Image preview - the first page of the document
>> Download how_to_repair_115 documenatation <<
Text preview - extract from the document
Disassembly
Step 1 Step 2
Supply a DC Power to L/MOTOR DC
Supply a DC Power to L/MOTOR DC Unscrew a Slide Chassis
execute a Eject MODE(DC 3V below) Unscrew a Slide Chassis
execute a Eject MODE(DC 3V below)
-1/1-
Step 3 Step 4
Disassembly Slide Chassis.
Disassembly Slide Chassis. Separated a Slide chassis
Separated a Slide chassis
-2/1-
Modification
b
b
a
a
code: AD66-00327A
code: AD66-00327A
1. replace a new Slide Main Chassis ((Recommend ))
1. replace a new Slide Main Chassis Recommend
2. Modification of Slide Main Chassis
2. Modification of Slide Main Chassis
(( Bend a little, not too much. ((First, Down and Twist direction))
Bend a little, not too much. First, Down and Twist direction))
First Second
Front
aa b a Front b
b a b
Back
-3/1-
Assembly
Step 1
11
33
22
11
22
33
before Assembly of slide chassis,
before Assembly of slide chassis,
set a hole() of gear to one of main chassis and check
set a hole() of gear to one of main chassis and check
points() between gears and check a position of Arm
points() between gears and check a position of Arm
Tension ().
Tension ().
OK NG
-4/1-
Step 2 Step 3
Test ::supply a DC Power to L/MOTOR.
Test supply a DC Power to L/MOTOR.
Put a Slide main and screw itit
Put a Slide main and screw ((in direction and reverse test ))
in direction and reverse test
** final Test ---> Loading & Unloading Test after inserting a tape ( over 5 times)
-5/1- ( on condition of full Unit.)
