Image preview - the first page of the document
>> Download SMV70 documenatation <<
Text preview - extract from the document
'
PC with processor better than MMX Pentium 233MHz (XP : Pentium II 300MHz)
Windows 98/98SE/2000/ME/XP
For Windows Minimum 32MB RAM (XP : 128MB)
140MB of available hard-disk space, USB port, CD-ROM drive,
800 600 pixels, 16-bit colour display compatible monitor
(24-bit color display recommended)
Power Mac G3 or later
Mac OS 9.0 ~ 10.2
For Macintosh Minimum 64MB RAM
110MB of available hard-disk space, USB port, CD-ROM drive,
QuickTime 4.0 or later for Movie Clip
PC Card Adaptor Card Reader SD Card
USB Cable
IBM / MAC
Video Cable
Lap top TV Monitor
'
1. MAIN ASSEMBLY
1-17
1-14
1-13
1-1
1-12
1-5
1-10
1-3 1-19
1-6
1-4
1-10
1-20
1-8
1-18
1-9
1-2 1-10
1-7
1-10
1-11
1-10
1-16
1-15
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
1-1 Q4101028301A CONNECTION FPCB 1
1-2 Q7211068701A TRIPOD CONNECTOR 1
1-3 Q7309041101A SPEAKER RUBBER 1
1-4 Q7411103602A STRAP HOLDER 1
1-5 Q7217323201A L SIDE COVER 1
1-6 Q7017036201A E-RING 1
1-7 Q7117009201A R SIDE DECO 1
1-8 Q7409157601A R SIDE DECO TAPE 1
1-9 Q7217323401A R SIDE COVER 1
1-10 Q6003042701A SCREW 8
1-11 Q6003042601A SCREW 2
1-12 Q7217299501B EP WINDOW 1
1-13 Q7217301302B EP COVER 1
1-14 Q7217323101A JACK DOOR 1
1-15 Q7411103702A CONVERT BARREL-A 1
1-16 Q7409174301A MIC LABEL_KENOX @7 1
Q7409174201A FCC LABEL_DIGIMAX V70/@7 1
1-17 Q7409160201A LCD PROTECTION SHEET 1
1-18 Q7012074901A DECORATION RING 1
1-19 Q9007220501A BACK COVER ASS'Y 1
1-20 Q9007966901A FRONT COVER ASSY-DIGIMAX @7 1
Q9007220701A FRONT COVER ASSY-DIGIMAX V70 1
Q9007220801A FRONT COVER ASSY-KENOX @7 1
2. BODY ASSEMBLY
2-26
2-39
2-40
2-41
2-44
2-45 2-43
2-13
2-42
2-8 2-23
2-46
2-37
2-7
2-21
2-6
2-24
2-14
2-19 2-22
2-15 2-38
2-1
2-17
2-18 2-37
2-56
2-20 2-3 2-5
2-16 2-2
2-4
2-13
2-37 2-52
2-9
2-11 2-55
2-54
2-10
2-12
2-13 2-51 2-57
2-46
2-25
2-34
2-37
2-30
2-35
2-27 2-28 2-29
2-53
2-32 2-32
2-48 2-50 2-47
2-49
2-33 2-31
2-36
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
2-1 Q7211071301A BATTERY CHAMBER_A 1
2-2 Q7011046002A BATTERY CONTACT 2
2-3 Q7211068402A BATTERY CHAMBER-B 1
2-4 Q7409156801A BATTERY SUB CONTACT 1
2-5 Q7011045602A BATTERY SUB CONTACT 1
2-6 Q7211069201B BATTERY LOCK 1
2-7 Q0958905801A FRONT TAPE-A 1
2-8 Q7011046301A BATTERY LOCK PLATE 1
2-9 Q7211068802A BATTERY PUSH SLIDER 1
2-10 Q6107056301A BATTERY PUSH SPRING 1
2-11 Q7411103501A PUSH SHAFT 1
2-12 Q7011045902A PUSH GUIDE PLATE 1
2-13 Q6003027501A SCREW 5
2-14 Q7211069104A BATTERY PLATE_B 1
2-15 Q7011045401A BATTERY PLATE-C 1
2-16 Q7011045303A BATTERY PLATE-A 1
2-17 Q6003042401A SCREW 1
2-18 Q6107056201A BATTERY HINGE SPRING 1
2-19 Q7411103301A BATTERY HINGE 1
2-20 Q7011045701A BATTERY PLATE GUIDER 1
2-21 Q7217326201A BATTERY COVER 1
2-22 Q7409173301A BATTERY LABEL 1
2-23 Q3708008001A CARD SOCKET 1
2-24 Q4101030101A CARD FPCB 1
2-25 Q9008080001A POWER PCB ASS'Y 1
2-26 Q7011046502B SPEAKER FRAME 1
2-27 Q9008071401A REFLECTOR ASS'Y 1
2-28 Q7014004501A REFLECTOR 1
2-29 Q7211068503A REFLECTOR HOLDER 1
2-30 Q4102007601A TRIG FPCB 1
2-31 Q0611003101A XE-TUBE 1
2-32 Q7011045501A XE TUBE CONTACT 2
2-33 Q7211068901A FRESNEL LENS 1
2-34 Q2401007701A MAIN CONDENSOR 1
2-35 Q7409148601A CONDENSOR TAPE 1
2-36 Q9762144007 SCREW 1
2-37 Q0961900301A SCREW1 2
2-38 Q9008080101A MAIN PCB SMD ASS'Y 1
2-39 Q9008071601A SPEAKER FPCB ASS'Y 1
2-40 Q4101027801A SPEAKER FPCB 1
2-41 Q4719002801A SPEAKER 1
2-42 Q0601004801A AF LED 1
2-43 Q7211068601A AF PHOTO HOLDER 1
2-44 Q0509000601A PHOTO TR 1
2-45 Q7211069303A PHOTO TR CAP 1
2-46 Q9761173507 SCREW 4
2-47 Q9008071701A REMOCON FPCB ASS'Y 1
2-48 Q4101027901A REMOCON FPCB 1
2-49 Q1409000201A REMOCON RECEIVER 1
2-50 Q0902007801A MIC 1
2-51 Q9008071801A JACK PCB ASS'Y 1
2-52 Q7409156701A TOP PCB TAPE 1
2-53 Q9002130001A BARREL SUB ASS'Y 1
2-54 Q2904002201A IR FILTER 1
2-55 Q7309042403A OLPF CUSHION 1
2-56 Q9008080201A CCD FPCB ASS'Y 1
2-57 Q9003020801A FINDER ASS'Y 1
3. BARREL ASSEMBLY
3-20
3-1
3-44 3-18
3-43
3-17
3-2
3-14 3-17
3-15
3-10
3-6 3-16
3-5 3-13
3-21
3-22 3-12
3-3
3-24 3-11
3-7
3-23
3-25 3-4 3-9
3-32
3-26 3-8 3-28
3-19 3-32 3-30
3-33
3-29
3-34
3-32
3-27
3-35 3-31
3-37
3-36 3-39
3-40
3-41
3-38
3-42
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
3-1 Q9002125201A LENS BASE ASS'Y 1
3-2 Q7212178705A LENS BASE 1
3-3 Q7411085401A AF GUIDER BAR_A 1
3-4 Q7411100601A AF GUIDE BAR 1
3-5 Q7411101001A FINDER GUIDE BAR 1
3-6 Q7411085902A ZOOM GEAR_A SHAFT 1
3-7 Q7411090001B ZOOM GEAR_C SHAFT 2
3-8 Q3107001701A ZOOM MOTOR 1
3-9 Q9611142007 SCREW 2
3-10 Q7212160001B ZOOM MOTOR GEAR 1
3-11 Q7411085802A ZOOM GEAR_D 1
3-12 Q7411085702A ZOOM GEAR_C 1
3-13 Q7411085601B ZOOM GEAR_B 1
3-14 Q7212160101A ZOOM GEAR_A 1
3-15 Q7212160602B ZOOM GEAR_E 2
3-16 Q7212178801A ZOOM COVER 1
3-17 Q0961900301A SCREW 3
3-18 Q9008068201A MAIN PCB ASS'Y 1
3-19 Q6003019201A SCREW 2
3-20 Q0994913101A SCREW 1
3-21 Q6107048305A 3RD LENS BARREL SPRING 1
3-22 Q9002124701A 3rd LENS ASS'Y 1
3-23 Q7012069406C AF LIMIT SPRING 1
3-24 Q7012069301A AF CLIP 1
3-25 Q6001014001A SCREW 1
3-26 Q7212178906A AF HOLDER 1
3-27 Q7212159302A GUIDE PLATE 1
3-28 Q9002124601A 2nd LENS ASS'Y 1
3-29 Q9005016301A SHUTTER ASS'Y 1
3-30 Q9761142507S CREW 2
3-31 Q7409123201A SHUTTER PROTECT SHEET 1
3-32 Q7411085305A 2ND MOVE PIN 3
3-33 Q6001014001A SCREW 1
3-34 Q7012069202A F-PCB GUIDER 1
3-35 Q7212171301A ZOOM RING 1
3-36 Q7212158903A 1ST GUIDE BARREL 1
3-37 Q9002109201A 1st LENS ASSY 1
3-38 Q7012069004B 1ST PUSH PLATE 1
3-39 Q7411097502A 1st MOVE PIN 2
3-40 Q7212171201A CAM BARREL 1
3-41 Q7212178501A OUTER CAM BARREL 1
3-42 Q9002125101A OUTER GUIDE BARREL ASS'Y 1
3-43 Q0961900301A SCREW 5
3-44 Q9002130001A BARREL SUB ASS'Y 1
4. BARRIER ASSEMBLY
4-1
4-11
4-5
4-4
4-3
4-2
4-12
4-8
4-7
4-3
4-4 4-6
4-10
4-9
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
4-1 Q9002113901A BARRIER ASS'Y 1
4-2 Q7212167704A NEW FRONT PANEL 1
4-3 Q6107051702A NEW CLOSE SPRING 2
4-4 Q7212160403B BARRIER_C 2
4-5 Q7212167804A NEW BARRIER_A 1
4-6 Q7212167902A NEW BARRIER_B 1
4-7 Q7012073502A NEW BARRIER BASE 1
4-8 Q7012073403A NEW LEVER_B 1
4-9 Q7411095501A NEW LEVER PIN 1
4-10 Q7012073301A NEW LEVER_A 1
4-11 Q6107051802A NEW OPEN SPRING 1
4-12 Q7409120802B FORNT PANEL TAPE 2
5. FINDER ASSEMBLY
5-1 5-15
5-11
5-7
5-13
5-10
5-12
5-14
5-8
5-9
5-2
5-6
5-16
5-4
5-5
5-3
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
5-1 Q9003020801A FINDER ASS'Y 1
5-2 Q7213034004A FINDER BASE 1
5-3 Q7411100801A FINDER SHAFT 2
5-4 Q6721009002A CO LENS 1
5-5 Q6107055002A FINDER SPRING 1
5-6 Q9003021101A VA LENS ASS'Y 1
5-7 Q7411100901A EP SHAFT 1
5-8 Q6107055101A EP SPRING 1
5-9 Q6721009302A EP LENS 1
5-10 Q6003040801A SCREW 1
5-11 Q6726002401A PORRO PRISM 1
5-12 Q6725001001B MIRROR 1
5-13 Q6721009202A TARGET LENS 1
5-14 Q7013015203A FINDER MASK 1
5-15 Q7213034104A FINDER COVER 1
5-16 Q7409144002A SHIELD_A 1
6. FRONT COVER ASSEMBLY
6-18
6-1
6-17
6-16
6-15
6-10
6-14 6-19
6-9
6-13
6-28
6-11
6-6
6-20 6-12
6-7
6-31 6-5
6-4
6-7
6-30
6-2
6-8
6-21
6-3 6-23
6-22
6-29 6-25
6-24
6-26
6-27
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
6-1 Q9007966901A FRONT COVER ASSY-DIGIMAX @7 1
Q9007220701A FRONT COVER ASSY-DIGIMAX V70 1
Q9007220801A FRONT COVER ASSY-KENOX @7 1
6-2 Q7217323001A FRONT COVER BASE 1
6-3 Q7017044301A FRONT COVER-DIGIMAX @7 1
Q7117009001A FRONT COVER-DIGIMAX V70 1
Q7117009301A FRONT COVER-KENOX @7 7
6-4 Q7217299103A DIAL LAMP WINDOW 1
Q6107054401A POWER SPRING 1
6-6 Q7217298403A POWER BUTTON 1
6-7 Q7409145101A RELEASE WASHER 2
6-8 Q7117009101A TOP COVER 1
6-9 Q7017039003A MODE CLICK PLATE 1
6-10 Q7217323301A MODE DIAL 1
6-11 Q9008060101A MODE CONTACT ASS'Y 1
6-12 Q9761173507 SCREW 3
6-13 Q9008072901A JOG CONTACT ASS'Y 1
6-14 Q6107058201A JOG SPRING 1
6-15 Q7217298803B RELEASE DECO 1
6-16 Q9761142507 SCREW 2
6-17 Q6107044602A RELEASE SPRING 1
6-18 Q7217298305A RELEASE BUTTON 1
6-19 Q9008073001A MODE FPCB ASS'Y 1
6-20 Q0961900101A SCREW 2
6-21 Q7409161501A ELECTRONIC CONDUCTION 1
6-22 Q7217299401A FINDER WINDOW 1
6-23 Q7217299002A FRONT LED WINDOW 1
6-24 Q7217299301A AF WINDOW 1
6-25 Q7217299603A PHOTO WINDOW 1
6-26 Q6735004001A REMOTE CONTROL FILTE 1
6-27 Q7217299201A REMOCON WINDOW 1
6-28 Q7217301103B CONVERT BARREL_B 1
6-29 Q7217322701A FRONT GRIP 1
6-30 Q6003028101A SCREW 1
6-31 Q6003042701A SCREW 1
7. BACK COVER ASSEMBLY
7-36
7-32 7-35
7-1 7-37
7-31
7-29
7-34 7-27
7-24
7-41
7-25
7-33
7-27
7-23
7-40
7-30
7-28
7-22
7-26
7-42
7-3
7-2
7-17 7-10
7-5
7-15
7-6
7-20 7-14
7-4
7-7 7-21
7-8
7-19 7-16
7-12
7-11
7-13
7-12
7-39
7-9 7-38
7-12 7-18
7-12 7-12
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
7-1 Q9007220501A BACK COVER ASS'Y 1
7-2 Q9007220601A BACK COVER SUB ASS'Y 1
7-3 Q7217322901A BACK COVER 1
7-4 Q9007199801A NAVI BUTTON ASS'Y 1
7-5 Q7217297801A FUNCTION BUTTON-1 1
7-6 Q7217297901A FUNCTION BUTTON-2 1
7-7 Q7217298002A FUNCTION BUTTON-3 1
7-8 Q9008072201A KEY PCB ASS'Y 1
7-9 Q7017041802A PRESSURE PLATE 1
7-10 Q7309042903A LCD CLOSE CUSHION 2
7-11 Q7011047401A PCB WASHER 1
7-12 Q6003027501A SCREW 6
7-13 Q6003028101A SCREW 1
7-14 Q7217298102A FUNCTION BUTTON-4 1
7-15 Q7217301902A FUNCTION BUTTON-5 1
7-16 Q7309040902A FUNCTION RUBBER-A 1
7-17 Q7309041003A ZOOM RUBBER 1
7-18 Q9008072401A KEY FPCB ASS'Y 1
7-19 Q7217305001A LCD LOCK FRAME 1
7-20 Q7217301404A LCD CLOSE LOCK 1
7-21 Q6107056402A LCD CLOSE LOCK SPRING 1
7-22 Q9008080301A TFT LCD ASS'Y 1
7-23 Q9007208201A HINGE COVER ASS'Y 1
7-24 Q9010049501A HINGE ASS'Y 1
7-25 Q7409161901A HINGE ISOLATION TAPE 1
7-26 Q9008072701A HINGE FPCB ASS'Y 1
7-27 Q6001016501A SCREW 2
7-28 Q7217326401A HINGE HOUSING UPPER 1
7-29 Q7217326501A HINGE HOUSING LOWER 1
7-30 Q7017042701A LCD FRONT COVER 1
7-31 Q7409159401A LCD SPONGE 1
7-32 Q0604003201A LCD 1
7-33 Q9008072801A LCD PCB SMD ASS'Y 1
7-34 Q7409159501A LCD ISOLATION TAPE 1
7-35 Q7217299701A LCD BACK COVER 1
7-36 Q6003042801A SCREW 2
7-37 Q6001016401A SCREW 4
7-38 Q7217302002A UNDER LCD COVER 1
7-39 Q9761173507 SCREW 2
7-40 Q9762144007 SCREW 2
7-41 Q9762145007 TAP TITE SCREW 2
7-42 Q7217298203A ZOOM BUTTON 1
8. PACKING ITEMS
8-13 8-14 8-15 8-17
8-11 8-9 8-10
8-18
8-1
8-12
8-4
8-3
8-5
8-6
8-20
8-7
8-8
8-2
PARTS LIST
Fig.No. Parts No. Parts Name Q'ty Remarks
8-1 QP960210101A PE BAG (FOR CAMERA) 1
8-2 Q6909011601A PE BAG (FOR ACCESSORY) 1
8-3 Q6901176801A INNER PAD 1
8-4 Q6904025601A POUCH 1
8-5 Q6806238601A Q/GUIDE_DIGIMAX V70_ENG 1
Q6806238701A Q/GUIDE_DIGIMAX V70_GER 1
Q6806238801A Q/GUIDE_DIGIMAX V70_FRA 1
Q6806238901A Q/GUIDE_DIGIMAX V70_SPA 1
Q6806239001A Q/GUIDE_DIGIMAX V70_ITA 1
Q6806239101A Q/GUIDE_DIGIMAX V70_CHI(T) 1
Q6806239201A Q/GUIDE_DIGIMAX V70_DUT 1
Q6806239301A Q/GUIDE_DIGIMAX V70_POR 1
Q6806239401A Q/GUIDE_DIGIMAX V70_SWE 1
Q6806239501A Q/GUIDE_DIGIMAX V70_DEN 1
Q6806239601A Q/GUIDE_DIGIMAX V70_FIN 1
Q6806239701A Q/GUIDE_DIGIMAX V70_RUS 1
Q6806239801A Q/GUIDE_DIGIMAX V70_TUR 1
Q6806241401A Q/GUIDE_KENOX @7_KOR 1
Q6806239901A Q/GUIDE_DIGIMAX@7_CHI(S) 1
8-6 Q6806241301A U/MANUAL_Digimax@7_CHI(S) 1
Q6806241501A U/MANUAL_KENOX @7_KOR 1
Q6806240001A U/MANUAL_Digimax V70_ENG 1
Q6806240101A U/MANUAL_Digimax V70_GER 1
Q6806240201A U/MANUAL_Digimax V70_FRA 1
Q6806240301A U/MANUAL_Digimax V70_SPA 1
Q6806240401A U/MANUAL_Digimax V70_ITA 1
Q6806240501A U/MANUAL_Digimax V70_CHI(T) 1
Q6806240601A U/MANUAL_Digimax V70_DUT 1
Q6806240701A U/MANUAL_Digimax V70_POR 1
Q6806240801A U/MANUAL_Digimax V70_SWE 1
Q6806240901A U/MANUAL_Digimax V70_DEN 1
Q6806241001A U/MANUAL_Digimax V70_FIN 1
Q6806241101A U/MANUAL_Digimax V70_RUS 1
Q6806241201A U/MANUAL_Digimax V70_TUR 1
8-7 Q4609009801A DRIVER+Quick+VIEW+PhotoImpression+Digimax Reader 1
Q4609009901A DRIVER+Quick+VIEW+Photo Elements+Digimax Reader 1
Q4609010001A CD ROM_Digimax@7 _CHI(S) 1
Fig.No. Parts No. Parts Name Q'ty Remarks
8-8 Q6901204701A G/T BOX_DIGIMAX@7_CHI(S) 1
Q6901204501A G/T BOX_DIGIMAX_V70_EXP/AUS 1
Q6901204601A G/T BOX_DIGIMAX_V70_EXP/AUS/USA/CAN_SLB-1437 1
Q6901204801A G/T BOX_KENOX @7_KOR 1
Q6901204701A G/T BOX_DIGIMAX @7_CHI(S) 1
8-9 Q4308000101A CR-V3 1
8-10 Q4309001401A LI-ION CHARGER SBC-L2 1
8-11 Q4301002401A LI-ION BATTERY SLB-1437 1
8-12 Q3801003201A AC CODE CABLE_EXP 1
Q3801003101A AC CODE CABLE_USA 1
Q3801001001A AC CODE CABLE_UK 1
Q3801003401A AC CODE CABLE_AUS 1
Q3801003001A AC CODE CABLE_KOR 1
Q3801003701A AC CODE CABLE_CHI 1
8-13 Q7409121701A STRAP 1
8-14 Q3802002801A USB CABLE 1
8-15 Q3802001901A A/V CABLE_V4/V3 1
Q6807003003U WARRANTY CARD_EXP 1
Q6807010902B WARRANTY CARD_RUS 1
Q6807002601F WARRANTY CARD_KOREA 1
Q6807011301B WARRANTY CARD_TSOE(CHINA) 1
8-17 Q4602000601A SECURE DIGITAL CARD(32MB) 1
Q4602000701A SECURE DIGITAL CARD(64MB) 1
8-18 Q9010044301A REMOCON ASSY 1
9. INITIAL PARTS LIST
PAGE PARTS NO. PARTS NAME SPEC SYMBOL
32 Q4101028101A CARD FPCB
30 Q7217323401A R SIDE COVER
30 Q7217323101A JACK DOOR
30 Q9007220501A BACK COVER ASS'Y
30 Q9007966901A FRONT COVER ASS'Y DIGIMAX @7
30 Q9007220701A FRONT COVER ASS'Y DIGIMAX V70
30 Q9007220801A FRONT COVER ASS'Y KENOX @7
32 Q9008080001A POWER PCB ASS'Y
32 Q9008080101A MAIN PCB SMD ASS'Y
32 Q9008071801A JACK PCB ASS'Y
32 Q9008080201A CCD FPCB ASS'Y
32 Q9008072201A KEY PCB ASS'Y
42 Q9008073001A MODE FPCB ASS'Y
38 Q9003020801A FINDER ASS'Y
34 Q9002130001A BARREL SUB SS'Y
42 Q9008072801A LCD PCB SMD ASS'Y
42 Q0604003201A LCD
32 Q9008071601A SPEAKER FPCB ASS'Y
32 Q9008071701A REMOCON FPCB ASS'Y
42 Q9008072401A KEY FPCB ASS'Y
72 Q2802001901A CRYSTAL Y2
72 Q4304000101A BUTTONCELL BATTERY BTP1
72 Q3601000701A CHIP FUSE F1
73 Q1407000901A IGBT Q8
73 Q2704001901A TRIG COIL T2
73 Q2601001501A TRANSFORMER T1
73 Q2601002001A TRANSFORMER T1_LCD
73 Q2601002101A TRANSFORMER T2_CCD
73 Q1209002001A PWMIC U1
73 Q2403008901A CHIP CAP. "C18,21,26,43"
76 Q3708004601A USB/AV JACK J3
76 Q3722000801A DC JACK J8
77 Q3403000301A RELEASE SWITCH S2
77 Q3409001901A TACT SWITCH S1
AF Chart
80cm
Camera
Tripod
Reflector paper
1m
Camera
Tripod
Q4
J3
D3 J7
D4
Q5
J6
D2
Q3
C3 C11 C6
U1
Q1
C97
C94
J4
C105 U6
Y2
J5
U3
U2 U5 J2
C74 C75
J1
C120
U7
U8
Y1
C108
C92
Y3
C72
C62
C63
U4
Q2
C83
J4
REF8
CEF7
10 2
Q10
E8
REF1 REF3
QEF5
REF7 R138
CEF5
REF5
QEF4
R236 QEF2
REF2
QEF1 SVCC1
CEF8
CEF1 BDEF1
AL LEDN
AL LEDP
SPK N1
SPK P1
LED P1
REF9 REF4
QEF3
XETN1 XGND1
CEF2
CEF3
DEF1
DEF2
CEF4
UEF1 LED N1
BTP1 : Button cell Battery
Y2 : Crystal
Q4304000101A
Q2802001901A
BTP1
C15
C11
C3
Y2
LI CHK
LED1
LED2
LED3
R156
44 34 C19
R195
R194 BAT 1
R157 1 33 R193 C79
R158 4 1 FB8
C20
C94
FB10
C85
R167
C75
U14
HRESET
C93
R237 R243 C83
E1 C100
Q13 U13
R226
E7 R103
C135
TDO
23 TMS
C48
TDI
C134 11 Q14
C90
R35
12 22 C50
C74 TCK VCC GND C49
C72
R150
R242
R105
C73
KEY PO 5 8
R6
R111 R244 R34
FB1
R180
R179 R108
C54
D11
C47 U16 Q4 R33
U2 F1
C57
C137 R238 U9 C56 R32
FB3 C8
C44
R38 BAT 1
RC S1
C25 C7 C71
MIC N1
U8 RC G
R37
C55
B 1 VIN1 G1 C70 MIC P1
Q11 5VCC A
F1 : Fuse
Q3601000701A
J3
1 79
51338 - 0803 (REC)
2 80
10 6 C78
R121 R127 C67 T1 : Transformer
R120
R123
R119
U12 Q12
Q2601001501A
5 FB5 R124
FB4 C64
R136
R137
R129
R126
C69
C62 C63 Q9 Q6 Q5
D10 T1
C60
C61
R133 1 8
5
6
R128
C66
Q7 Q8
R132
C65
R134
4 5 C68
4
1
T2
R131 R122
T2 : TRIG COIL
Q8 : IGBT Q2704001901A
Q1407000901A
T2_CCD : Transformer
L10
Q2601002101A L8 C30
D6
L9
C34
T1_LCD : Transformer 8 5 8 5
Q2601002001A C23
T2 CCD
T1 LCD
D1
D2
D3
D5
C38 C39
U1 : PWMIC 1 4 1 4
Q1209002001A C5 C24 C80
R232
R231
R230
R229
C1 C9 C13 Q1
C99
Q3
C6 R9 R5
R10
FB12
FB13
E2 R2 R1 Y2
R12 U1 C12
R7 40
E3
R227
R196
C136
14 8 31
R233 C138 1 30
R3
15 7 C16
R234
R14
R228
C87
C4
U17 U3-A1
R15
C95
R203 C96
C92 R17
R200
C28
R13
21 1
R19
22 28 C91 10 21 R11
R165 11 20 R8
R18
R16
R164 C20 8
5 1 C31 C33 R199
C133
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
