Image preview - the first page of the document



>> Download Samsung_HT_DB120.part4 documenatation <<

Text preview - extract from the document

1. Alignment and Adjustments
1. Tuner




                                                                                                       FM THD Adjustment                           FM
                                                                                                                                     Output
                                                                                                                                                   Antenna SET
                                                                                                                                     GND
                                                                                          SSG FREQ.               98 MHz                           Terminal
                                                                                                                                                                                  Oscilloscope
                                                                                          Adjustment                              FM S.S.G                            Input
                                                                                          point             FM DETECTOR COIL                  Speaker
                                                                                          (FM DET)                                            Terminal
                                                                                                                                                                     output              Input
                                                                                          Output             60 dB
                                                                                                                                                                 Distortion Meter
                                                                                          Minumum Distortion (0.4% below)
                                                                                          (Figure 1-1)
                                                                                                                                   Figure1-1 IF CENTER and THD Adjustment




                                                                                                FM Search Level Adjustment
                                                                                                                                                  28 dB      FM Antenna
                                                                                           SSG FREQ.              98 MHz
                                                                                           Adjustment       BEACON                                                             SET
                                                                                           point            SENSITIVITY
                                                                                             (SVR1)         SEMI-VR(20K)                        GND
                                                                                                                                  FM S.S.G                       FM IN
                                                                                           Output           28 dB(
