Image preview - the first page of the document
>> Download SMV50 documenatation <<
Text preview - extract from the document
2
3
Type 1/1.8 CCD
Image Sensor Effective Pixel Approx. 5.0 Mega-pixel
Total Pixel Approx. 5.3 Mega-pixel
Schneider Lens f = 7.7 ~ 23.1mm
Focal Length
(35mm film equivalent : 38 ~ 114mm)
Lens F No. F2.7 ~ F4.9
Still Image mode : 1.0X ~ 4.0X
Digital Zoom
Play mode : 1.0X ~ 10.0X (depends on image size)
Optical Viewfinder Real image optical viewfinder
Viewfinder
LCD Monitor 1.5 color TFT LCD
Type TTL auto focus, Manual focus
Focusing Normal : 80cm ~ infinity
Range
Macro : 30cm ~ 80cm, Super Macro : 6cm ~ 30cm(Wide only)
Type Mechanical and Electronic shutter
Shutter
Speed 1 ~ 1/2,000sec. (Manual, Night Mode : 16 ~ 1/2,000 sec.)
Program AE, Shutter Priority AE, Aperture Priority AE or Manual Exposure
Control
Metering : Multi, Spot
Exposure
Compensation 2EV (0.5EV steps)
ISO Equivalent Auto, 50, 100, 200, 400
Modes Auto, Auto & Red-eye reduction, Slow sync, Fill-in flash, Flash off
Flash Range Wide : 0.3 ~ 3.0m, Tele : 0.3 ~ 2.0m
Recharging Time Approx. 7 sec.
Sharpness Soft, Normal, Vivid
Effect Normal, B&W, Sepia, RGB
White Balance Auto, Daylight, Cloudy, Fluorescent H, Fluorescent L, Tungsten, Custom
Voice Recording (max. 1 hours)
Voice Recording
Voice Memo in Still Image (max. 10 sec.)
Date Imprinting Date, Date&Time, Off (user selectable)
Modes : Auto, Program, A,S,M, Night Scene, MySet, Scene
* Scene : Portrait, Children, Landscape, Close-up, Sunset, Dawn, Backlight,
Still Image Fireworks, Beach & Snow
Continuous : Single, Continuous
Shooting
Self-timer : 2 sec., 10 sec., Remocon
With Audio (recording time : memory capacity dependent)
Movie Clip Size : 640x480, 320x240
Frame rate : 30fps, 15fps
Media SD / MMC Card (up to 512MB guaranteed)
Still Image : TIFF, JPEG(DCF), EXIF 2.2, DPOF 1.1, PictBridge 1.0
File Format
Movie Clip : AVI(MJPEG) Voice : WAV
Storage
2560 : 2560x1920 2272 : 2272x1704
Image Size 2048 : 2048x1536 1600 : 1600x1200
1024 : 1024x768 640 : 640x480
4
2560: Super Fine 11, Fine 22, Normal 32 TIFF 2
2272: Super Fine 14, Fine 28, Normal 40 TIFF 2
2048: Super Fine 17, Fine 33, Normal 49 TIFF 3
Capacity 1600: Super Fine 28, Fine 53, Normal 75 TIFF 5
Storage
(32MB) 1024: Super Fine 64, Fine 106, Normal 139 TIFF 12
640: Super Fine 129, Fine 201, Normal 227 TIFF 27
* These figures are measured under Samsung's standard conditions and may
vary depending on shooting conditions and camera settings.
Type Single image, Thumbnails, Slide show, Movie Clip
Image Play
Editing Trimming, Resizing
Digital output connector : USB 1.1
Audio : Mono
Interface
Video output : NTSC, PAL (user selectable)
DC power input connector : 5.0V
Primary battery : 2xAA alkaline, Lithium, Ni-Mn, Ni-Zn/1xCR-V3
Rechargeable battery : 3.7V Li-ion (SLB-1437), 2xAA Ni-MH,
Power Source Ni-Cd/1xI-Pack(SBP-1303)
AC Adapter : SAC-51(DC 5.0V, 2.0A)
Included power source may vary depending on sales region.
Dimensions (WxHxD) 105.5 x 54.6 x 38mm
Weight 170g (without batteries and card)
Operating Temperature 0 ~ 40
Operating Humidity 5 ~ 85 %
Camera Storage Driver (Windows98/98SE/2000/ME/XP, Mac OS 9.0~10.2)
Software
DriverApplication Digimax Viewer, Adobe PhotoShop Elements
A World Unique 9 Different Power Sources
Special Features A World Superior Schneider Lens
VGA 30fps Movie Clip, AVI AVI capture on Play Mode
PC with processor better than MMX Pentium 233MHz (XP : Pentium II 300MHz)
Windows 98/98SE/2000/ME/XP
Minimum 32MB RAM (XP : 128MB)
For Windows
140MB of available hard-disk space, USB port, CD-ROM drive,
800 600 pixels, 16-bit colour display compatible monitor
(24-bit color display recommended)
Power Mac G3 or later
Mac OS 9.0 ~ 10.2
For Macintosh Minimum 64MB RAM
110MB of available hard-disk space, USB port, CD-ROM drive,
QuickTime 4.0 or later for Movie Clip
5
[ Image & Full Status ]
No. Description Icons
1 Battery
Recording mode
3 Camera shake warning
4 Flash
5 Self-timer
6 Voice memo
7 Macro
8 Metering
9 Manual focus
10 Sharpness
11 Auto focus frame
12 Date/ Time 2004/03/01 01:00 PM
13 Exposure compensation
14 White Balance
15 ISO
16 RGB
17 Image quality
18 Image size/ Continuous shot 2560, 2272, 2048, 1600, 1024, 640
Number of available shots remaining 28
Remaining time (Movie clip/ Voice recording) 00:01:30/01:00:00
20 Optical/ Digital Zoom rate
6
No. Description Icon
1 Battery
2 Play mode
3 File Type
4 Voice memo
5 Protect indicator
6 DPOF indicator
7 Stored image number 9
8 TIFF file
SIZE : 2560x1920 Size
SIZE : 2560X1920 AV : F2.7 Aperture value
AV : F2.7
TV : 1/30 Shutter speed
TV : 1/30
ISO : 50 ISO : 50 ISO sensitivity
FLASH : OFF FLASH : OFF Whether or not the
DATE : 2004/03/01 flash is used.
DATE : 2004/03/01 Recording date
7
5.0
V5
8
Power switch
Shutter button
Microphone
Flash light
amount sensor Viewfinder
Flash
Self-timer lamp
Strap eyelet
Remote control
sensor
Lens
Flash indicator lamp(Red) Mode dial lamp(Green)
Autofocus indicator lamp(Green) Mode dial
Zoom W button
Viewfinder (Thumbnail)
Zoom T button
(Digital zoom)
+&-/PLAY &
PAUSE button 5-function
button
MF / DELETE Speaker
button
LCD button
USB/ AV
connection
LCD monitor terminal
Tripod socket PLAY mode DC input connection point
button
9
Memory card slot
Battery chamber cover
Battery chamber
Voice memo/ UP button
FLASH/ LEFT SELF-TIMER/ RIGHT
button button
MENU/ OK button
MACRO / SUPER MACRO /
DOWN button
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
1. MAIN ASSEMBLY
1-14 1-6
1-2
1-11
1-5
1-1
1-8 1-10
1-3 1-4
1-13
1-12
1-9
1-7
34
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
1-1 Q9007209301A FRONT COVER ASS'Y-KENOX DIGIMAX V5 1
Q9007207201A FRONT COVER ASS'Y-DIGIMAX V5 1
Q9007211101A FRONT COVER ASS'Y-KENOX DIGIMAX V500 1
Q9007211001A FRONT COVER ASS'Y-DIGIMAX V5000 1
1-2 Q7217304702A L SIDE COVER 1 V5
Q7217314501A L SIDE COVER 1 V5000
1-3 Q7217304603A R SIDE COVER 1 V5
Q7217314401A R SIDE COVER 1 V5000
1-4 Q7217304802A SIDE DECO PLATE 1
1-5 Q7409159701A SIDE DECO PLATE TAPE 1
1-6 Q7217255901B EP WINDOW 1
1-7 Q7409158201A FCC LABEL_DIGIMAX V5 1
Q7409161401A FCC LABEL_DIGIMAX V5000 1
Q7409158301A MIC LABEL_KENOX V5 1
1-8 Q7012074102A DECORATION RING 1 V5
Q7012074901A DECORATION RING 1 V5000
1-9 Q6003037301A SCREW 3
1-10 Q6003024201A SCREW 2
1-11 Q6003038401A SCREW 4
1-12 Q6804056301A PRODUCT STICKER 1
1-13 Q7211028902A TRIPOD CONNECTOR 1
1-14 Q9007206901A BACK COVER ASSY 1 V5
Q9007211301A BACK COVER ASSY 1 V5000
35
2. BODY ASSEMBLY
2-24
2-53
2-44
2-23
2-6
2-22 2-9
2-21
2-5 2-2
2-14 2-38
2-13 2-16 2-23
2-50
2-11
2-8
2-10 2-7 2-48
2-18 2-51
2-4 2-49
2-1
2-12
2-19
2-52
2-23
2-20
2-24
2-17 2-28 2-15
2-27
2-43 2-3
2-35
2-25 2-31
2-24 2-36
2-34
2-46
2-33
2-25 2-37 2-47
2-24
2-41
2-24 2-45
2-39
2-42
2-40
2-30 2-26 2-29
36
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
2-1 Q7211064605A BODY 1
2-2 Q6804044802A BATTERY LABEL 1
2-3 Q7409137101A PCB TAPE-B 1
2-4 Q7409136601A PLAY TAPE 2
2-5 Q7217253502A BATTERY COVER 1 V5
Q7217275501A BATTERY COVER 1 V5000
2-6 Q7217253601A BATTERY COVER STOPPER 1
2-7 Q7217253704A BATTERY COVER LOCK 1
2-8 Q6107050901A BATTERY HINGE SPRING 1
2-9 Q7011041002A BODY COVER 1
2-10 Q7011041602A BATTERY PLATE 1
2-11 Q7011041702A BATTERY SUB CONTACT 1
2-12 Q7011041802B BATTERY PLATE GUIDER 1
2-13 Q7011042003B BATTERY LOCK PLATE 1
2-14 Q7011042101A BATTERY LOCK HOLDER 1
2-15 Q7011043404A BATTERY CONTACT 2
2-16 Q7309037402A MIC CAP 1
2-17 Q7411092902A BATTERY HINGE_A 1
2-18 Q7411095002A BATTERY HINGE_B 1
2-19 Q7411093002A STRAP LINK 1
2-20 Q7017036201A E-RING 1
2-21 Q7409134201A PCB TAPE_A 1
2-22 Q9761173007 SCREW 1
2-23 Q0961900101A SCREW 5
2-24 Q6003000101A SCREW A 9
2-25 Q7011041401A XE TUBE CONTACT 2
2-26 Q7409106001A AF FPCB TAPE 1
2-27 Q4103010801A CON_SUB PCB 1
2-28 Q0902007301A MAIN CONDENSOR 1
2-29 Q9008057201A REFLECTOR PHOTO ASSY 1
2-30 Q7211064702A FRESNEL LENS 1
2-31 Q7211064803B REFLECTOR HOLDER 1
2-32 Q7211064903A AF PHOTO HOLDER 1
2-33 Q7014004101A REFLECTOR 1
2-34 Q7011041501A TRIG CONTACT 1
2-35 Q4102005501A TRIG FPCB 1
2-36 Q4101025401A PHOTO FPCB 1
2-37 Q7409106001A AF FPCB TAPE 1
2-38 Q0902007601A MIC 1
2-39 Q0611003101A XE-TUBE 1
2-40 Q0601004801A AF LED 1
2-41 Q2704001401A TRIGGER COIL 1
2-42 Q0509000601A PHOTO TR 1
2-43 Q9008070301A POWER PCB ASS'Y 1
2-44 Q9008070501A MAIN PCB ASSY 1
2-45 Q9761174507 SCREW 1
2-46 Q9761173507 SCREW 1
2-47 Q7011041103A BODY FRAME_A 1
2-48 Q7309042102A OLPF CUSHION 1
2-49 Q2904001801A OLPF-D2(5M) 1
2-50 Q0961900301A SCREW 2
2-51 Q9008070101A CCD PCB ASSY 1
2-52 Q9002113301A BARREL ASSY 1 V5
Q9002128301A BARREL ASSY 1 V5000
2-53 Q4104019401A MAIN CU FPCB 1
37
3. BARREL ASSEMBLY
3-11 3-3
3-13
3-14 3-27
3-22
3-1 3-15
3-23
3-19
3-20
3-5 3-28
3-21
3-4
3-17
3-3
3-9
3-25 3-10
3-26
3-16
3-12 3-18
3-7
3-24 3-30
3-8
3-6 3-34 3-32
3-42 3-26
3-31
3-35 3-33
3-29
3-36
3-2
3-39
3-37 3-40
3-38
3-41
38
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
3-1 Q9002113201A LENS BASE ASSY 1
3-2 Q9002109201A 1st LENS ASSY 1
3-3 Q0961900301A SCREW 4
3-4 Q0994913101A SCREW 1
3-5 Q3107001701A ZOOM MOTOR 1
3-6 Q6003018501A MACHINE SCREW 1
3-7 Q6003019201A SCREW 2
3-8 Q6031005801A MOTOR WASHER 1
3-9 Q6107048305A 3RD LENS BARREL SPRING 1
3-10 Q7212159803A ZOOM COVER 1
3-11 Q7212159904A AF HOLDER 1
3-12 Q7212160001B ZOOM MOTOR GEAR 1
3-13 Q7212160101A ZOOM GEAR_A 1
3-14 Q7212160602B ZOOM GEAR_E 2
3-15 Q7212166006A LENS BASE 1
3-16 Q7411085401A AF GUIDER BAR_A 1
3-17 Q7411085501A AF GUIDER BAR_B 1
3-18 Q7411085601B ZOOM GEAR_B 1
3-19 Q7411085702A ZOOM GEAR_C 1
3-20 Q7411085802A ZOOM GEAR_D 1
3-21 Q7411085902A ZOOM GEAR_A SHAFT 1
3-22 Q7411090001B ZOOM GEAR_C SHAFT 2
3-23 Q9002109401A 3rd LENS ASSY 1
3-24 Q7012069406C AF LIMIT SPRING 1
3-25 Q6001014001A SCREW 1
3-26 Q9008055501A MAIN FPCB ASSY 1
3-27 Q9611142007 SCREW 2
3-28 Q7212159302A GUIDE PLATE 1
3-29 Q9002109301A 2ND LENS ASS'Y 1
3-30 Q9005016301A SHUTTER ASS'Y 1
3-31 Q9761142507 SCREW 3
3-32 Q7409123201A SHUTTER PROTECT SHEET 1
3-33 Q7411085305A 2ND MOVE PIN 3
3-34 Q7012069202A F PCB GUIDER 1
3-35 Q7212171301A ZOOM RING 1 V5
Q7212171101A ZOOM RING 1 V5000
3-36 Q7212158903A 1ST GUIDE BARREL 1
3-37 Q7012069004B 1ST PUSH PLATE 1
3-38 Q7212171201A CAM BARREL 1 V5
Q7212171001A CAM BARREL 1 V5000
3-39 Q7212159503A OUTER CAM BARREL 1
3-40 Q9002113101A OUTER GUIDE BARREL ASS'Y 1
3-41 Q90021126001A BARREL SUB ASS'Y 1 V5
BARREL SUB ASS'Y 1 V5000
39
4. BARRIER ASSEMBLY
4-1
4-8
4-4
4-3
4-2
4-12
4-11
4-7
4-6
4-2
4-3 4-5
4-9
4-10
40
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
4-1 Q9002113901A BARRIER ASS'Y 1
4-2 Q6107051702A NEW CLOSE SPRING 2
4-3 Q7212160403B BARRIER-C 2
4-4 Q7212167804A NEW BARRIER-A 1
4-5 Q7212167902A NEW BARRIER-B 1
4-6 Q7012073502A NEW BARRIER BASE 1
4-7 Q7012073403A NEW LEVER-B 1
4-8 Q6107051802A NEW OPEN SPRING 1
4-9 Q7012073301A NEW LEVER-A 1
4-10 Q7411095501A NEW LEVER PIN 1
4-11 Q7409120802B FRONT PANEL TAPE 1
4-12 Q7212167704A NEW FRONT PANEL 1
41
5. FINDER ASSEMBLY
5-7
5-15
5-15 5-6
5-11
5-9 5-13
5-12
5-14
5-1
5-2
5-10
5-4
5-8
5-1
5-3
5-5
5-2
42
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
5-1 Q7213031706A FINDER BASE 1
5-2 Q7411086201A FINDER SHAFT 2
5-3 Q6721007403A CO LENS 1
5-4 Q9003018401A VA LENS ASS'Y 1
5-5 Q6107048501A FINDER SPRING 1
5-6 Q6726002002A PRISM-A 1
5-7 Q7213031903A FINDER COVER 1
5-8 Q9003018501A OB LENS ASS'Y 1
5-9 Q6001010601A SCREW 1
5-10 Q7013014201A FINDER MASK 1
5-11 Q7213031806A EP HOLDER 1
5-12 Q6031005903A EP WASHER 1 1
Q6031006003A EP WASHER 2 1
Q6031006103A EP WASHER 3 1
5-13 Q6721007503A EP LENS 1
5-14 Q6726002101A PRISM-B 1
5-15 Q9003019801A FINDER ASS'Y 1
43
6. FRONT COVER ASSEMBLY
6-13 6-15
6-21
6-1 6-16 6-17
6-27
6-19
6-12
6-22
6-20
6-18
6-23 6-14
6-6
6-4
6-2
6-10
6-26
6-5
6-3
6-7
6-8
6-24
6-12
6-25
6-9
44
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
6-1 Q9007207201A FRONT COVER ASS'Y- DIGIMAX V5 1
Q9007209301A FRONT COVER ASS'Y-KENOX DIGIMAX V5 1
Q9007211001A FRONT COVER ASS'Y- DIGIMAX V5000 1
Q9007211101A FRONT COVER ASS'Y-KENOX DIGIMAX V500 1
6-2 Q7409134402A STROBO SHELD 1
6-3 Q7117007402A FRONT COVER- DIGIMAX V5 1
Q7117007601A FRONT COVER-KENOX DIGIMAX V5 1
Q7117008201A FRONT COVER- DIGIMAX V5000 1
Q7117008301A FRONT COVER-KENOX DIGIMAX V500 1
6-4 Q7217304502A FRONT INNER COVER 1
6-5 Q7409159801A STROBO SHIELD_A 1
6-6 Q7409159901A SHIELD FORM A 1
6-7 Q7409156001A FRONT TAPE 1
6-8 Q7217304901A GRIP 1
6-9 Q7004000103A DECO RING 1
6-10 Q7217255702A FINDER WINDOW 1
6-11 Q7409139801A FRONT COVER TAPE 3
6-12 Q6003028101A SCREW 3
6-13 Q9007207301A TOP COVER ASSY 1 V5
Q9007211201A TOP COVER ASSY 1 V5000
6-14 Q0960213901A BOND TAPE-C 1
6-15 Q7217254501A RELEASE BUTTON 1
6-16 Q7217254602B RELEASE DECO 1 V5
Q7217276401A RELEASE DECO 1 V5000
6-17 Q7217254701A POWER BUTTON 1 V5
Q7217276501A POWER BUTTON 1 V5000
6-18 Q7217254802A POWER PLATE 1
6-19 Q7217308401A TOP COVER 1 V5
Q7217317901A TOP COVER 1 V5000
6-20 Q6107050801A POWER SPRING 1
6-21 Q6107044602A RELEASE SPRING 1
6-22 Q7409145101A RELEASE WASHER 1
6-23 Q6735002101A REMOCON FILTER 1
6-24 Q7217254102A BOTTOM COVER 1 V5
Q7217276001A BOTTOM COVER 1 V5000
6-25 Q7217308201A CONNECTOR COVER 1 V5
Q7217318001A CONNECTOR COVER 1 V5000
6-26 Q7409032001A MAIN PCB TAPE-A 1
6-27 Q7409135901A PHOTO SHIELD 1
45
7. BACK COVER ASSEMBLY
7-4
7-14 7-3 7-5
7-1 7-16
7-22
7-24
7-13
7-25
7-7 7-6
7-18
7-9 7-35
7-8
7-20 7-15
7-30 7-10
7-33
7-23 7-11
7-29 7-12
7-36 7-19
7-23
7-26 7-31 7-28
7-17
7-23
7-23
7-27
7-21
7-34
7-32
7-2
46
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
7-1 Q9007206901A BACK COVER ASS'Y 1 V5
Q9007211301A BACK COVER ASS'Y 1 V5000
7-2 Q4101026001A LCD CU F PCB 1
7-3 Q7217254902A ZOOM BUTTON 1
7-4 Q7217308501A MODE DIAL 1 V5
Q7217317801A MODE DIAL 1 V5000
7-5 Q7309036902A EP RUBBER 1
7-6 Q7217253903A BACK COVER 1 V5
Q7217275801A BACK COVER 1 V5000
7-7 Q7217255101A NAVI BUTTON 1
7-8 Q7217255201A OK BUTTON 1
7-9 Q7217255302A PLAY BUTTON 1
7-10 Q7217255402A FUNCTION BUTTON_1 1
7-11 Q7217255502A FUNCTION BUTTON_2 1
7-12 Q7217255602A FUNCTION BUTTON_3 1
7-13 Q7217256002A LAMP WINDOW 1
7-14 Q7217256103A JACK DOOR 1 V5
Q7217277301A JACK DOOR 1 V5000
7-15 Q9008060101A MODE CONTACT ASSY 1
7-16 Q7017033702B MODE CLICK PLATE 1
7-17 Q7017034302A LCD P_PLATE 1
7-18 Q7309037101B NAVI RUBBER 1
7-19 Q7309037201A FUNCTION RUBBER 1
7-20 Q7309037301A ZOOM RUBBER 1
7-21 Q7217255801A TFT LCD WINDOW 1
7-22 Q7409128701A EP RUBBER TAPE 1
7-23 Q9761173007 SCREW 10
7-24 Q0958905801A FRONT TAPE-A 1
7-25 Q0960213901A BOND TAPE-C 1
7-26 Q7011041902A SPEAKER FRAME 1
7-27 Q9008056701A MODE FPCB ASSY 1
7-28 Q7409138202C FUNCTION TAPE_2 1
7-29 Q7409138401C LCD TAPE_2 1
7-30 Q7409141101A NAVI CUSHION 4
7-31 Q9008069701A LCD PCB SMD ASSY 1
7-32 Q0704009501A TFT LCD 1
7-33 Q4719002901A SPEAKER 1
7-34 Q7409128402A LCD SPONGE 1
7-35 Q9007212501A BACK COVER SUB ASS'Y 1 V5
Q9007213101A BACK COVER SUB ASS'Y 1 V5000
7-36 Q7409129002A NAVI BUTTON SHEET 1
47
8. PACKING ITEMS
8-15 8-16 8-17 8-18 8-10
8-11
8-9
8-12
8-13
8-1
8-14
8-4
8-3
8-19 8-5 8-6
8-20 8-7
8-8
8-2 8-8
48
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
8-1 QP960210101A PE BAG (CAMERA) 1
8-2 Q6909011601A PE BAG (ACCESSORY) 1
8-3 Q6901172401A INNER PAD- DIGIMAX V4 1
8-4 Q6904024701A POUCH-KENOX 1
8-5 Q6806195501A Q/GUIDE_KENOX V5_KOR 1
Q6806195601A Q/GUIDE_DIGIMAX V5_ENG 1
Q6806195701A Q/GUIDE_DIGIMAX V5_GER 1
Q6806195801A Q/GUIDE_DIGIMAX V5_FRA 1
Q6806195901A Q/GUIDE_DIGIMAX V5_SPA 1
Q6806196001A Q/GUIDE_DIGIMAX V5_ITA 1
Q6806196101A Q/GUIDE_DIGIMAX V5_CHI(T) 1
Q6806196201A Q/GUIDE_DIGIMAX V5_DUT 1
Q6806196301A Q/GUIDE_DIGIMAX V5_POR 1
Q6806196401A Q/GUIDE_DIGIMAX V5_SWE 1
Q6806196501A Q/GUIDE_DIGIMAX V5_DEN 1
Q6806196601A Q/GUIDE_DIGIMAX V5_FIN 1
Q6806196701A Q/GUIDE_DIGIMAX V5_RUS 1
Q6806196801A Q/GUIDE_DIGIMAX V5_CHI(S) 1
Q6806209501A Q/GUIDE_DIGIMAX V5_CZE 1
Q6806209601A Q/GUIDE_DIGIMAX V5_HUN 1
Q6806209701A Q/GUIDE_DIGIMAX V5_POL 1
Q6806209801A Q/GUIDE_DIGIMAX V5_IND 1
8-6 Q6806196901A U/MANUAL_KENOX V5_KOR 1
Q6806197001A U/MANUAL_Digimax V5_ENG 1
Q6806197101A U/MANUAL_Digimax V5_GER 1
Q6806197201A U/MANUAL_Digimax V5_FRA 1
Q6806197301A U/MANUAL_Digimax V5_SPA 1
Q6806197401A U/MANUAL_Digimax V5_ITA 1
Q6806197501A U/MANUAL_Digimax V5_CHI(T) 1
Q6806197601A U/MANUAL_Digimax V5_DUT 1
Q6806197701A U/MANUAL_Digimax V5_POR 1
Q6806197801A U/MANUAL_Digimax V5_SWE 1
Q6806197901A U/MANUAL_Digimax V5_DEN 1
Q6806198001A U/MANUAL_Digimax V5_FIN 1
Q6806198101A U/MANUAL_Digimax V5_RUS 1
49
Fig.No. Parts No. Parts Name Q'ty Remarks
Q6806198201A U/MANUAL_Digimax V5_CHI(S) 1
Q6806209901A U/MANUAL_Digimax V5_CZE 1
Q6806210001A U/MANUAL_Digimax V5_HUN 1
Q6806210101A U/MANUAL_Digimax V5_POL 1
Q6806210201A U/MANUAL_Digimax V5_IND 1
8-7 Q6807002601F WARRANTY CARD_KOREA 1
Q6807003003S WARRANTY CARD_EXP 1
Q6807003802D WARRANTY CARD_UK 1
Q6807010902B WARRANTY CARD_RUS(3 YEARS) 1
Q6807011301B WARRANTY CARD_TSOE(CHINA) 1
8-8 Q6901190701A G/T BOX_KENOX V5_KOR 1
Q6901190801A G/T BOX_DIGIMAX_V5_EXP/AUS 1
Q6901190901A G/T BOX_DIGIMAX_V5_USA/CAN 1
Q6901194101A G/T BOX_DIGIMAX V5000_EXP/AUS 1
Q6901194201A G/T BOX_DIGIMAX V5000_USA/CAN 1
Q6901195001A G/T BOX_KENOX V500_KOR 1
Q6901196501A G/T BOX_DIGIMAX_V5_EXP/AUS_SLB-1437 1
Q6901197001A G/T BOX_DIGIMAX_V5000_EXP/AUS_SLB-1437 1
8-9 4309-0009-01A LI-ION CHARGER 1
8-10 4301-0024-01A LI-ION BATTERY 1
8-11 3801-0027-01A CAR CHARGE CABLE 1
8-12 3719-0021-01A AC ADAPTOR 1
3719-0024-01A AC ADAPTOR-TEOE 1
8-13 3801-0030-01A AC CODE CABLE-KOREA 1
3801-0031-01A AC CODE CABLE-USA 1
3801-0032-01A AC CODE CABLE-EXP 1
3801-0033-01A AC CODE CABLE-UK 1
3801-0034-01A AC CODE CABLE-AUS 1
8-14 9010-0443-01A REMOCON ASS'Y 1
8-15 7409-1349-01A STRAP 1
8-16 3802-0020-01A USB CABLE 1
8-17 3802-0019-01A A/V CABLE 1
8-18 4602-0006-01A SD CARD-32MB 1
8-19 Q4609007601A DRIVER+VIEW+Adobe Photoshop Elements 1
Q4609007701A DRIVER+VIEW+ArcSoft Photoimpression 1
50
9. INITIAL PARTS LIST
PAGE PARTS NO. PARTS NAME SPEC SYMBOL
30 Q7011043404A BATTERY CONTACT SUS304 CSP-H
30 Q7217253502A BATTERY COVER V5
30 Q7217275501A BATTERY COVER V5000
32 Q9008055501A MAIN F-PCB ASS'Y
32 Q9002104301A AF MOTOR
32 Q0608000701A PHOT REFLECTER
32 Q0608000901A PHOT INTERRUPTER
32 Q9002109401A 3rd BARREL ASS'Y
32 Q9005016301A SHUTTER ASS'Y
34 Q9002109901A BARRIER ASS'Y
28 Q7012074102A DECORATION RING V5
28 Q7012074901A DECORATION RING V5000
40 Q9008056701A MODE FPCB ASSY
40 Q7217308501A MODE DIAL V5
40 Q7217317801A MODE DIAL V5000
40 Q7217256103A JACK DOOR V5
40 Q7217277301A JACK DOOR V5000
40 Q7217255801A TFT LCD WINDOW
38 Q7217255702A FINDER WINDOW
38 Q7217254102A BOTTOM COVER V5
38 Q7217276001A BOTTOM COVER V5000
40 Q0704009501A TFT LCD
30 Q0902007301A MAIN CONDENSOR 115UF/310V
74 Q3722000801A DC JACK J6
74 Q2601000901A OSC TANS T1
72 Q1407000601A IGBT Q21
72 Q3403000301A RELEASE SWITCH EVQPRBA09 S2
72 Q3408000701A POWER SWITCH S1
72 Q3601000601A CHIP FUSE F1
74 Q3708004601A USB/VIDEO CONNECTOR CAM-G38 J4
30 Q0611003101A XE-TUBE
30 Q2704001401A TRIG TANS
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
C94 C95
C96
FB14
E4 C104
R46
E2 E1 Q5 R195 R115 R146 R147
R94
R50
R148
C102
R120
R45
R48
U8 C53 FB8 C55 J5
C106 R117
C107
E6 R122 R144
R124 R142
R126 R139
R128 R137
C74
C69
R130 R134
Q3
R100 R132
FB17
Q7
L2
R151
C116 U5
C56 C93 U4 R181
R49 C108 R182
C110
R179
E5 FB16
C92 C91 R96 C109
R183
75
R180
Q4 R177
R178 R184
U7 Q6 R114 R174
R116 R189
R47 R119 R186
R188
R191R193
C54 R185
R121 R187
C81
C84
E3
R196
R192 C103 R190 R123
R108 R176 C62
R112
R110
R109
R197 C58 C60 FB1
C2
C59
C61
R198
R135 R118
R104
R157 R102
R107
R111 R103
R105
R106
R113
C100
R73 C1
FB9 C57 Q8 R79
FB10 D5 R86
FB15
R72
R87
Q9 R77
D6
R71
J3
R88
Q10 R75
D7
76
R53 R52 R51 R54
R68 R69
R70 R74
R76 R78
R80 R81
U3
R65
R84 R85
J4
R82 R83
C79
U6
R98
C26
C25
R24
R25
FB7
C3
D4
C37
C38
R23
R20
R22
R29
R30
R33
R37
R36
R39
C97
C4 D3 C23
R21
R28
R32
R31
R34
R35
R38
FB2
R201
C101 C43
C35
R12
C36
D1
C18
C66 R91 R89 C65 R175 C20
77
R97 R194 R13
R8
Q1
X1
C72
C75
FB11
Y1 Q2
C51
C49
C52
R4
R16 C33 R18 C34 R11
U2
C87 C50 C47
R3
C86
C19
CCDR2
CCDC3
C73 E7
J1
FB12 C85 C32 R7 L1 C46
C80 C115 C29 CCDR1
FB13
C31 R6
R202
C28
R17
C77 C76 C82 FB18
R200 R5 IQ1
C42
C44
C41
CCDC2
C83 C78 C30
CCDC1
C105
C14 C8 C27
C22 C48
J2 FB5 C40
FB4
C45
C99 C98
C10 U1
C9
Y2
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
