Image preview - the first page of the document
>> Download Samsung SGH-M100 service manual documenatation <<
Text preview - extract from the document
DUAL BAND Mobile
Cellular Phone
SGH-M100
SERVICE Manual
Dual Band Mobile Cellular Phone CONTENTS
1. Electrical Parts List
2. Exploded Views and Parts List
3. Block Diagram
4. PCB Views
5. Schematic Diagrams
ABC
GH
I
DE
JKL F
PQ
RS
MN
TUV O
MB
B
WX
YZ
2. Exploded View and its Parts List
2-1 SGH-M100 Cellular phone Exploded View
1-1
1-5 1
1-2
1-6
1-7
1-8
1-9
1-3
1-10
1-4
1-11
2
4-4
3
4-1
4
4-3
4-2
7 9
5
6
8
10
11
12-1
12
12-2 14
12-3
12-4 12-5
13
SAMSUNG Proprietary-Contents may change without notice
2-1
Exploded view and its Part List
2-2 SGH-M100 Cellular phone Parts List
NO DESCRIPTION SEC.CODE REMARK
1 MEC-FRONT COVER GH75-00498C GOLD
1-1 MEC-FLIP COVER GH75-00500C
1-2 PMO-FRONT COVER GH72-01126C SNA
1-3 MEC-HINGE ASS'Y GH75-11115A SNA
1-4 NPR-SHIELD STRIP GH7100258A
1-5 PMO-IRDA WINDOW GH72-01130A
1-6 PMO-EARJACK HOLDER GH72-01134A
1-7 SPEAKER 3001-001148
1-8 MEC-VOLUME KEY GH75-00746A
1-9 MPR-LCD SILICON GH74-00548A SNA
1-10 PMO-LCD WINDOW GH72-01129A
1-11 MPR-LCD SPONGE GH74-00493A SNA
2 PMO-KEY PAD GH72-01144A
3 PMO-MIC HOLDER GH73-00494A
4 KEY PBA ASS'Y GH82-00031A
4-1 VOL KEY ASS'Y GH59-00092A
4-2 REAR SHIELD CAN GH72-01132A
4-3 MIC 3003-001047
4-4 METAL DOME GH59-00101A
5 MPR-MIC SPONGE GH74-00557A
6 BUZZER 3002-001095
7 RMO-BUZZER HOLDER GH7300337A
8 DISPLAY LCD GH07-00035A
9 PMO-KEY SHIELD CAN GH72-01133A
10 MAIN PBA GH92-00785A
11 ANTENNA GH42-00062B
12 MEC-REAR COVER GH75-00499A GOLD
12-1 PMO-REARCOVER GH72-011127A SNA
12-2 IPR-LOCKER SPRING GH70-10516A SNA
12-3 PMO-BATTERAY LOCKER GH72-01143A SNA
12-4 PMO-SIM LOCKER GH72-00513D SNA
12-5 IPR-SIM SPRING GH70-00006A SNA
13 SCREW-MACHINE 6001-001345 4PCS
14 BATTERY GH43-00206A 750 mAh
SAMSUNG Proprietary-Contents may change without notice
2-2
Exploded view and its Part List
2-3 Test Jig (GH80-00161A)
HP
D S
SD
TO
/L
IG
61A ST J S/W UG
-00100 TE NICS
DEB
G
0
GH800/M1 LECTRO
U
EB
1
D
-A E
+ SGH
3.8V
TE
WER
ST
-PO
PA
CK
S/WLOAD
WN
/W S DO
S D
O S
AUT
Data Cable Test Cable
SWITCH
MODE AUTO SDS DOWNLOAD DEBUG SDS DEBUG
S/W S/W S/W D/L
D/L HIGH LOW HIGH LOW CONNECT N.C
CAL HIGH LOW LOW HIGH CONNECT N.C
SAMSUNG Proprietary-Contents may change without notice
2-3
Exploded view and its Part List
2-4 MP3 Data Cable (GH59-00090A) 2-5 Desk Top Charger
Europe (GH44-00121A)
China (GH44-00121C)
2-6 Cigarette Lighter Adaptor 2-7 Test Cable (GH39-00051A)
(GH44-30546A)
2-8 Jack Adaptor (GH59-00103A) 2-9 CD ROM (GH46-00006A)
SAMSUNG Proprietary-Contents may change without notice
2-4
Exploded view and its Part List
2-10 Travel Adaptor 2-11 Travel Adaptor
Europe (GH44-00119A) England (GH44-00119B)
2-12 Travel Adaptor 2-13 Travel Adaptor
China (GH44-00119C) Australian (GH44-00119D)
SAMSUNG Proprietary-Contents may change without notice
2-5
Exploded view and its Part List
MEMO
SAMSUNG Proprietary-Contents may change without notice
2-6
