Image preview - the first page of the document
>> Download Samsung SGH-800C service manual documenatation <<
Text preview - extract from the document
00-Cover 7/28/99 2:29 PM Page 2
GSM Mobile Cellular
Phone
SGH-800C
SERVICE Manual
GSM Mobile Cellular Phone CONTENTS
1. Exploded Views and it's Part list
2. Electrical Part list
3. Block Diagram
4. PCB Diagram
5. Schematic Diagram
00-Cover 7/28/99 2:29 PM Page 1
ELECTRONICS
Samsung Electronics Co.,Ltd.
Printed in Korea
05/1999 Rev 1.0
GH68-00684A
01-Exploded 7/21/99 11:28 AM Page 1
1. Exploded View and its Parts List
1-1 Main Exploded View
1-2 Main Parts List
1-3 Charger Exploded View
1-4 DTC Parts List
1-5 Travel Adaptor
1-6 Travel Adaptor Parts List
1-7 Ciger Light Adaptor
1-8 Ciger Light Adaptor Part List
1-9 Hands Free Kit Diagram
1-10 Boost Kit
1-11 Hands Free Car Kit Option
1-11-1 Hands Free Car Kit Ass'y
1-11-2 Hands Free Cradle Exploded View
1-11-3 Cradle Mechanism Part List
Samsung Electronics 1-1
01-Exploded 7/21/99 11:28 AM Page 2
Exploded View and its Parts List
1-1 Main Exploded View
1-1 1
2 2
4-1 5 3 20
5 21
4 22
6 6
23
24
7
8 25
9 12
13
10 26
11
27
14 28
29
15
30
16 31
17 32
18 33
19 34 40
35
36 43
37
41
38
42
39
44
45
46
47
1-2 Samsung Electronics
01-Exploded 7/21/99 11:28 AM Page 3
Exploded View and its Parts List
1-2 Main Parts List
NO DESCRIPTION SEC. CODE Q'TY REMARK
1 PMO-DECORATION(ANYCALL) CH72-00264A 1
1-1 PMO-DECORATION(SAMSUNG) GH-00263A 1
2 MPR-TAPE DOCORATION GH-74-10772A 1
3 LABEL(M)-BADGE GH-68-20008E 1
4 PMO-FOLDER UPPER(C) GH-72-00126A 1
4-1 PMO-FOLDER UPPER(EU) 1
5 SCREW-MACHINE 6001-000876 2
6 MCT-SHIELD GASKET GH74-00011A 1
7 LCD A'SSY 1
8 MPR-SPONGE-LCD GH74-10774A 1
9 MPR-TAPE EARPIECE CH74-00005A 1
10 MPR-TAPE VIBRATOR CH74-10776A 1
11 NPR-BRACKET FOLDER R GH71-10726A 1
12 MEX-LCD SHEET GH74-00124A 1
13 MEC-HINGE CH75-11337A 1
14 ICT-MAGNET GH70-40005A 1
15 NPR-BRACKET FOLDER GH71-10722A 1
16 PMO-FOLDER LOWER GH72-00125A 1
17 MEX-WINDOW TAPE GH74-00127A 1
18 PCT-WINDOW LCD GH72-00265A 1
19 PPR-TAPE WINDOW BOHO GH72-00498A 1
20 PMO-HINGE DUMMY GH72-00067A 1
21 PMO-REFLECTOR LED GH72-41801A 1
22 PMO-FRONT COVER GH72-00123A 1
23 MPR-DUPLEXER GH74-00106A 1
24 RMO-KEY PAD GH73-00074A 1
25 LOGIC BOARD 1
26 RMO-HOLDER MIC GH73-00121A 1
27 RMO-CONNECTOR COVER GH73-40704A 1
28 RMO HOLDER BUZZER GH73-00075A 1
29 RPR GROUND GASKET GH73-00005A 1
30 PMO-SHIELD COVER GH72-00262A 1
31 RMO-MOBILE CAP GH73-00079A 1
32 RF GOARD 1
33 NPR CONTACT PLATE-ANT GH71-00047A 1
34 PMO-KEY VOLULME GH72-41787A 1
35 MCT-SPONG BATT GH74-00159A 1
36 RMO-COVER EAR/J GH73-00087A 1
37 PMO-REAR COVER GH72-00124A 4
38 SCREW-MACHINE 6001-001140 1
39 LABEL(R)-MAIN GH68-00339A 1
40 NPR-BRACKET ANT GH71-10720A 1
41 IPR-SPRING LOCKER MA GH70-10516A 1
42 PMO-BATT LOCKER GH72-00127A 1
43 ANTENNA 1
44 PPR-SIM BOHO GH72-00449A 1
45 BATTERY SLIM 1
46 BATTERY STD 1
47 BATTERY LONG 1
Samsung Electronics 1-3
01-Exploded 7/21/99 11:28 AM Page 4
Exploded View and its Parts List
1-3 Charger Exploded View
1
2
6
3 4
5
7
8
9
10
11
1-4 Samsung Electronics
01-Exploded 7/21/99 11:28 AM Page 5
Exploded View and its Parts List
1-4 DTC Parts List
NO DESCRIPTION SEC. CODE Q'TY REMARK
1 DTC UPPER 1
2 HANDY LOCKER 1
3 SCREW 4
4 SUPPORT 1
5 SCREW 3
6 BATTERY HOUSING 1
7 PCB 1
8 DTC LOWER 1
9 SCREW 4
10 BUMPON 4
11 LABEL 1
Samsung Electronics 1-5
01-Exploded 7/21/99 11:28 AM Page 6
Exploded View and its Parts List
1-5 Travel Adaptor
B
A
C
1-6 Travel Adaptor Parts List
Type SEC Code Remark
A GH44-30548A CHINA
B GH44-30549A EUROPE
C GH44-30547A UNITED KINGDOM
1-6 Samsung Electronics
01-Exploded 7/21/99 11:28 AM Page 7
Exploded View and its Parts List
1-7 Ciger Light Adaptor
1-8 Ciger Light Adaptor Part List
Description SEC Code Remark
Ciger Light Adaptor Code GH44-30546A BLACK
Samsung Electronics 1-7
01-Exploded 7/21/99 11:28 AM Page 8
Exploded View and its Parts List
1-9 Hands Free Kit Diagram
CRADLE
CLAM SHEEL
MOUNT UPPER
CELLULAR
PHONE
FIXED SCREW
HANDS
FREE BOX
CLAM SHEEL
MOUNT LOWER
CAR
32
32
1-8 Samsung Electronics
01-Exploded 7/21/99 11:28 AM Page 9
Exploded View and its Parts List
1-11 Hands Free Car Kit Option
1-11-1 Hands Free Car Kit Ass'y
Micro Phone
Yellow(lgnition)
White(Stereo Mute)
Red(Vehicle Battery)
Black(GND)
Option Code: GH96-01150A
1-9 Samsung Electronics
01-Exploded 7/21/99 11:28 AM Page 10
Exploded View and its Parts List
1-11-2 Hands Free Cradle Exploded View
1
2
4
3
6
5
7
9
8
7
11 10
13
14
12
15
16
17
Samsung Electronics 1-10
01-Exploded 7/21/99 11:28 AM Page 11
Exploded View and its Parts List
1-11-3 HFK PART LIST
NO DESCRIPTION SEC. CODE Q'TY REMARK
1 CRADLE UPPER 1
2 SOCKET PLATE 1
3 TORSION SPRING 2
4 LOCKER(R) 1
5 LOCKER(L) 1
6 EJECTOR PIN(R) 2
7 EJECTOR SPRING 1
8 CLAMP 1
9 EJECTOR PIN(L) 1
10 SCREW M2 x 6, +, BH 6
11 PCB 1
12 CRADLE LOWER 1
13 SCREW M2 x 6, +, BH 1
14 CABLE CAP 1
15 SCREW M3 x 8, +, BH 1
16 CRADLE LABEL 1
17 CRADLE DATA CABLE 1
1-11 Samsung Electronics
2. Electrical Parts List
Main B'd (COMP)
NO SEC CODE Location No Description Etc
1 0404-001005 D400 DIODE-SCHOTTY, 40V, 1A, SOD-87
2 0407-001007 D401 DIODE-ARRAY, 80V, 25mA, CA4-2, UM5
3 0501-002096 Q200 TR-SMALL SIGNAL, NPN, 160mW, SOT343
4 0504-000167 U106, U874 TR-DIGITAL, NPN, 100mW, 10K-10Kohm, SSM
5 0504-000168 U401, U407 TR-DIGITAL, NPN, 100mW, 47K-47Kohm, SSM
6 1205-001643 U861 IC-KERNEL-5, BGA, 144P, 472MIL, 3V, TR
7 0504-001021 U105, U848 TR-DIGITAL, 3P, SC-59, TP
8 0506-001004 U309 TR-ARRAY, NPN/PNP, 2.50V, 300mW, UM5
9 1103-001090 U412 IC-EEPROM, 24C128, 16Kx8BIT, SOP, 8P, 150MIL
10 1107-001164 U870 IC-FLASH MEMORY, 512Kx16BIT, BGA,48P,
11 1109-001129 U867 IC-MEMORY, 1048KX16+524KX8BIT, CSP, 72P, 2.7V
12 1201-001326 U839 IC-BUFFER AMP, SOP, 6P, SINGLE
13 1203-001285 U103 IC-SWITCH VOL. REG. SOT-23, 5P, 150MIL
14 1203-001402 U402 IC-DC/DC CONVERTER, SO8, 8P, 150MIL
15 1203-001548 U846 IC-RESET, SOT-23, 5P, 150mW
16 1203-001717 U868 IC-SWITCH VOLT. REG. 3.0V, DUAL
17 1204-001405 U102 IC-BRIGHT, QFP, 48P, 4.0V, 400mW
18 1206-001009 U312 IC-RTC, SOP, 8P, 173MIL
19 1209-001161 U101 IC-Synthesizer, MTC20, 20P
20 1404-001005 TH400 THERMISTOR, 47Kohm, 5%, 4050K, 2.0mW/C, TP
21 1405-001019 VA1 VARISTOR, 5.6V,-,1.6x0.8mm,TP
22 2007-000138 R134, R135 R-CHIP, 100ohm, 5%, 1/16W, DA, TP, 1005
23 2007-000140 R112, R522 R-CHIP, 1Kohm, 5%, 1/16W, DA, TP, 1005
R124, R125, R127, R130,
24 2007-000141 R-CHIP, 2.2Kohm, 5%, 1/16W, DA, TP, 1005
R137, R438, R439,
25 2007-000142 R102 R-CHIP, 2.7Kohm, 5%, 1/16W, DA, TP, 1005
26 2007-000143 R500 R-CHIP, 4.7Kohm, 5%, 1/16W, DA, TP, 1005
27 2007-000147 R128, R114 R-CHIP, 8.2Kohm, 5%, 1/16W, DA, TP, 1005
R101, R219, R422, R423,
28 2007-000148 R427, R433, R970, R972, R-CHIP, 10Kohm, 5%, 1/16W, DA, TP, 1005
R988
29 2007-000149 R113 R-CHIP, 12Kohm, 5%, 1/16W, DA, TP, 1005
30 2007-000157 R440, R442, R474 R-CHIP, 47Kohm, 5%, 1/16W, DA, TP, 1005
31 2007-000159 R424 R-CHIP, 56Kohm, 5%, 1/16W, DA, TP, 1005
32 2007-000161 R123, R126 R-CHIP, 82Kohm, 5%, 1/16W, DA, TP, 1005
R402, R421, R428, R434,
33 2007-000162 R436, R441, R964, R965, R-CHIP, 100Kohm, 5%, 1/16W, DA, TP, 1005
R976, R979, R987,R993
34 2007-000171 R136 R-CHIP, 0 ohm, 5%, 1/16W, DA, TP, 1005
R100, R103, R105, R116,
35 2007-000172 R-CHIP, 10ohm, 5%, 1/16W, DA, TP, 1005
R206, R503, R129
36 2007-000932 R220 R-CHIP, 470ohm, 5%, 1/16W, DA, TP, 1005
R107, R108, R109, R117,
37 2007-001288 R-CHIP, 18ohm, 5%, 1/16W, DA, TP, 1005
R120, R121
38 2007-001292 R221, R222 R-CHIP, 33ohm, 5%, 1/16W, DA, TP, 1005
39 2007-001298 R504 R-CHIP, 51ohm, 5%, 1/16W, DA, TP, 1005
40 2007-001301 R131, R132, R133 R-CHIP, 68ohm, 5%, 1/16W, DA, TP, 1005
41 2007-001307 R209 R-CHIP, 180 ohm, 5%, 1/16W, DA, TP, 1005
42 2007-000242 R992 R-CHIP, 1.5Kohm, 5%, 1/16W, DA, TP, 1005
Samsung Electronics 2-1
Electrical Parts List
43 2007-001319 R467 R-CHIP, 1.2Kohm, 5%, 1/16W, DA, TP, 1005
44 2007-001320 R464 R-CHIP, 1.8Kohm, 5%, 1/16W, DA, TP, 1005
45 2007-007137 R469, R470, R471 R-CHIP, 1.2Kohm, 1%, 1/16W, DA, TP, 1005
46 2007-007142 R435 R-CHIP, 10Kohm, 1%, 1/16W, DA, TP, 1005
47 2007-007517 R473 R-CHIP, 240Kohm, 1%, 1/16W, DA, TP, 1005
48 2007-007528 R472 R-CHIP, 1.5Kohm, 1%, 1/16W, DA, TP, 1005
C103, C105, C110, C112,
C113, C116, C130, C139,
49 2203-000233 C-CHIP, 100pF, 5%, 50V, TP, 1005
C165, C468, C469, C470,
C471, C123
C107, C143, C144, C148,
C149, C153, C155, C206,
50 2203-000254 C207, C422, C440, C441, C-CHIP, 10nF, 10%, 16V, TP, 1005
C442, C462, C966, C968,
C969, C971, C982, C125
51 2203-000311 C104 C-CHIP, 120pF, 5%, 50V, TP, 1005
52 2203-000359 C124 C-CHIP, 150pF, 5%, 50V, TP, 1005
C119, C122, C135, C163,
53 2203-000438 C-CHIP, 1nF, 10%, 50V, TP, 1005
C203, C220, C924, C169
54 2203-000466 C146, C101 C-CHIP, 1pF, 0.25pF, 50V, TP, 1005
55 2203-000489 C109 C-CHIP, 2.2nF, 10%, 50V, TP, 1005
56 2203-000628 C114, C118, C926 C-CHIP, 22pF, 5%, 50V, TP, 1005
57 2203-000679 C216, C221 C-CHIP, 27pF, 5%, 50V, TP, 1005
C136, C140, C141, C147,
58 2203-000812 C159, C161, C167, C168, C-CHIP, 33pF, 5%, 50V, TP, 1005
C170, C219, C152
59 2203-000870 C171, C101 C-CHIP, 3pF, 0.25pF, 50V, TP, 1005
60 2203-001017 C172 C-CHIP, 4pF, 0.25pF, 50V, TP, 1005
61 2203-000888 C120 C-CHIP, 4.7nF, 10%, 50V, TP, 1608
62 2203-000940 C138, C931 C-CHIP, 47pF, 10%, 50V, TP, 1005
63 2203-000995 C131, C134 C-CHIP, 47pF, 5%, 50V, TP, 1005
64 2203-001103 C142 C-CHIP, 6.8nF, 10%%, 50V, TP, 1608
65 2203-001221 C453 C-CHIP, 820pF, 10%, 50V, TP, 1005
66 2203-001259 C205 C-CHIP, 8pF, 5%, 50V, TP, 1005
67 2203-001385 C162, C160 C-CHIP, 1.5pF, 0.25pF, 50V,NPO, TP, 1005
68 2203-001389 C108 C-CHIP, 12nF, 10%, 50V, TP, 1608
69 2203-001441 C204 C-CHIP, 75pF, 5%, 50V, TP, 1005
70 2203-001598 C145, C150, C157 C-CHIP, 2.2uF, +80-20%, 16V, TP, 2012
71 2203-002443 C117 C-CHIP, 330pF, 10%, 50V, TP, 1005
72 2203-002525 C460 C-CHIP, 560pF, 10%, 50V, TP, 1005
73 2203-005052 C218 C-CHIP, 3.3pF, 0.25pF, 50V, TP, 1005
C102, C106, C111, C115,
74 2203-005061 C402, C435, C439, C461, C-CHIP, 100nF, +80-20%, 16V, TP, 1005
C465, C466, C467, C919
75 2203-005065 C436 C-CHIP, 1uF, +80-20%, 10V, TP, 1608
76 2203-005234 C164 C-CHIP, 1.2pF, 0.25pF, 50V, TP, 1005
77 2203-005496 C941 C-CHIP, 220nF, +80-20%, 16V, TP, 1005
78 2404-001083 C400, C404 CAP-TANTAL, 220uF, 20%, 6.3V, 7125
79 2404-001105 C151, C970 CAP-TANTAL, 10uF, 20%, 6.3V
80 2404-001113 C154 C-TA, CHIP, 22uF, 20%, 6.3V,-,TP, 3528
81 2703-001040 L206, L104, L205 Inductor, 10nH, 5%, 1608
82 2703-001513 L204 Inductor, 100nH, 5%, 1.8x1.12x1.02mm
83 2703-001189 L200, L203 Inductor, 18nH, 5%, 1608
84 2703-001748 L100 Inductor, 6.8nH, 5%, 1005
85 2703-001293 L101, L201, L202 Inductor, 82nH, 5%, 1608
86 2703-001165 L207 Inductor, 4.7nH, 5%, 1608
2-2 Samsung Electronics
Electrical Parts List
87 2703-001259 L106, L108 Inductor, 47nH, 5%, 1608
88 2703-001514 L105 Inductor, 68nH, 5%, 1608
89 2703-001784 L400 INDUCTOR-SMD, 22UH, 20%, 6.6X7.5X2.5MM
90 2801-003747 X300 Crystal, 32.768KHz, 30ppm, 9pF
91 2806-001161 U104 VCO, 880-915MHz, TP, 5V, 50mA
92 2806-001162 U100 VCO, 1150-1185MHz, TP, 5V
93 2806-001210 U849 Oscillator-VCO, 545MHZ, TP, 2.85V, 5MA
94 2904-001092 F100 FILTER-SAW, 225.01MHz
95 2904-001094 F200 FILTER-SAW, 947.5MHz, 12.5MHz, +-12.5MHz/1dB
96 2904-001124 F101 FILTER-SAW, 947.5MHz, 25MHz , TP
97 3705-001163 J1004 CONNECTOR-COAXIAL, SMC, JACK, 100mohm
98 3710-001277 J1003 B'd Connector, 60P, 2R, 0.5mm, SOCKET
Samsung Electronics 2-3
2. Electrical Parts List
Main B'd (SOLD)
NO SEC CODE Location No. Description Etc
1 0401-001033 D304 DIODE-SWITCHING, MCL4154,25V,200mA,M-MELF,TP
2 0404-001044 D302,D303 DIODE-SCHOTTY, 20V, 1A, SMD
3 0404-001054 U206 DIODE-SCHOTTY, 70V, 15mA. SOT-143
4 0407-001002 D301 DIODE-ARRAY, 80V, 300mA, CA2-3, EM3
5 0501-000162 Q401 TR-SMALL SIGNAL, PNP, 200mW, SC-70
6 0506-000107 Q402 TR-ARRAY, NPN, 50V, 40V, 30mA, 300mW
7 0506-001004 U109, U410 TR-ARRAY, NPN/PNP, 2.50V, 300mW, UM5
8 0506-001024 U200 TR-ARRAY, PNP/NPN, 200mW, UM6
9 0506-001030 Q403 TR-ARRAY, NPN, 150MW, SC-88A, TP
10 0801-000796 U842 IC-CMOS LOGIC, GATE, SOP, 5P, 64MIL
11 0801-0002345 U852 IC-CMOS LOGIC, INVERTER, 200mW, SOP, 5P
12 1201-001456 U203 IC-OP AMP, SOT-23, 5P, SINGLE, 70dB
13 1201-001007 U411 IC-OP AMP, SOP, 14P, DUAL
14 1201-001299 U202 IC-POWER AMP, RF-K, 8P, SINGLE, 8V
15 1203-001256 U311 IC-VOLTAGE REGULATOR, SOT-23, 5P, 59MIL
16 1203-001454 U307, U406 IC-VOLTAGE REGULATOR, SOT-23, 5P, 59MIL
17 1203-001515 U304 IC-CHARGE, SSOP, 16P, 150MIL
18 1203-001740 U400 IC-voltage translator, SOP, 16P, 150MIL
19 1205-001697 U405 IC-CODE, TQFP, 80P, 472MIL, 3V, T R, VLSI
20 2007-000070 R201 R-CHIP, 0ohm, 5%, 1/16W, DA, TP, 1005
21 2007-000137 R205 R-CHIP, 2Kohm, 5%, 1/16W, DA, TP, 1005
22 2007-000138 R204 R-CHIP, 100ohm, 5%, 1/16W, DA, TP, 1005
23 2007-000139 R413, R417 R-CHIP, 220ohm, 5%, 1/16W, DA, TP, 1005
R218, R223, R305, R419,
24 2007-000140 R-CHIP, 1Kohm, 5%, 1/16W, DA, TP, 1005
R420, R991
25 2007-000142 R200, R-CHIP, 2.7Kohm, 5%, 1/16W, DA, TP, 1005
26 2007-000143 R139, R213 R-CHIP, 4.7Kohm, 5%, 1/16W, DA, TP, 1005
27 2007-000147 R224 R-CHIP, 8.2Kohm, 5%, 1/16W, DA, TP, 1005
R403, R410, R411, R418,
28 2007-000148 R429, R526, R527, R982, R-CHIP, 10Kohm, 5%, 1/16W, DA, TP, 1005
R983, R971, R989
29 2007-000149 R214 R-CHIP, 12Kohm, 5%, 1/16W, DA, TP, 1005
30 2007-000151 R216 R-CHIP, 15Kohm, 5%, 1/16W, DA, TP, 1005
31 2007-000153 R215 R-CHIP, 22Kohm, 5%, 1/16W, DA, TP, 1005
32 2007-000157 R217 R-CHIP, 47Kohm, 5%, 1/16W, DA, TP, 1005
R400, R401, R430, R437,
33 2007-000162 R-CHIP, 100Kohm, 5%, 1/16W, DA, TP, 1005
R966, R990, R993, R989
34 2007-000758 R455, R457 R-CHIP, 330Kohm, 5%, 1/16W, DA, TP, 1005
35 2007-000831 R203 R-CHIP, 39Kohm, 5%, 1/16W, DA, TP, 1005
36 2007-001119 R211 R-CHIP, 680ohm, 5%, 1/16W, DA, TP, 1005
37 2007-001306 R210 R-CHIP, 150ohm, 5%, 1/16W, DA, TP, 1005
38 2007-001307 R208 R-CHIP, 180ohm, 5%, 1/16W, DA, TP, 1005
39 2007-001325 R212 R-CHIP, 3.3Kohm, 5%, 1/16W, DA, TP, 1005
40 2007-002797 R225, R521 R-CHIP, 560ohm, 5%, 1/16W, DA, TP, 1005
41 2007-007008 R306 R-CHIP, 300ohm, 5%, 1/16W, DA, TP, 1005
42 2007-007107 R311 R-CHIP, 100Kohm, 1%, 1/16W, DA, TP, 1005
2-4 Samsung Electronics
Electrical Parts List
43 2007-007137 R302 R-CHIP, 18Kohm, 1%, 1/16W, DA, TP, 1005
44 2007-007136 R446, R463 R-CHIP, 4.7Kohm, 1%, 1/16W, DA, TP, 1005
R445, R448, R461, R451,
45 2007-007142 R-CHIP, 10Kohm, 1%, 1/16W, DA, TP, 1005
R453, R456, R458, R462
46 2007-007309 R304, R307 R-CHIP, 12Kohm, 1%, 1/16W, DA, TP, 1005
47 2007-007311 R449, R450, R454, R460, R-CHIP, 22Kohm, 1%, 1/16W, DA, TP, 1005
48 2007-007312 R502 R-CHIP, 20Kohm, 1%, 1/16W, DA, TP, 1005
49 2007-007318 R443, R452, R459, R468 R-CHIP, 1Kohm, 1%, 1/16W, DA, TP, 1005
50 2007-007586 R444, R447, R465, R466 R-CHIP, 470ohm, 1%, 1/16W, DA, TP, 1005
51 2007-007586 R310 R-CHIP, 82Kohm, 1%, 1/16W, DA, TP, 1005
52 2007-007592 R303 R-CHIP, 270Kohm, 1%, 1/16W, DA, TP, 1005
C209, C214, C223, C226,
53 2203-000233 C-CHIP, 100pF, 5%, 50V, TP, 1005
C227, C229, C233, C208
C200, C201, C315, C317,
C405, C419, C421, C423,
54 2203-000254 C-CHIP, 10nF, 10%, 16V, TP, 1005
C427, C428, C438, C458,
C967
C407, C451, C455, C935,
55 2203-000438 C-CHIP, 1nF, 10%, 50V, TP, 1005
C936
56 2203-000489 C446, C459 C-CHIP, 2.2nF, 10%, 50V, TP, 1005
57 2203-000585 C210 C-CHIP, 220pF, 10%, 50V, TP, 1005
58 2203-000628 C213 C-CHIP, 22pF, 5%, 50V, TP, 1005
59 2203-000714 C445, C464 C-CHIP, 3.3nF, 10%, 50V, TP, 1005
60 2203-000725 C447, C457 C-CHIP, 3.9nF, 10%, 50V, TP, 1005
61 2203-000812 C224 C-CHIP, 33pF, 5%, 50V, TP, 1005
62 2203-000854 C920 C-CHIP, 39pF, 5%, 50V, NPO,TP, 1005
63 2203-000940 C963, C972 C-CHIP, 470pF, 10%, 50V, TP, 1005
64 2203-001033 C444, C463 C-CHIP, 5.6nF, 10%, 25V, TP, 1005
65 2203-001153 C983 C-CHIP, 68nF, 5%, 50V, TP, 1005
66 2203-001221 C212 C-CHIP, 820pF, 10%, 50V, TP, 1005
C922, C979, C980, C981,
67 2203-001239 C-CHIP, 82pF, 5%, 50V, TP, 1005
C974, C975
68 2203-001259 C174 C-CHIP, 8pF, 5%, 50V, TP, 1005
69 2203-001405 C406, C429 C-CHIP, 22nF, 10%, 50V, X7R, TP, 1005
70 2203-001432 C424, C450, C452 C-CHIP, 47nF, 10%, 16V, TP, 1005
71 2203-002443 C448, C449, C454, C456 C-CHIP, 330pF, 10%, 50V, TP, 1005
72 2203-005061 C302, C304, C408, C985 C-CHIP, 100nF, +80-20%, 16V, TP, 1005
73 2203-005065 C230, C303, C311 C-CHIP, 1uF, +80-20, 10V, TP, 1608
74 2203-005367 C305 C-CHIP, 6.8uF, 20%, 25V, 3225
75 2404-001039 C430 CAP-TANTAL, 47uF, 20%, 6.3V, 3528
76 2404-001083 C228, CAP-TANTAL, 220uF, 20%, 6.3V, 7125
C202, C316, C409, C410,
77 2404-001105 CAP-TANTAL, 10uF, 20%, 6.3V
C437, C961
78 2404-001086 C942 Capacitor, 4.7uF, 20%, 6.3V, 2012
79 2404-001113 C314 C-TA, CHIP , 22uF, 20%, 6.3V,-, 3528
80 2703-000153 L402, L404 Inductor, 1000uH, 20%, 1210-ac13225
81 2703-001174 L208 Inductor, 33nH, 5%, 1608
82 2703-001417 L401, L403 Inductor, 680uH, 20%, 3225
83 2703-001781 L300 INDUCTOR-SMD, 10UH, 20%, 4.45X6.6X2.5MM
84 2809-001220 U201 VCTCXO, 13MHz, 2.5pm, TP, 3V
Samsung Electronics 2-5
Electrical Parts List
85 2909-001072 U204 IC-SWITCH, 942.5MHz, 897.5MHz, TP
86 3301-001177 FB100 CORE-FERRITE BEAD, AB, 3.2x1.6x1.1mm
87 3301-001208 B1, B2 CORE-FERRITE BEAD, AB, 1.6x0.8x0.8mm
88 3709-001074 J400 SIM CONNECTOR, 6P, SMD-S
89 4709-001124 U205 COUPLER, 800+-1000MHz, 14dB, 3.2x1.6x0.7mm
2-6 Samsung Electronics
2. Electrical Parts List
Key B'd (COMP)
NO SEC CODE Location No Description Etc
D404, D415, D416, D417
1 0406-001005 D421, D422, D423, D424, ESD DIODE, 6V/1mA, SOT-23
D426, D427
D405, D406, D407, D408
2 0601-000273 LED-CHIP, Y/GRN, 0.8!1.2mm, 570nm
D409, D410, D411, D412
3 0601-000276 D428 LED-CHIP, Y/GRN, 1.6!2.0mm, 570nm
4 1405-001019 VA1 VARISTOR, 5.6V, -, 1.6!0.8mm, TP
5 2007-000138 R477 R-CHIP, 100ohm, 5%, 1/16W, DA, TP, 1005
6 2203-000254 C1006, C1007 C-CHIP, 10nF, 10%, 16V, TP, 1005
7 2203-001239 C923, C1028, C1029 C-CHIP, 82pF, 5%, 50V, TP, 1005
Samsung Electronics 2-7
Key B'd (SOLD)
NO SEC CODE Location No Description Etc
1 0406-001005 D420, D429, D430 ESD DIODE, 6V/1mA, SOT-23
2 0406-001012 D402, D414 ESD DIODE, 13.3V/1mA, 300W, SOT-23
3 0407-001002 D431 DIODE-ARRAY, 80V, 300mA, CA2-3, EM3
D305, D306, D403, D418
4 0407-001030 DIODE-ARRAY, 5V, CK5-2, SOT-23
D419
5 0501-000218 Q300 TR-SMALL SIGNAL, NPN, 200mW, UMT
6 0501-002011 Q500, Q502 TR-SMALL SIGNAL, NPN, 200mW, SOT-23
7 0504-001012 U878 TR-DIGITAL, NPN, 150mW, 10K-47Kohm, EMT
8 0505-001332 Q501 FET-SILICON, N, 25V, 0.22A, 4OHM, 3W, SC70-6
9 1001-001088 U887, U888 IC-ANALOG SWITCH, SOT-23, 6P, 13V, 571MW
10 1202-001022 U886 IC-VOLFAGECOMP, 8P, DUAL, 36V, CMOS
11 0504-001012 U861 TR-DIGITAL, NPN, 150mW, 10K-47Kohm, EMT
R478, R479, R482, R483
12 2007-000138 R-CHIP, 100ohm, 5%, 1/16W, DA, TP, 1005
R484, R485, R1002, R1003
R967, R969, R970, R988,
13 2007-000139 R-CHIP, 220ohm, 5%, 1/16W, DA, TP, 1005
R1027
14 2007-000143 R301, R502 R-CHIP, 4.7Kohm, 5%, 1/16W, DA, TP, 1005
15 2007-000148 R971, R980 R-CHIP, 10Kohm, 5%, 1/16W, DA, TP, 1005
R300, R975, R1032, R1036,
16 2007-000162 R-CHIP, 100Kohm, 5%, 1/16W, DA, TP, 1005
R1037, R1038, R1039
17 2007-000171 R498, R1033 R-CHIP, 0ohm, 5%, 1/16W, DA, TP, 1005
18 2007-000172 R480, R481 R-CHIP, 10ohm, 5%, 1/16W, DA, TP, 1005
19 2007-000242 R501 R-CHIP, 1.5Kohm, 5%, 1/16W, DA, TP, 1005
20 2007-001308 R524 R-CHIP, 200ohm, 5%, 1/16W, DA, TP, 1005
21 2007-007142 R1035 R-CHIP, 10Kohm, 1%, 1/16W, DA, TP, 1005
22 2007-007138 R1034 R-CHIP, 27Kohm, 1%, 1/16W, DA, TP, 1005
23 2203-000254 C950 C-CHIP, 10nF, 10%, 16V, TP, 1005
C1021, C1022, C1030
24 2203-001239 C-CHIP, 82pF, 5%, 50V, TP, 1005
C1031
25 2203-005061 C300 C-CHIP, 100nF, +8-20%, 16V, TP, 1005
26 2203-005065 C940 C-CHIP, 1◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
