHAFT 4
3-7 Q7411090001B ZOOM GEAR_C SHAFT 2
3-8 Q7411097901B ZOOM GEAR_D SHAFT 1
3-9 Q3107001701A ZOOM MOTOR 1
3-10 Q9611142007 SCREW 2
3-11 Q7212160001B ZOOM MOTOR GEAR 1
3-12 Q7212160101A ZOOM GEAR_A 1
3-13 Q7411085802A ZOOM GEAR_D 1
3-14 Q7411085702A ZOOM GEAR_C 1
3-15 Q7411085601B ZOOM GEAR_B 1
3-16 Q7212160602B ZOOM GEAR_E 2
3-17 Q7212172701A ZOOM GEAR_H 3
3-18 Q7212173801A ZOOM GEAR_G 1
3-19 Q7212172601A ZOOM COVER 1
3-20 Q7012075903A ZOOM COVER_B 1
3-21 Q9761142507 SCREW 1
3-22 Q0961900301A SCREW 2
3-23 Q9008062101A MAIN FPCB ASS'Y 1
3-24 Q4101025801A MAIN F PCB 1
3-25 Q9002104301A AF MOTOR ASS'Y 1
3-26 Q4101026701A ZOOM MOTOR FPCB 1
3-27 Q0608001001A PHOTO INTERRUPTER 2
3-28 Q0608000701A PHOTO REFLECTOR 1
3-29 Q7012076001A AF PI CAP 1
3-30 Q9002121701A 3rd LENS BARREL ASS'Y 1
3-31 Q9002119301A 3rd LENS ASS'Y 1
3-32 Q7012069406C AF LIMIT SPRING 1
3-33 Q6001014001A SCREW 1
3-34 Q6107048305A 3RD LENS BARREL SPRING 1
3-35 Q7212174303A AF GUIDE HOLDER 1
3-36 Q0961900101A SCREW 1
3-37 Q0994913101A SCREW 1
3-38 Q6003040401A SCREW 2
3-39 Q7212172103A GUIDE PLATE 1
3-40 Q9002119401A 2nd LENS BARREL ASS'Y 1
3-41 Q9002119101A 2nd LENS ASS'Y 1
3-42 Q9005017101A SHUTTER ASS'Y 1
3-43 Q0961900301A SCREW 2
3-44 Q7409137303C SHUTTER SHIELD 1
3-45 Q7411085305A 2ND MOVE PIN 3
3-46 Q7012075703A F_PCB GUIDER 1
3-47 Q7212172003A ZOOM RING 1
3-48 Q7212171702A SLIP RING 1
3-49 Q7012075502A 1ST PUSH PLATE 1
3-50 Q7411097502A 1st MOVE PIN 3
3-51 Q7212172201A CAM BARREL 1
3-52 Q7012075802A FINDER HOLDER 1
3-53 Q9002119501A OUTER GUIDE BARREL ASS'Y 1
3-54 Q7212172303A OUTER CAM BARREL 1
3-55 Q9761173007 SCREW 5
3-56 Q9002119001A 1st LENS ASS'Y 1
3-57 Q7409138001A FRONT SHIELD 1
3-58 Q7012069301A AF CLIP 1
45
4. FRONT COVER ASSEMBLY
4-6
4-3
4-7
4-9
4-8
4-1 4-16
4-17
4-13
4-14
4-4 4-5
4-2
4-10
4-15
4-18
4-12
4-11
4-19
46
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
4-1 Q9007195501A FRONT COVER ASS'Y-KENOX UCA-3 1 SILVER
4-1 Q9007196101A FRONT COVER ASS'Y-DIGIMAX UCA-3 1 SILVER
Q9007196201A FRONT COVER ASS'Y-DIGIMAX UCA-3 1 WHITE
Q9007196301A FRONT COVER ASS'Y-KENOX UCA-3 1 WHITE
Q9007196401A FRONT COVER ASS'Y-DIGIMAX UCA-3 1 GRAY
Q9007196501A FRONT COVER ASS'Y-KENOX UCA-3 1 GRAY
4-2 Q7217284802A FRONT COVER-DIGIMAX UCA-3 1
Q7217294701A FRONT COVER-KENOX UCA-3 1 SILVER
Q7217294801A FRONT COVER-DIGIMAX UCA-3 1 WHITE
Q7217294901A FRONT COVER-KENOX UCA-3 1 WHITE
Q7217295001A FRONT COVER-DIGIMAX UCA-3 1 GRAY
Q7217295101A FRONT COVER-KENOX UCA-3 1 GRAY
4-3 Q7217284901A FINDER WINDOW 1
4-4 Q7217285001A SELF LED WINDOW 1
4-5 Q7217285101A FRONT LED WINDOW 1
4-6 Q7217285201A RELEASE BUTTON 1
4-7 Q7217285301A MODE SLIDE BUTTON 1 SILVER
Q7217295201A MODE SLIDE BUTTON WHITE
Q7217295301A MODE SLIDE BUTTON GRAY
4-8 Q7217285401A MODE SLIDE PLATE 1
4-9 Q7217286201A POWER BUTTON 1 SILVER
Q7217296001A POWER BUTTON WHITE
Q7217296101A POWER BUTTON GRAY
4-10 Q7017037501A STRAP LINK PLATE 1
4-11 Q7409142801A FRONT AL TAPE 1
4-12 Q7409147501A FRONT AL TAPE 2 1
4-13 Q7409145101A RELEASE WASHER 1
4-14 Q7409111601A RELEASE WASHER 1
4-15 Q7411100201A STRAP LINK 1
4-16 Q6107054301A RELEASE SPRING 2
4-17 Q6107054401A POWER SPRING 1
4-18 Q7017037701C LOGO PLATE 1
Q7017038101A LOGO PLATE 1
4-19 Q7117006703A AL FRONT COVER 1
Q7117006901A AL FRONT COVER 1
47
5. BACK COVER ASSEMBLY
5-7
5-1
5-18 5-17
5-5
5-15 5-6
5-16 5-2
5-11
5-3 5-12
9
5-19
5-10
5-14
5-13
5-4
5-16
5-8
5-16 5-9
48
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
5-1 Q9007195601A BACK COVER ASS'Y 1 SILVER
Q9007196601A BACK COVER ASS'Y 1 WHITE
Q9007196701A BACK COVER ASS'Y 1 GRAY
5-2 Q7217285505A BACK COVER 1 SILVER
Q7217295401A BACK COVER 1 WHITE
Q7217295501A BACK COVER 1 GRAY
5-3 Q9007192401A NAVI BUTTON ASS'Y 1
5-4 Q7217285804A 3 FUNCTION BUTTON 1 SILVER
Q7217295601A 3 FUNCTION BUTTON 1 WHITE
Q7217295701A 3 FUNCTION BUTTON 1 GRAY
5-5 Q7217285903A ZOOM BUTTON 1
5-6 Q7217286001A BACK LED WINDOW 1
5-7 Q7217286102A JACK DOOR 1 SILVER
Q7217295801A JACK DOOR 1 WHITE
Q7217295901A JACK DOOR 1 GRAY
5-8 Q0704009501A TFT LCD 1
5-9 Q7017037601A LCD FRAME 1
5-10 Q7409143401A METAL DOME SWITCH 1
5-11 Q7409142901A BACK AL TAPE 1 1
5-12 Q7409147701A BACK AL TAPE 2 2
5-13 Q7409143001A LCD SPONGE 1
5-14 Q9008065001A LCD PCB ASSY 1
5-15 Q7217286301A INNER ZOOM BUTTON 1
5-16 Q6003027501A SCREW 10
5-17 Q7117006801A AL BACK COVER 1
5-18 Q9007197201A BACK COVER SUB ASS'Y 1 SILVER
Q9007197301A BACK COVER SUB ASS'Y 1 WHITE
Q9007197401A BACK COVER SUB ASS'Y 1 GRAY
5-19 Q7409147501A FRONT AL TAPE 2 1
49
6. BARRIER AND FINDER ASSEMBLY
6-1
6-8
6-2 6-3
6-4 6-5
6-6
6-7
6-4
6-22
6-9
6-21
6-18
6-20
6-19
6-17
6-10
6-16
6-14
6-11 6-15
6-13
6-12
50
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
6-1 Q9002119801A BARRIER ASS'Y 1
6-2 Q7212172804A FRONT PANEL 1
6-3 Q6107052903A BARRIER CLOSE SPRING 2
6-4 Q7212172902A BARRIER_A 2
6-5 Q7012076303A BARRIER BASE 1
6-6 Q9002119901A BARRIER LEVER PIN ASS'Y 1
6-7 Q6107052802A BARRIER OPEN SPRING 1
6-8 Q7409136301A FRONT PANEL TAPE 2
6-9 Q9003020001A FINDER ASS'Y 1
6-10 Q7213033505A FINDER BASE 1
6-11 Q7411098201A FINDER SHAFT_A 1
6-12 Q6721007803A CO LENS 1
6-13 Q7411098301A FINDER SHAFT_B 1
6-14 Q6107053002A FINDER SPRING 1
6-15 Q6721007903A VA LENS 1
6-16 Q7013015101A VA MASK 1
6-17 Q6726002202A PRISM_A 1
6-18 Q7013015002A FINDER MASK 1
6-19 Q6721008001A EP LENS 1
6-20 Q6726002301A PRISM_B 1
6-21 Q7013014903B FINDER COVER 1
6-22 Q7409149701A FRONT TAPE 2
51
7-15 7-16 7-17 7-18 7-19
7-9 7-10 7-11
7-12
7-14
7-13
7-1
7-3
7-4
7-20 7-7
7-6
7-5
7-8
7-2
52
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
7-1 QP960210101A PE BAG (FOR CAMERA) 1
7-2 Q6909011601A PE BAG (FOR ACCESSORY) 1
7-3 Q6901182601A INNER PAD_UCA 3_EXP 1
Q6901182701A INNER PAD_ KENOX UCA 3_KOR 1
7-4 Q6904025101A POUCH_UCA 3_KOR/EXP 1
7-5 Q6806165601A Q/GUIDE_KENOX UCA 3_KOR 1
Q6806165701A Q/GUIDE_ UCA 3_ENG 1
Q6806165801A Q/GUIDE_ UCA 3_GER 1
Q6806165901A Q/GUIDE_ UCA 3_FRA 1
Q6806166001A Q/GUIDE_ UCA 3_SPA 1
Q6806166101A Q/GUIDE_ UCA 3_ITA 1
Q6806166201A Q/GUIDE_ UCA 3_CHI (T) 1
Q6806166301A Q/GUIDE_ UCA 3_DUT 1
Q6806166401A Q/GUIDE_ UCA 3_POR 1
Q6806166501A Q/GUIDE_ UCA 3_SWE 1
Q6806166601A Q/GUIDE_ UCA 3_DEN 1
Q6806166701A Q/GUIDE_ UCA 3_FIN 1
Q6806166801A Q/GUIDE_ UCA 3_RUS 1
Q6806166901A Q/GUIDE_ UCA 3_CHI (S) 1
7-6 Q6806167001A U/MANUAL_KENOX UCA 3_KOR 1
Q6806167101A U/MANUAL_Digimax UCA 3_ENG 1
Q6806167201A U/MANUAL_Digimax UCA 3_GER 1
Q6806167301A U/MANUAL_Digimax UCA 3_FRA 1
Q6806167401A U/MANUAL_Digimax UCA 3_SPA 1
Q6806167501A U/MANUAL_Digimax UCA 3_ITA 1
Q6806167601A U/MANUAL_Digimax UCA 3_CHI (T) 1
Q6806167701A U/MANUAL_Digimax UCA 3_DUT 1
Q6806167801A U/MANUAL_Digimax UCA 3_POR 1
Q6806167901A U/MANUAL_Digimax UCA 3_SWE 1
Q6806168001A U/MANUAL_Digimax UCA 3_DEN 1
Q6806168101A U/MANUAL_Digimax UCA 3_FIN 1
Q6806168201A U/MANUAL_Digimax UCA 3_RUS 1
Q6806168301A U/MANUAL_Digimax UCA 3_CHI (S) 1
Q6806168501A POWER PACK MANUAL_KOR 1
Q6806168601A POWER PACK MANUAL_ENG 1
Q6806168701A POWER PACK MANUAL_E/F/G/S/P/CHI (T) 1
7-7 Q6807002601E WARRANTY CARD_KOREA 1
Q6807003003R WARRANTY CARD_EXP 1
Q6807003802D WARRANTY CARD_UK 1
Q6807010902B WARRANTY CARD_RUS (3 YEARS) 1
Q6807011301A WARRANTY CARD_TSOE (CHINA) 1
Q6807009502D CARD PRODUCK (Mexico) 1
53
Fig.No. Parts No. Parts Name Q'ty Remarks
7-8 Q6901181201A G/T BOX_KENOX UCA 3_KOR 1
Q6901182801A G/T BOX_Digimax UCA 3_EXP/AUS/USA/CAN 1
Q6901183001A G/T BOX_Digimax UCA 3+POWER PACK 1
7-9 Q4302000201A LITHIUM-ION SLB-1037 (SDI) 1
7-10 Q4301002601A DURACELL LITHIUM BATTERY CP1 1
7-11 Q4309001101A LI-ON CHARGER SBC-1037 1
7-12 Q3801002701A CAR CHARGE CABLE-DV4 1
7-13 Q3719002301A AC ADAPTOR D360/D420_KOR/EXP 1
7-14 Q3801003001A AC CODE CABLE_KOR-D1 1
Q3801003201A AC CODE CABLE_EXP-D1 1
Q3801003101A AC CODE CABLE_USA-D1 1
Q3801003301A AC CODE CABLE_UK-D1 1
Q3801003401A AC CODE CABLE_AUS-D1 1
7-15 Q7409145001A STRAP DIGIMAX UCA 3_KOR/EXP 1
7-16 Q3802002001A USB CABLE_V4/V3 1
7-17 Q3802001901A A/V CABLE_V4/V3 1
7-18 Q4602000901A MEMORY STICK DUO CARD (32MB) 1
7-19 Q4602001001A MEMORY STICK DUO ADAPTOR 1
7-20 Q4609005301A DRIVER+MGI (E/F/G/S/I/DUT/P)+QUICK TIME 1
Q4609005401A DRIVER+MGI (E/JPN/T.C/S.C/K)+QUICK TIME 1
Q4609004701A ADOBE PHOTOSHOP ELEMENT_KENOX D1_KOR 1
Q4609005701A AVATAR CD UCA 3 KOR/EXP 1
Q4609006201A AVATAR CD UCA 3 ENG/THAI 1
PA G E PARTS NO. PARTS NAME SPEC SYMBOL
88 Q0601005101A 7COLOR LED SSC-HBTGFR421 "D10, D14"
88 Q3601000701A CHIP FUSE FHC16-322 FP1
88 Q0501011001A CHIP TRANSISTOR IMD10A(SMT6) "U1, U2"
88 Q2802001201A CRYSTAL 27MHz(FCX-04) Y1
88 Q2802001101A CRYSTAL 48MHz(FCX-04) Y2
88 Q2802001001A CRYSTAL 48.6MHz(FCX-03) Y3
78 Q3722002201A DC JACK LGP2231-0100 J3
88 Q0505001801A FETTKY NTHD4N02 "Q2,4,6"
88 Q1407000901A IGBT GT08G131 Q305
74 Q3403000301A RELEASE SWITCH EVQPRBA09 S402
54
PA G E PARTS NO. PARTS NAME SPEC SYMBOL
88 Q0902007401A RTC S-3530A U10
74 Q3409001801A SLIDE SWITCH SSQ-132MHT SW401
74 Q3409001901A TACT SWITCH SOT-152HST S401
88 Q2601001401A TRANSFORMER 6CA2(838CN-1726=P3) T1_LCD
88 Q2601001301A TRANSFORMER 6CA1(#838CN-1740) T2_LCD
88 Q2601001501A TRANSFORMER W03-073 T3
88 Q2704001901A TRIG COIL W03-031 T4
46 Q9002120101A Barrel Ass'y
52 Q9003020001A Finder Ass'y
50 Q9007192401A Navi button Ass'y
48 Q9007195501A Front Cover Ass'y Kenox Silver
50 Q9007195601A Back Cover Ass'y Silver
48 Q9007196101A Front Cover Ass'y Digimax Silver
48 Q9007196201A Front Cover Ass'y Digimax White
48 Q9007196301A Front Cover Ass'y Kenox White
46 Q9007196401A Front Cover Ass'y Digimax Gray
48 Q9007196501A Front Cover Ass'y Kenox Grey
50 Q9007196601A Back Cover Ass'y White
50 Q9007196701A Back Cover Ass'y Gray
50 Q9007197201A Back Cover sub ass'y Silver
50 Q9007197301A Back Cover sub ass'y White
50 Q9007197401A Back Cover sub ass'y Gray
44 Q9008064801A CCD F-PCB Ass'y
50 Q9008065001A LCD PCB Ass'y
44 Q9005065201A Reflector Ass'y
44 Q9005065101A Main PCB Ass'y
44 Q9008065401A JACK PCB ASS'Y
44 Q9008065801A Audio F-PCB Ass'y
44 Q9008065901A Power PCb Ass'y
44 Q7217284503B BATTERY COVER
54 Q4609005701A AVATAR_CD_UCA 3_KOR/EXP
54 Q4609005301A DRIVER+MGI(E/F/G/S/I/DUT/P)
54 Q4609005401A DRIVER+MGI(E/JPN/T.C/S.C/K)
50 Q0704009501A TFT LCD
54 Q6806167001A USER MANUAL(KOR)
54 Q6806167101A USER MANUAL(ENG)
52 Q9002119801A BARRIER ASS'Y
55
56
3.2
UNG SHD LE
MS N
SA
S
ZO m
OM
5 .8-1 7.4 m
U-CA 3
Connecter
CPU UPGRADE CAMERA
D1 I/F MODULE
Serial cale
USB
SAMSUNG
TECHWIN
RS232C
Interface box
USB cable
57
R167 C139
C85
Q2 R114
R116
C84
R164 C129
R162
TP3
FB1
C2 C128 TP2
28
27
C27 C3 R142
R68 R69 R70 R94 R71 C31 C32 C33 R35 JP1
C28 R140 R138 Y1
10
11
12
13
14
15
16
17
18
19
1
2
3
4
5
6
7
8
9
C29 R141 R136 1
R34
A
FLASH MEMORY
B
C21
C
R30
R146
R150
C37
D
R137
E
R24
C22
R201
F
C39
G
R145
R149
C26
U7
R36
H
C38
R200
J
DSP
R144
R148
R139
K
U3
SDRAM
R37
L
C40
M U8 C117
R50
R41
R147
N R49
58
P C116
R11 R12 R82 R86 R R51
R39
R48
R143
R13 R14 R81 R88 T R52
R47
R15 R16 R85 U C115
R46
R17 R18 R87 R53
C23
V
W R45
R75 E1 10 R54
C114
C109 R44 R55
R80 R89 R67 C44 C52 C34 R64 C25 R56
R163
R43
R63
R60
R31 R90 C45 R66 Q1 R76 C35 R58
FB6
R42
C130 R165 R65 C48 C113
R84
R32
R78 FB4
U1
L2
54
Y2
C20
1
C50
1) MAIN PCB Assembly
VIDEO OUT
R108
C131 R79 R1 C1 R2
R117 C111 C108
C51 FB17
a) Parts Arrangement R73 U4 18 C107
C106
C47
R72
C49
R74
J2 C112
UC1
ALPHA (A)
03. 09. 16
FB12
C101
C95
C90
FB15
FB10
GND FB11 FB14 R113
C82
C83
C99 C93
2 80 C79
C91
C74
C16
L5
R172
N C71
J5 L9
M L7
L
C138
R168
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
